DLA 13017
www.vishay.com
Vishay
Wet Tantalum Capacitors, Extended Capacitance, Tantalum Case
with Glass-to-Tantalum Hermetic Seal for -55 °C to +125 °C
FEATURES
• Enhanced performance, high reliability design
• Terminations: Axial, standard tin/lead (SnPb)
plated
• The 13017 tantalum-case electrolytic capacitors
provide all the advantages of Vishay’s SuperTan
®
series
devices, while offering improved reverse voltage and
vibration capabilities
• Increased thermal shock capability of 300 cycles
• Mounting: Through-hole
PERFORMANCE CHARACTERISTICS
Refer to: Typical Performance Characteristics
Operating Temperature:
-55 °C to +85 °C
(To +125 °C with voltage derating)
Capacitance Tolerance:
± 10 %, ± 20 % standard
DC Leakage Current (DCL Max.):
At +25 °C and above,
leakage current shall not exceed the values listed in the
Standard Ratings table.
• Designed for the avionics and aerospace applications
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and/or parts that are non-RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information/tables in this datasheet for details.
ORDERING INFORMATION
13017
DLA DRAWING NUMBER
-01
DASH NUMBER
K
CAPACITANCE TOLERANCE
K = ± 10 %
M = ± 20 %
S = Sleeved
U = Unsleeved
S
DLA LAND AND MARITIME
COLUMBUS, OHIO
Drawing no.
13017
DIMENSIONS
in inches [millimeters]
Terminal Welded
to Case
0.250 (6.35)
Max.
0.025 ± 0.002
(0.64 ± 0.05)
0.094 (2.38)
Max.
E
L
1
E
“D” Dia.
Terminal Location
within 0.031 of Center
CASE CODE
T1
T2
T3
T4
D
± 0.016 [0.41]
0.188 [4.78]
0.281 [7.14]
0.375 [9.52]
0.375 [9.52]
D MAX. INSULATED
(DIA.)
0.219 [5.56]
0.312 [7.92]
0.406 [10.31]
0.406 [10.31]
L
1
UNINSULATED
+0.031 [0.79]
-0.016 [0.41]
0.453
[11.51]
0.641
[16.28]
0.766
[19.46]
1.062 [26.97]
E
± 0.250 [6.35] MAX.
1.500 [38.10]
2.250 [57.15]
2.250 [57.15]
2.250 [57.15]
Note
• Insulation sleeving will lap over the ends of the capacitor body.
Revision: 16-Sep-13
Document Number: 40167
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
DLA 13017
www.vishay.com
Vishay
STANDARD RATINGS
CAPACITANCE CASE
(μF)
CODE
MAX. ESR MAX. IMP.
AT +25 °C AT -55 °C
120 Hz
120 Hz
()
()
MAX. DCL
(μA) AT
+25 °C
+85 °C
AND
+125 °C
MAX. CAPACITANCE
CHANGE (%)
-55 °C
+85 °C
+125 °C
AC
RIPPLE
+85 °C
40 kHz
(mA
RMS
)
1250
PART NUMBER
120
560
1200
1800
100
470
1000
1500
68
220
470
680
47
150
390
560
33
110
330
470
15
68
150
220
10
47
82
100
150
T1
T2
T3
T4
T1
T2
T3
T4
T1
T2
T3
T4
T1
T2
T3
T4
T1
T2
T3
T4
T1
T2
T3
T4
T1
T2
T3
T3
T4
13017-01(1)(2)
13017-02(1)(2)
13017-03(1)(2)
13017-04(1)(2)
13017-05(1)(2)
13017-06(1)(2)
13017-07(1)(2)
13017-08(1)(2)
13017-09(1)(2)
13017-10(1)(2)
13017-11(1)(2)
13017-12(1)(2)
13017-13(1)(2)
13017-14(1)(2)
13017-15(1)(2)
13017-16(1)(2)
13017-17(1)(2)
13017-18(1)(2)
13017-19(1)(2)
13017-20(1)(2)
13017-21(1)(2)
13017-22(1)(2)
13017-23(1)(2)
13017-24(1)(2)
13017-25(1)(2)
13017-26(1)(2)
13017-27(1)(2)
13017-28(1)(2)
13017-29(1)(2)
25 V
DC
AT 85 °C, 15 V
DC
AT 125 °C
1.30
25
1
5
-42
8
Preliminary value. Contact Marketing.
Preliminary value. Contact Marketing.
Preliminary value. Contact Marketing.
30 V
DC
AT 85 °C, 20 V
DC
AT 125 °C
1.30
25
1
5
-38
8
Preliminary value. Contact Marketing.
