1,5
3,27
2
1,5
Verpackt im Gurt nach DIN IEC 60286-3
Tape on Reel Packaging according to DIN IEC 60286-3
Verpackungseinheit: 560 Stück
Anforderungsstufe 1
1
12,7
9,57
1,27
Packaging unit: 560 pcs
Performance Level 1
Kontaktbereich vergoldet
Mating Area gold plating
Anschlussbereich verzinnt 4-6 µm
3,25
1,8
Terminal Area 4-6 µm tin plating
Koplanarität der Anschlüsse
≤
0,1 mm
Coplanarity Area of Termination
≤
0,1 mm
8,57
10,77
±0,03
330
5 x 1,27 = 6,35
1,5
-0,03
b6
1,27
b1
Abspulrichtung -
Reel off Direction
7,2
8,8
10
+0,2
4
-0,1
5
6,4
10,37
0,75
-0,05
4,25
Leiterplatten-Layout Vorschlag für SMT
24
PCB-Layout Proposal for SMT
10,77
±0,03
2,21
±0,03
1,27
5 x 1,27 = 6,35
1,27
2
±0,05
b1
16
BA7-03 - Standard Bauhöhe
type7-03 - Standard Assembly Height
Copyright by ERNI Production GmbH & Co. KG
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm
Scale
3:1
7,6
2,2
a1
0,3
1,2
0,8
1,6
-0,03
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
e
Index
17.07.2015
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Messerl. SMC-B 12-SMD-BA7-03
Male SMC-B 12-SMD-type7-03
www.ERNI.com
Class
100103210101
SMCB
K
A3
