designed for digitizing high frequency, wide dynamic range
signals with input frequencies up to 380MHz. The input
range of the ADC can be optimized with the PGA front end.
The LTC2201 is perfect for demanding applications, with
AC performance that includes 81.6dB SNR and 100dB
spurious free dynamic range (SFDR). Maximum DC specs
include ±5LSB INL, ±1LSB DNL (no missing codes).
A separate output power supply allows the CMOS output
swing to range from 0.5V to 3.6V.
A single-ended CLK input controls converter operation. An
optional clock duty cycle stabilizer allows high performance
at full speed with a wide range of clock duty cycles.
L,
LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear
Technology Corporation. All other trademarks are the property of their respective owners.
n
Sample Rate: 20Msps
81.6dB SNR and 100dB SFDR (2.5V Range)
90dB SFDR at 70MHz (1.667V
P-P
Input Range)
PGA Front End (2.5V
P-P
or 1.667V
P-P
Input Range)
380MHz Full Power Bandwidth S/H
Optional Internal Dither
Optional Data Output Randomizer
Single 3.3V Supply
Power Dissipation: 211mW
Clock Duty Cycle Stabilizer
Out-of-Range Indicator
Pin Compatible Family
25Msps: LTC2203 (16-Bit)
10Msps: LTC2202 (16-Bit)
48-Pin (7mm
×
7mm) QFN Package
APPLICATIONS
n
n
n
n
n
n
Telecommunications
Receivers
Cellular Base Stations
Spectrum Analysis
Imaging Systems
ATE
TYPICAL APPLICATION
3.3V
SENSE
V
CM
2.2μF
A
IN +
ANALOG
INPUT
A
IN –
1.25V
COMMON MODE
BIAS VOLTAGE
INTERNAL ADC
REFERENCE
GENERATOR
OV
DD
0.5V TO 3.6V
1μF
Integral Nonlinearity (INL)
vs Output Code
2.0
1.5
1.0
+
S/H
AMP
–
16-BIT
PIPELINED
ADC CORE
CORRECTION
LOGIC AND
SHIFT REGISTER
OUTPUT
DRIVERS
OF
CLKOUT+
CLKOUT–
D15
CMOS
OUTPUTS
INL ERROR (LSB)
3.3V
1μF
0.5
0.0
–0.5
–1.0
–1.5
–2.0
0
16384
32768
CODE
49152
65536
2201 TA02
D0
OGND
CLOCK/DUTY
CYCLE
CONTROL
V
DD
GND
CLK
PGA
SHDN
DITH
MODE
OE
RAND
1μF
1μF
2201 TA01
ADC CONTROL INPUTS
2201f
1
LTC2201
ABSOLUTE MAXIMUM RATINGS
OV
DD
= V
DD
(Notes 1 and 2)
TOP VIEW
PIN CONFIGURATION
48 GND
47 PGA
46 RAND
45 MODE
44
OE
43 OF
42 D15
41 D14
40 D13
39 D12
38 OGND
37 OV
DD
SENSE 1
V
CM
2
V
DD
3
V
DD
4
GND 5
A
IN+
6
A
IN–
7
GND 8
GND 9
CLK 10
GND 11
V
DD
12
49
36 OV
DD
35 D11
34 D10
33 D9
32 D8
31 OGND
30 CLKOUT
+
29 CLKOUT
–
28 D7
27 D6
26 D5
25 OV
DD
UK PACKAGE
48-LEAD (7mm 7mm) PLASTIC QFN
EXPOSED PAD IS GND (PIN 49)
MUST BE SOLDERED TO PCB BOARD
T
JMAX
= 150°C,
θ
JA
= 29°C/W
Supply Voltage (V
DD
) .................................. –0.3V to 4V
Digital Output Supply Voltage (OV
DD
) ......... –0.3V to 4V
Digital Output Ground Voltage (OGND) ........–0.3V to 1V
Analog Input Voltage (Note 3) .....–0.3V to (V
DD
+ 0.3V)
Digital Input Voltage ....................–0.3V to (V
DD
+ 0.3V)
Digital Output Voltage............... –0.3V to (OV
DD
+ 0.3V)
Power Dissipation ............................................2000mW
Operating Temperature Range
