55091244403 datasheet, PDF - EEWORLD Datasheet

55091244403: DescriptionGeneral Purpose Inductor, 120uH, 2%, 1 Element, Ferrite-Core, SMD, 1812, CHIP; CategoryPassive components inductor; File Size1MB，10 Pages; ManufacturerSUMIDA; Websitehttp://www.sumida.com/; Environmental Compliance

Download Datasheet Parametric View All

55091244403 Overview

General Purpose Inductor, 120uH, 2%, 1 Element, Ferrite-Core, SMD, 1812, CHIP

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SUMIDA
package instruction	CHIP
Reach Compliance Code	unknown
uppercase and lowercase codes	1812
structure	Rectangular
core material	Ferrite
DC Resistance	5.3 Ω
Nominal inductance(L)	120 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e4
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	3.1 mm
Package length	4.45 mm
Package form	SMT
Package width	3 mm
method of packing	TR, 13 Inch
Minimum quality factor (at nominal inductance)	16
Maximum rated current	0.18 A
self resonant frequency	3.75 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Silver/Palladium/Platinum (Ag/Pd/Pt)
Terminal location	DUAL ENDED
Terminal shape	ONE SURFACE
Test frequency	0.796 MHz
Tolerance	2%

SMT Chipinduktivitäten

SMT Chip Inductors

compliant

Baugröße /

Size

1812 (4532)

Serie /

Series

5309, 5509

20191001

- 56 -