Preliminary value. Contact Marketing.
Preliminary value. Contact Marketing.
50 V
DC
AT 85 °C, 30 V
DC
AT 125 °C
1.50
35
1
5
-25
8
0.90
17.5
2
10
-50
8
0.75
10
3
25
-45
8
0.70
8
5
40
-58
10
60 V
DC
AT 85 °C, 40 V
DC
AT 125 °C
2.00
44
1
5
-25
8
1.10
20
2
10
-40
8
0.90
15
3
25
-45
8
0.80
10
5
40
-58
8
75 V
DC
AT 85 °C, 50 V
DC
AT 125 °C
2.50
66
1
5
-25
5
1.30
24
2
10
-35
6
1.00
12
3
30
-45
6
0.90
12
5
50
-50
6
100 V
DC
AT 85 °C, 65 V
DC
AT 125 °C
3.50
125
1
5
-18
3
2.10
37
2
10
-30
4
1.60
22
3
25
-35
6
1.20
15
5
50
-40
6
125 V
DC
AT 85 °C, 85 V
DC
AT 125 °C
5.50
175
1
5
-15
3
2.30
47
2
10
-25
5
1.80
40
3
25
-35
5
1.80
35
3
25
-35
5
1.60
20
5
50
-35
6
12
12
1200
15
15
15
20
12
15
15
15
9
10
10
10
10
12
12
12
10
12
12
12
12
1050
1800
2100
2700
1050
1800
2100
2700
1050
1650
2100
2700
1050
1650
2100
2700
1050
1650
1950
2100
2700
Note
• Part number definitions:
(1) Capacitance tolerance: K = 10 %, M = 20 %
(2) Case or body insulation: S = Sleeved; U = Unsleeved
RIPPLE CURRENT MULTIPLIERS VS. FREQUENCY, TEMPERATURE, AND APPLIES PEAK VOLTAGE
FREQUENCY OF
APPLIED RIPPLE
CURRENT
AMBIENT STILL
AIR TEMP. IN °C
100 %
% of
90 %
85 °C
rated
80 %
peak
70 %
voltage
66 2/3 %
120 Hz
800 Hz
1 kHz
10 kHz
40 kHz
100 kHz
55 85 105 125
55 85 105 125
55 85 105 125
55 85 105 125
55 85 105 125
55 85 105 125
0.60
0.60
0.60
0.60
0.60
0.39 -
-
0.46 -
-
0.52 0.35 -
0.58 0.44 -
0.60 0.46 0.27
0.71
0.71
0.71
0.71
0.71
0.43 -
-
0.55 -
-
0.62 0.42 -
0.69 0.52 -
0.71 0.55 0.32
0.72
0.72
0.72
0.72
0.72
0.46 -
-
0.55 -
-
0.62 0.42 -
0.70 0.52 -
0.72 0.55 0.32
0.88
0.88
0.88
0.88
0.88
0.55 -
-
0.67 -
-
0.76 0.52 -
0.85 0.64 -
0.88 0.68 0.40
1.0
1.0
1.0
1.0
1.0
0.63 -
-
0.77 -
-
0.87 0.59 -
0.97 0.73 -
1.0 0.77 0.45
1.1
1.1
1.1
1.1
1.1
0.69 -
-
0.85 -
-
0.96 0.65 -
1.07 0.80 -
1.1 0.85 0.50
Revision: 16-Sep-13
Document Number: 40167
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
DLA 13017
www.vishay.com
TYPICAL PERFORMANCE CHARACTERISTICS OF DLA 13017 CAPACITORS
ELECTRICAL CHARACTERISTICS
ITEM
Operating Temperature Range
Capacitor Tolerance
Capacitor Change by Temperature
ESR
Impedance
DCL (Leakage Current)
AC Ripply Current
Reverse Voltage
PERFORMANCE CHARACTERISTICS
- 55 °C to + 85 °C (to + 125 °C with voltage derating)
± 20 %, ± 10 % at 120 Hz, at + 25 °C
Limit per Standard Ratings table
Limit per Standard Ratings table, at + 25 °C, 120 Hz
Limit per Standard Ratings table, at - 55 °C, 120 Hz
Limit per Standard Ratings table
Limit per Standard Ratings table, at + 85 °C and 40 kHz
Reverse voltage shall be in accordance with MIL-PRF-39006, paragraphs 3.23 and 4.8.19, except DC
potential will be maximum of 1.5 V.
Surge voltage shall be in accordance with MIL-PRF-39006 and DLA13017.