LTC2201C ............................................... 0°C to 70°C
LTC2201I ............................................ –40°C to 85°C
Storage Temperature Range ................. –65°C to 150°C
ORDER INFORMATION
LEAD FREE FINISH
LTC2201CUK#PBF
LTC2201IUK#PBF
TAPE AND REEL
LTC2201CUK#TRPBF
LTC2201IUK#TRPBF
PART MARKING*
LTC2201UK
LTC2201UK
PACKAGE DESCRIPTION
48-Lead (7mm
×
7mm) Plastic QFN
48-Lead (7mm
×
7mm) Plastic QFN
TEMPERATURE RANGE
0°C to 70°C
–40°C to 85°C
Consult LTC Marketing for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
For more information on lead free part marking, go to:
http://www.linear.com/leadfree/
For more information on tape and reel specifications, go to:
http://www.linear.com/tapeandreel/
V
DD
13
V
DD
14
GND 15
SHDN 16
DITH 17
D0 18
D1 19
D2 20
D3 21
D4 22
OGND 23
OV
DD
24
2201f
2
LTC2201
temperature range, otherwise specifications are at T
A
= 25°C. (Note 4)
PARAMETER
Resolution (No missing codes)
Integral Linearity Error
Differential Linearity Error
Offset Error
Offset Drift
Gain Error
Full-Scale Drift
Transition Noise
External Reference
Internal Reference
External Reference
External Reference (2.5V Range, PGA = 0)
l
CONVERTER CHARACTERISTICS
The
l
denotes the specifications which apply over the full operating
CONDITIONS
Differential Analog Input (Note 5)
Differential Analog Input
(Note 6)
l
l
l
MIN
16
TYP
±1.5
±0.3
±2
±10
±0.2
±30
±15
1.92
MAX
±5
±1
±10
±1.5
UNITS
LSB
LSB
mV
μV/°C
%FS
ppm/°C
ppm/°C
LSB
RMS
The
l
denotes the specifications which apply over the full operating temperature range, otherwise
specifications are at T
A
= 25°C. (Note 4)
SYMBOL
V
IN
V
IN, CM
I
IN
I
SENSE
I
MODE
I
OE
C
IN
t
AP
t
JITTER
CMRR
BW-3dB
PARAMETER
Analog Input Range (A
IN+
–
A
IN–
)
Analog Input Common Mode
Analog Input Leakage Current
SENSE Input Leakage Current
MODE Pin Pull-Down Current to GND
OE
Pin Pull-Down Current to GND
Analog Input Capacitance
Sample-and-Hold
Acquisition Delay Time
Sample-and-Hold
Acquisition Delay Time Jitter
Analog Input
Common Mode Rejection Ratio
Full Power Bandwidth
1V < (A
IN+
= A
IN–
) <1.5V
R
S
< 20Ω
Sample Mode CLK = 0
Hold Mode CLK = 0
CONDITIONS
3.135V ≤ V
DD
≤ 3.465V
Differential Input (Note 7)
0V ≤ A
IN+
,
A
IN–
≤ V
DD
(Note 9)
0V ≤ SENSE ≤ V
DD
(Note 10)
l
l
l
ANALOG INPUT
MIN
1
–1
–3
TYP
1.667 or 2.5
1.25
MAX
1.5
1
3
UNITS
V
P-P
V
μA
μA
μA
μA
pF
pF
ns
fs
RMS
dB
MHz
10
10
10.5
1.4
0.9
200
80
380
DYNAMIC ACCURACY
SYMBOL
SNR
PARAMETER
Signal-to-Noise Ratio
The
l
denotes the specifications which apply over the full operating temperature range,
otherwise specifications are at T
A
= 25°C. A
IN
= –1dBFS. (Note 4)
CONDITIONS
1MHz Input (2.25V Range, PGA = 0)
1MHz Input (1.667V Range, PGA = 1)
5MHz Input (2.5V Range, PGA = 0)
5MHz Input (1.667V Range, PGA = 1)
12.5MHz Input (2.5V Range, PGA = 0)
12.5MHz Input (1.667V Range, PGA = 1)
30MHz Input (2.5V Range, PGA = 0)
30MHz Input (1.667V Range, PGA = 1)
