NRE-WY470M63V10X12.5F datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> NRE-WY470M63V10X12.5F

NRE-WY470M63V10X12.5F: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID; CategoryPassive components capacitor; File Size87KB，4 Pages; ManufacturerNichicon; Websitehttp://www.nichicon.co.jp; Environmental Compliance

Download Datasheet Parametric Compare View All

NRE-WY470M63V10X12.5F Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID

NRE-WY470M63V10X12.5F Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Nichicon
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	14 weeks
capacitance	47 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	10 mm
dielectric materials	ALUMINUM (WET)
ESR	270 mΩ
length	12.5 mm
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	130 °C
Minimum operating temperature	-40 °C
Package form	Radial
method of packing	Bulk
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	63 V
ripple current	400 mA
Terminal pitch	5 mm

Preview

Download Datasheet

View All

Miniature Aluminum Electrolytic Capacitors

+130

C WIDE TEMPERATURE RANGE, RADIAL LEADS, POLARIZED

FEATURES

NRE-WY Series

• -40

C* ~ +130

C EXTENDED OPERATING TEMPERATURE RANGE

• LONG LIFE (1,000 ~ 4,000 Hours @ 130C)

*200V and up -25°C ~ +130°C

includes all homogeneous materials

RoHS

Compliant

CHARACTERISTICS

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Capacitance Tolerance

After 2 minutes

Max. Leakage Current

After 1 minute

After 5 minutes

W.V. (Vdc)

S.V. (Vdc)

Max. Tan

@ 120Hz/20°C

C < 1000μF

C = 1,500μF

C = 2,200μF

C = 3,300μF

C = 4,700μF

Z-25°C/Z+20°C

Z-40°C/Z+20°C

Capacitance Change

Tan

Leakage Current

Capacitance Change

Tan

Leakage Current

P Number S

f D il

*See Part N b System for Details

10 ~ 400Vdc

1.0 ~ 4,700μF

-40 ~ +130°C (10 to 100Vdc), -25°C ~ +130°C (200 to 400Vdc)

±20% (M)

10 ~ 100Vdc: 0.01CV or 3μA whichever is greater

200Vdc, 400Vdc: 0.1CV+40μA

200Vdc, 400Vdc: 0.03CV+15μA

100

125

200

250

400

450

Low Temperature Stability

Impedance Ratio @ 120Hz

Load Life Test at Rated W.V.

1000 ~ 4000Hrs @ 130°C

(See part number table)

Shelf Life Test

+130°C 1000Hrs

0.20

0.16

0.14

0.12

0.10

0.09

0.08

0.15

0.20

0.09

0.22

0.18

0.16

0.14

0.12

0.24

0.20

0.18

0.16

0.26

0.22

Within ±30% of intial measured value

Within ±20% of intial measured value

Less than 300% of speciﬁed max. value

Less than 200% of speciﬁed max. value

Less than speciﬁed maximum vlaue

Within ±30% of intial measured value

Less than 300% of speciﬁed max. value

Not more than 500% of speciﬁed max. value

PART NUMBERING SYSTEM

NRE-WY 331 M 35V 10X16 TB F

RoHS Compliant

Series

TB = Tape & Box*

Case Size (DφxL)

Working Voltage (Vdc)

Tolerance Code (M=20%)

Capacitance Code: First 2 characters

signiﬁcant, third character is multiplier

*see tape speciﬁcation for details

Please review the notes on correct use, safety and precautions found on

pages T10

T11

of NIC’s

Electrolytic Capacitor catalog.

Also found at

www.niccomp.com/precautions

If in doubt or uncertainty, please review your speciﬁc application - process

details with NIC’s technical support personnel:

tpmg@niccomp.com

PRECAUTIONS

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com

SPECIFICATIONS ARE SUBJECT TO CHANGE

NRE-WY470M63V10X12.5F Related Products

	NRE-WY470M63V10X12.5F	NRE-WY220M50V8X11.5F	NRE-WY470M50V8X11.5F	NRE-WY100M50V8X11.5F
Description	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID
Is it Rohs certified?	conform to	conform to	conform to	conform to
Maker	Nichicon	Nichicon	Nichicon	Nichicon
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Factory Lead Time	14 weeks	14 weeks	14 weeks	14 weeks
capacitance	47 µF	22 µF	47 µF	10 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	10 mm	8 mm	8 mm	8 mm
dielectric materials	ALUMINUM (WET)	ALUMINUM (WET)	ALUMINUM (WET)	ALUMINUM (WET)
ESR	270 mΩ	350 mΩ	280 mΩ	600 mΩ
length	12.5 mm	11.5 mm	11.5 mm	11.5 mm
negative tolerance	20%	20%	20%	20%
Number of terminals	2	2	2	2
Maximum operating temperature	130 °C	130 °C	130 °C	130 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C
Package form	Radial	Radial	Radial	Radial
method of packing	Bulk	Bulk	Bulk	Bulk
polarity	POLARIZED	POLARIZED	POLARIZED	POLARIZED
positive tolerance	20%	20%	20%	20%
Rated (DC) voltage (URdc)	63 V	50 V	50 V	50 V
ripple current	400 mA	260 mA	300 mA	200 mA
Terminal pitch	5 mm	3.5 mm	3.5 mm	3.5 mm
