LR9193-28RN: DescriptionRegulator, 1 Output, CMOS, PDSO5,; CategoryPower/power management The power supply circuit; File Size797KB，9 Pages; ManufacturerLRC; Websitehttp://www.lrc.cn; Environmental Compliance

Download Datasheet Parametric Compare View All

LR9193-28RN Overview

Regulator, 1 Output, CMOS, PDSO5,

LR9193-28RN Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	LRC
package instruction	TSOP, TSOP5/6,.11,37
Reach Compliance Code	unknown
Adjustability	FIXED
Nominal dropback voltage 1	0.21 V
Maximum absolute input voltage	6 V
JESD-30 code	R-PDSO-G5
Maximum grid adjustment rate	0.0056%
Maximum load regulation	0.014%
Output times	1
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current 1	0.3 A
Nominal output voltage 1	2.8 V
Package body material	PLASTIC/EPOXY
encapsulated code	TSOP
Encapsulate equivalent code	TSOP5/6,.11,37
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE
Certification status	Not Qualified
surface mount	YES
technology	CMOS
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
Maximum voltage tolerance	2%

Preview

Download Datasheet

View All

LESHAN RADIO COMPANY, LTD.

300mA Ultra-low Noise, Ultra-Fast

CMOS LDO Regulator

LR9193



FEATURES



Ultra-low Noise for RF Application

Ultra-Fast Respose in Line/Load Transient

Quick Start-Up (Typically 50S)

<0.01A Standby Current When Shutdown.

Low Dropout:220mV@300mA

Wide Operating Voltage Ranges:2.5V to

5.5V

TTL-logic-Controlled Shutdown Input

Low Temperature Coefficient

Current Limiting Protection

Thermal Shutdown Protection

Only 1F Output Capacitor Required for

Stability

High Power Supply Rejection Ratio

Custom Voltage Available

Fast output discharge

Available in 5-Lead SOT-23 and SC-70

Package

PCMCIA Cards

MP3 Players

Portable Information Appliances

DESCRIPTION

The LR9193 is designed for portable RF and

wireless

applications

with

demanding

performance and space requirements. The

LR9193 performance is optimized for battery-

powered systems to deliver ultra low noise

and low quiescent current. A noise bypass

pin is available for further reduction of output

noise. Regulator ground current increases

only slightly in dropout, further prolonging the

battery life. The LR9193 also works with low-

ESR ceramic capacitors, reducing the

amount of board space necessary for power

applications, critical in hand-held

wireless

devices. The LR9193 consumes less than

0.01μA in shutdown mode and has fast turn-

on time less than 50μs. The other features

include ultra low dropout voltage, high output

accuracy, current limiting protection, and high

ripple rejection ratio. Available in the 5-lead of

SC-70,SOT-23,packages.

APPLICATIONS



Cellular and Smart Phones

Battery-Powered Equipment

Laptop, Palmtops,Notebook Computers

Hand-Held Instruments

ORDERING INFORMATION

LR9193-

XX XX

TYPICAL APPLICATION

Package:

RN:SOT-23-5

URN:SC-70-5

3.3V-5.5V

1uF

VIN

VOUT

1uF

2.8V

Chip Enable

GND

LR9193

100k

22nF

Output Voltage:

12:1.2V

15:1.5V

18:1.8V

28:2.8V

::3.3V

CT: custom fixed output(50mv step)

AD:Adjustable

1/9

LR9193-28RN Related Products

	LR9193-28RN	LR9193-28URN	LR9193-12RN
Description	Regulator, 1 Output, CMOS, PDSO5,	Regulator, 1 Output, CMOS, PDSO5,	Regulator, 1 Output, CMOS, PDSO5,
Is it Rohs certified?	conform to	conform to	conform to
package instruction	TSOP, TSOP5/6,.11,37	TSSOP, TSSOP5/6,.08	TSOP, TSOP5/6,.11,37
Reach Compliance Code	unknown	unknown	unknown
Adjustability	FIXED	FIXED	FIXED
Nominal dropback voltage 1	0.21 V	0.21 V	0.21 V
Maximum absolute input voltage	6 V	6 V	6 V
JESD-30 code	R-PDSO-G5	R-PDSO-G5	R-PDSO-G5
Maximum grid adjustment rate	0.0056%	0.0056%	0.0024%
Output times	1	1	1
Number of terminals	5	5	5
Maximum output current 1	0.3 A	0.3 A	0.3 A
Nominal output voltage 1	2.8 V	2.8 V	1.2 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSOP	TSSOP	TSOP
Encapsulate equivalent code	TSOP5/6,.11,37	TSSOP5/6,.08	TSOP5/6,.11,37
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE
Certification status	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.95 mm	0.635 mm	0.95 mm
Terminal location	DUAL	DUAL	DUAL
Maximum voltage tolerance	2%	2%	2%
Maker	LRC	LRC	-
Maximum load regulation	0.014%	0.014%	-
Maximum operating temperature	85 °C	85 °C	-
Minimum operating temperature	-40 °C	-40 °C	-