The DC rated surge voltage is the maximum voltage to which the capacitors can be subjected under
any conditions including transients and peak ripple at the highest line voltage.
The DC surge voltage is 115 % of rated DC voltage.
Vishay
Surge Voltage
PERFORMANCE CHARACTERISTICS
ITEM
PERFORMANCE CHARACTERISTICS
Capacitors shall be capable of withstanding a 2000 h life test at a temperature + 85 °C at rated
voltage, or a 1000 h life test at 125 °C test at derated voltage.
After the test, the capacitors shall meet the following requirements:
Life Testing
a) DC leakage at 85 °C and 125 °C shall not exceed 125 % of the specified value
b) DC leakage at 25 °C shall not exceed the specified value
c) Capacitance shall be within + 10 %, - 20 % of initial value
d) ESR shall not exceed 200 % of the specified value
ENVIRONMENTAL CHARACTERISTICS
ITEM
Seal
Moisture Resistance
Barometric Pressure
(Reduced)
CONDITION
MIL-PRF-39006
MIL-PRF-39006
MIL-STD-202, method 105, condition E
COMMENTS
When the capacitors are tested as specified in MIL-PRF-39006,
there shall be no evidence of leakage.
Moisture resistance shall be in accordance with MIL-PRF-39006.
Number of cycles: 10 continuous cycles
Altitude 150 000 feet
Revision: 16-Sep-13
Document Number: 40167
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
DLA 13017
www.vishay.com
Vishay
MECHANICAL CHARACTERISTICS
ITEM
Shock (Specified Pulse)
Vibration, High Frequency
Random Vibration
Thermal Shock
Solderability
Terminal Strength
Resistance to Solder Heat
CONDITION
MIL-STD-202, method 213, condition I
(100
g)
MIL-STD-202, method 204, condition E
(50
g
peak)
MIL-STD-202, method 214, condition II-G
(overall RMS 27.78
g)
MIL-STD-202, method 107, condition A
MIL-STD-202, method 208,
ANSI/J-STD-002, test A
MIL-STD-202, method 211
MIL-STD-202, method 210, condition C
COMMENTS
The capacitors shall meet the requirements of MIL-PRF-39006.
The capacitors shall meet the requirements of MIL-PRF-39006.
The capacitors shall meet the requirements of MIL-PRF-39006.
Thermal shock shall be in accordance with MIL-PRF-39006 when
tested for 300 cycles.
Solderability shall be in accordance with MIL-PRF-39006.
Terminal strength shall be in accordance with MIL-PRF-39006.
The capacitors shall meet the requirements of MIL-PRF-39006.
Terminals shall be as specified in MIL-STD-1276. The length and
diameter of the terminals shall be as specified in Dimensions table.
All terminals shall be permanently secured internally and
externally, as applicable. All external joints shall be welded.
Marking of capacitors conforms to method I of MIL-STD-1285 and
include capacitance (in μF), capacitance tolerance letter, rated
voltage, date code, lot symbol and Vishay trademark.
Terminals
MIL-STD-1276
Marking
MIL-STD-1285
SELECTOR GUIDES
Tantalum Selector Guide
Parameter Comparison Guide
www.vishay.com/doc?49054
www.vishay.com/doc?42088
Revision: 16-Sep-13
Document Number: 40167
4
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Legal Disclaimer Notice
www.vishay.com
Vishay
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of typical
requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements
about the suitability of products for a particular application. It is the customer’s responsibility to validate that a particular
product with the properties described in the product specification is suitable for use in a particular application. Parameters
provided in datasheets and/or specifications may vary in different applications and performance may vary over time. All
operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk. Please
contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by
any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
Material Category Policy
Vishay Intertechnology, Inc. hereby certifies that all its products that are identified as RoHS-Compliant fulfill the
definitions and restrictions defined under Directive 2011/65/EU of The European Parliament and of the Council
of June 8, 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment
(EEE) - recast, unless otherwise specified as non-compliant.
Please note that some Vishay documentation may still make reference to RoHS Directive 2002/95/EC. We confirm that
all the products identified as being compliant to Directive 2002/95/EC conform to Directive 2011/65/EU.
Vishay Intertechnology, Inc. hereby certifies that all its products that are identified as Halogen-Free follow Halogen-Free
requirements as per JEDEC JS709A standards. Please note that some Vishay documentation may still make reference
to the IEC 61249-2-21 definition. We confirm that all the products identified as being compliant to IEC 61249-2-21
conform to JEDEC JS709A standards.
Revision: 02-Oct-12
1
Document Number: 91000
京公网安备 11010802033920号
EEWORLD
