Direct Coupling - Split Shell
See inside back cover fold-out or pages 13 and 14 for Tables I and II.
TABLE III: FRONT ADAPTER
J Max - Conn. Designator
A-E-F
D-B-G-K
J-H-L-S
C
1.180 (30.0) 1.250 (31.8)
1.180 (30.0) 1.250 (31.8)
1.180 (30.0) 1.250 (31.8) 1.735 (44.1)
1.180 (30.0) 1.250 (31.8) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.610 (40.9) 1.560 (39.6) 1.915 (48.6)
1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
1.610 (40.9) 2.190 (55.6) 1.915 (48.6)
TABLE IV: ELBOW DIMENSIONS
G
Elbow
E
F
Max
Size
Max
Max
02 .440 (11.2) 1.590 (40.4) .680 (17.3)
03 .440 (11.2) 1.590 (40.4) .680 (17.3)
04 .440 (11.2) 1.590 (40.4) .680 (17.3)
05 .500 (12.7) 1.650 (41.9) .750 (19.1)
06 .500 (12.7) 1.650 (41.9) .750 (19.1)
07 .560 (14.2) 1.720 (43.7) .810 (20.6)
08 .560 (14.2) 1.720 (43.7) .810 (20.6)
09 .620 (15.7) 1.750 (44.5) .870 (22.1)
10 .680 (17.3) 1.850 (47.0) .930 (23.6)
11 .680 (17.3) 1.850 (47.0) .930 (23.6)
12 .750 (19.1) 1.910 (48.5) 1.000 (25.4)
13 .820 (20.8) 1.970 (50.0) 1.060 (26.9)
14 .820 (20.8) 1.970 (50.0) 1.060 (26.9)
15 .880 (22.4) 2.030 (51.6) 1.120 (28.4)
16 .880 (22.4) 2.030 (51.6) 1.120 (28.4)
Shell
Size
08/09
10/11
12/13
14/15
16/17
18/19
20/21
22/23
24/25
28/29
32/33
36
40
H
Max
1.530 (38.9)
1.530 (38.9)
1.530 (38.9)
1.590 (40.4)
1.590 (40.4)
1.660 (42.2)
1.660 (42.2)
1.690 (42.9)
1.790 (45.5)
1.790 (45.5)
1.850 (47.0)
1.910 (48.5)
1.910 (48.5)
1.970 (50.0)
1.970 (50.0)
TABLE V: CABLE ENTRY
K
L
Dash
Dia
Dia
No.
.125 (3.2)
.250 (6.4)
02
.188 (4.8)
.312 (7.9)
03
.250 (6.4)
.375 (9.5)
04
.312 (7.9)
.438 (11.1)
05
.375 (9.5)
.500 (12.7)
06
.438 (11.1)
.562 (14.3)
07
.500 (12.7)
.625 (15.9)
08
.562 (14.3)
.688 (17.5)
09
.625 (15.9)
.750 (19.1)
10
.688 (17.5)
.812 (20.6)
11
.750 (19.1)
.875 (22.2)
12
.812 (20.6)
.938 (23.8)
13
.875 (22.2) 1.000 (25.4)
14
.938 (23.8) 1.062 (27.0)
15
16 1.000 (25.4) 1.125 (28.6)
17 1.062 (27.0) 1.188 (30.2)
18 1.125 (28.6) 1.250 (31.8)
20 1.250 (31.8) 1.375 (34.9)
22 1.375 (34.9) 1.500 (38.1)
24 1.500 (38.1) 1.625 (41.3)
1. Metric dimensions (mm) are indi-
cated in parentheses.
2. When using Connector Designator B
refer to pages 18 and 19 for part
number development.
3. Backshells supplied with 600-052-*
band, see Glenair Series 600 Tool
Catalog for installation.
© 2005 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 440 - Page 53
440
440-074
EMI/RFI Banding Adapter
