440-001
EMI/RFI Crimp Ring Adapter
Direct Coupling - Split Shell
440
A-B -C-D-E-F
G-H-J-K-L-S
* Conn. Desig. B See Note 4
CONNECTOR
DESIGNATORS
*
440 F D 001 M 16 32
Product Series
Connector Designator
Angle and Profile
D = Split 90
F = Split 45
Cable Entry (Table V)
Shell Size (Table I)
Finish (Table II)
Basic Part No.
DIRECT COUPLING
A Thread
(Table I)
J
E
G
(Table III)
(Table IV)
J
(Table III) (Table IV)
B Typ.
(Table I)
F (Table IV)
K*
Split 45°
N*
L*
M*
P*
R*
* (Table V)
TABLE III: FRONT ADAPTER
J Max - Conn. Designator
A-E-F
D-B-G-K
J-H-L-S
C
1.180 (30.0) 1.250 (31.8)
1.180 (30.0) 1.250 (31.8)
1.180 (30.0) 1.250 (31.8) 1.735 (44.1)
1.180 (30.0) 1.250 (31.8) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
1.610 (40.9) 1.560 (39.6) 1.915 (48.6)
1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
1.610 (40.9) 2.190 (55.6) 1.915 (48.6)
Split 90°
H (Table IV)
Shell
Size
08/09
10/11
12/13
14/15
16/17
18/19
20/21
22/23
24/25
28/29
32/33
36
40
See inside back cover fold-out or pages
13 and 14 for Tables I and II.
1. For proper installation of crimp ring, use Thomas & Betts (or
equivalent) installation dies listed (Table V) for each dash no.
2. Metric dimensions (mm) are indicated in parentheses.
3. Dimensions shown are not intended for inspection criteria.
4. When using Connector Designator B refer to pages 18 and 19
for part number development.
© 2005 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 440 - Page 10
Direct Coupling - Split Shell
TABLE IV: ELBOW DIMENSIONS
E
Dash No.'s
F
G
Max
(Table V)
Max
Max
.440 (11.2)
06-23
1.402 (35.6)
.680 (17.3)
.500 (12.7)
26-30
1.462 (37.1)
.750 (19.1)
.560 (14.2)
1.820 (46.2)
31-32
.810 (20.6)
.620 (15.7)
33
1.850 (47.0)
.870 (22.1)
.680 (17.3)
34
1.950 (49.5)
.930 (23.6)
.820 (20.8)
35
2.070 (52.6)
1.060 (26.9)
.880 (22.4)
36
2.130 (54.1)
1.120 (28.4)
.940 (23.9)
2.190 (55.6)
38-39
1.180 (30.0)
H
Max
1.342 (34.1)
1.402 (35.6)
1.760 (44.7)
1.790 (45.5)
1.890 (48.0)
2.010 (51.1)
2.070 (52.6)
2.130 (54.1)
TABLE V: CABLE ENTRY
Dash
No.
06
10
13
16
20
23
26
29
30
31
32
33
34
35
36
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
K
Nom
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.312 (7.9)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
L
Nom
.090 (2.3)
.124 (3.1)
.149 (3.8)
.175 (4.4)
.219 (5.6)
.250 (6.4)
.275 (7.0)
.297 (7.5)
.312 (7.9)
.375 (9.5)
.430 (10.9)
.550 (14.0)
.670 (17.0)
.810 (20.6)
.920 (23.4)
1.040 (26.4)
1.122 (28.5)
1.224 (31.1)
1.353 (34.4)
1.425 (36.2)
1.550 (39.4)
1.675 (42.5)
1.800 (45.7)
1.925 (48.9)
2.050 (52.1)
2.175 (55.2)
2.300 (58.4)
2.425 (61.6)
2.530 (64.3)
2.655 (67.4)
2.780 (70.6)
2.905 (73.8)
M
Nom
.113 (2.9)
.145 (3.7)
.179 (4.5)
.215 (5.5)
.250 (6.4)
.281 (7.1)
.306 (7.8)
.335 (8.5)
.365 (9.3)
.406 (10.3)
.500 (12.7)
.620 (15.7)
.750 (19.1)
.880 (22.4)
1.000 (25.4)
1.120 (28.4)
1.192 (30.3)
1.294 (32.9)
1.423 (36.1)
1.545 (39.2)
1.670 (42.4)
1.795 (45.6)
1.920 (48.8)
2.045 (51.9)
2.170 (55.1)
2.295 (58.3)
2.420 (61.5)
2.545 (64.6)
2.670 (67.8)
2.795 (71.0)
2.920 (74.2)
3.045 (77.3)
N
Nom
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.250 (6.4)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
.440 (11.2)
P
Nom
.156 (4.0)
.187 (4.7)
.225 (5.7)
.261 (6.6)
.297 (7.5)
.327 (8.3)
.375 (9.5)
.405 (10.3)
.425 (10.8)
.500 (12.7)
.590 (15.0)
.710 (18.0)
.840 (21.3)
1.010 (25.7)
1.130 (28.7)
1.250 (31.8)
1.332 (33.8)
1.440 (36.6)
1.562 (39.7)
1.670 (42.4)
1.795 (45.6)
1.920 (48.8)
2.045 (51.9)
2.170 (55.1)
2.295 (58.3)
2.420 (61.5)
2.545 (64.6)
2.670 (67.8)
2.795 (71.0)
2.920 (74.2)
3.045 (77.3)
3.170 (80.5)
R
Nom
.194 (4.9)
.227 (5.8)
.256 (6.5)
.297 (7.5)
.335 (8.5)
.372 (9.4)
.406 (10.3)
.453 (11.5)
.473 (12.0)
.560 (14.2)
.670 (17.0)
.790 (20.1)
.920 (23.4)
1.090 (27.7)
1.210 (30.7)
1.330 (33.8)
1.412 (35.9)
1.520 (38.6)
1.643 (41.7)
1.750 (44.5)
1.875 (47.6)
2.000 (50.8)
2.125 (54.0)
2.250 (57.2)
2.375 (60.3)
2.500 (63.5)
2.625 (66.7)
2.750 (69.9)
2.875 (73.0)
3.000 (76.2)
3.125 (79.4)
3.250 (82.6)
Color
Code
(Ref.)
Yellow
Orange
Purple
Yellow
Green
Tin
Yellow
Red
Tin
Green
Red
Blue
Gray
Brown
Green
Pink
Orange
Purple
Yellow
Red
Blue
Gray
Brown
Green
Pink
Orange
Purple
Yellow
Red
Blue
Gray
Brown
Inst. Tool
Die No.
(Note 2)
WT402
WT406
WT409
WT411
WT414
WT416
WT440/5451
WT440/5452
WT440/5454
WT440/5457
GS590
GS710
GS840
GS1010
GS1130
GS1250
GS1332
GS1440
GS1563
GS1670
GS1795
GS1920
GS2045
GS2170
GS2295
GS2420
GS2545
GS2670
GS2795
GS2920
GS3045
GS3170
© 2005 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 440 - Page 11
440
440-001
EMI/RFI Crimp Ring Adapter
