VIB0101THJ
•
Efficiency: up to 96%
•
Input: 48 V
•
Power Density: >1000 W/in
3
Product Description
•
Current sharing: 5%
•
Isolation: 2,250 Vdc
•
Footprint: 0.56 in
2
/ 1.08 in
2
C
22,0
0.87
AP8265VIDE213P
NRTL
V
•
I Chip BCM
Bus Converter
TM
TM
0812
™
–In
PC RSV TM
+In
™
VICOR CORP.
MADE IN USA
RoHS
BCM
–Out
S
US
™
S
22,0
0.87
RoHS
C
NRTL
US
MADE
IN
USA
U.S. PATS. LISTED ON PACKING MATERIALS & DATASHEETS
+Out
–Out
+Out
16,5
0.65
Half–Chip
6,73
0.265
32,5
1.28
Full–Chip
mm
in
The Bus Converter family consists of 14 models that provide an isolated intermediate bus voltage to power non-isolated POL
converters. The 48 V BCMs operate from a narrow-input-range DC source and depending on the model selected, deliver a single
output with ratings of 1.5 Vdc to 48 Vdc at up to 300 W. The 48 Vdc BCM family offers superior performance, the highest
efficiency and power density in the smallest package available.
Model
Number
B048F015T14
B048F030T21
B048F040T20
B048F060T24
B048F080T24
B048F096T24
B048F120T30
B048F160T24
B048F240T30
B048F320T30
B048F480T30
VIB0101THJ
Input
Voltage
(V)
38 – 55
38 – 55
38 – 55
38 – 55
38 – 55
38 – 55
38 – 55
38 – 55
38 – 53
38 – 55
38 – 55
38 – 55
Output
Voltage
(V)
1.19 – 1.71
2.38 – 3.43
3.17 – 4.58
4.75 – 6.87
6.33 – 9.16
7.60 – 11.0
9.50 – 13.8
12.7 – 18.3
19.0 – 26.5
25.3 – 36.7
38.0 – 55.0
9.5 – 13.75
Output
Power
(W)
135
210
200
240
240
240
300
240
300
300
300
120
Output
Current
(A)
90
70
50
40
30
25
25
15
12
9
6
11.3
Temp. Grade
T
T
T
T
T
T
T
T
T
T
T
T
Package
Full
Full
Full
Full
Full
Full
Full
Full
Full
Full
Full
Half
Part Numbering
B
Bus Converter
Module
Input Voltage
Designator
0 4 8
Configuration
F
= J-Lead
T
= Through hole
F
1 2 0
Output Voltage
Designator
( = V
OUT
x 10 )
T
3 0
Output Power
Designator
( = P
OUT
/ 10 )
Product Grade Temperatures (°C)
Grade
Storage
Operating (T
J
)
T=
– 40 to 125
–40 to 125
M=
–65 to 125
–55 to 125
VI
Branding
V
•
I Chip
B
x x x x
Product Reference
Reference Only
T
F
J
Package Size
F
= Full
H
= Half
Leadform
J
= J-Lead (SMT)
FPA Family
B
= Bus Converter Module
Product Grade Temperatures (°C)
Grade Storage (T
ST
) Operating (T
J
)
T
=
– 40 to 125
–40 to 125
M
=
–65 to 125
–55 to 125
Typical Application
enable / disable
switch
SW1
F1
POL
TM
PC
POL
+In
V
IN
3.15 A
C1
10 µF
-In
BCM
+Out
V
OUT
-Out
POL
POL
vicorpower.com
800-735-6200
Rev. 1.3
9/09
Page 1 of 2
General Specifications
Parameter
ISOLATION
Voltage
Capacitance
Resistance
3,000
10
cTÜVus
AGENCY APPROVALS / STANDARDS
CE Mark
RoHS
THERMAL
Operating Junction Temperature
-40 to 125
-55 to 125
Storage Temperature
-40 to 125
-65 to 125
°C
°C
°C
°C
T-Grade
M-Grade
T-Grade
M-Grade
2,250
1750
V
pF
MΩ
Min.
UL /CSA 60950, EN60950
Low Voltage Directive
Min.
Value
Full
Half
Units
Notes
BCM Mechanical Outline Drawing Full Chip
NOTES:
mm
1. DIMENSIONS ARE inch .
2. UNLESS OTHERWISE SPECIFIED, TOLERANCES ARE:
.X / [.XX] = +/-0.25 / [.01]; .XX / [.XXX] = +/-0.13 / [.005]
3. PRODUCT MARKING ON TOP SURFACE
BOTTOM VIEW
TOP VIEW ( COMPONENT SIDE )
DXF and PDF files are available on vicorpower.com
BCM Mechanical Outline Drawing Half Chip
BOTTOM VIEW
TOP VIEW ( COMPONENT SIDE )
The products described on this document are protected by the following U.S. Patents Numbers: 5,945,130; 6,403,009; 6,710,257; 6,911,848; 6,930,893; 6,934,166; 6,940,013;
6,969,909; 7,038,917; 7,166,898; 7,187,263; 7,361,844; D496,906; D505,114; D506,438; D509,472 and for use under 6,975,098 and 6,984,965
vicorpower.com
800-735-6200
Rev. 1.3
9/09
Page 2 of 2