70MHz Input (2.5V Range, PGA = 0)
70MHz Input (1.667V Range, PGA =1 )
l
MIN
TYP
81.6
79.4
MAX
UNITS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
80
81.6
79.4
81.4
79.3
80.8
78.9
78.3
77.2
2201f
3
LTC2201
DYNAMIC ACCURACY
SYMBOL
SFDR
PARAMETER
Spurious Free
Dynamic Range
2
nd
or 3
rd
Harmonic
The
l
denotes the specifications which apply over the full operating temperature range,
otherwise specifications are at T
A
= 25°C. A
IN
= –1dBFS. (Note 4)
CONDITIONS
1MHz Input (2.5V Range, PGA = 0)
1MHz Input (1.667V Range, PGA = 1)
5MHz Input (2.5V Range, PGA = 0)
5MHz Input (1.667V Range, PGA = 1)
12.5MHz Input (2.5V Range, PGA = 0)
12.5MHz Input (1.667V Range, PGA = 1)
30MHz Input (2.5V Range, PGA = 0)
30MHz Input (1.667V Range, PGA = 1)
70MHz Input (2.5V Range, PGA = 0)
70MHz Input (1.667V Range, PGA = 1)
l
MIN
TYP
100
100
MAX
UNITS
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
85
100
100
95
100
90
95
85
90
100
100
SFDR
Spurious Free
Dynamic Range
4th Harmonic or Higher
1MHz Input (2.5V Range, PGA = 0)
1MHz Input (1.667V Range, PGA = 1)
5MHz Input (2.5V Range, PGA = 0)
5MHz Input (1.667V Range, PGA = 1)
12.5MHz Input (2.5V Range, PGA = 0)
12.5MHz Input (1.667V Range, PGA = 1)
30MHz Input (2.5V Range, PGA = 0)
30MHz Input (1.667V Range, PGA = 1)
70MHz Input (2.5V Range, PGA = 0)
70MHz Input (1.667V Range, PGA = 1)
l
90
100
100
100
100
100
100
90
90
81.5
79.3
S/(N+D)
Signal-to-Noise
Plus Distortion Ratio
1MHz Input (2.5V Range, PGA = 0)
1MHz Input (1.667V Range, PGA = 1)
5MHz Input (2.5V Range, PGA = 0)
5MHz Input (1.667V Range, PGA = 1)
12.5MHz Input (2.5V Range, PGA = 0)
12.5MHz Input (1.667V Range, PGA = 1)
30MHz Input (2.5V Range, PGA = 0)
30MHz Input (1.667V Range, PGA = 1)
70MHz Input (2.5V Range, PGA = 0)
70MHz Input (1.667V Range, PGA = 1)
l
79.7
81.5
79.3
81.3
79.2
80.6
78.6
78.1
77
105
105
105
105
105
105
105
105
100
100
SFDR
Spurious Free
Dynamic Range
at –25dBFS
Dither “OFF”
1MHz Input (2.5V Range, PGA = 0)
1MHz Input (1.667V Range, PGA = 1)
5MHz Input (2.5V Range, PGA = 0)
5MHz Input (1.667V Range, PGA = 1)
12.5MHz Input (2.5V Range, PGA = 0)
12.5MHz Input (1.667V Range, PGA = 1)
30MHz Input (2.5V Range, PGA = 0)
30MHz Input (1.667V Range, PGA = 1)
70MHz Input (2.5V Range, PGA = 0)
70MHz Input (1.667V Range, PGA = 1)
2201f
4
LTC2201
DYNAMIC ACCURACY
SYMBOL
SFDR
PARAMETER
Spurious Free
Dynamic Range
at –25dBFS
Dither “ON”
The
l
denotes the specifications which apply over the full operating temperature range,
otherwise specifications are at T
A
= 25°C. A
IN
= –1dBFS. (Note 4)
CONDITIONS
1MHz Input (2.5V Range, PGA = 0)
1MHz Input (1.667V Range, PGA = 1)
5MHz Input (2.5V Range, PGA = 0)
5MHz Input (1.667V Range, PGA = 1)
12.5MHz Input (2.5V Range, PGA = 0)
12.5MHz Input (1.667V Range, PGA = 1)
30MHz Input (2.5V Range, PGA = 0)
30MHz Input (1.667V Range, PGA = 1)
70MHz Input (2.5V Range, PGA = 0)
70MHz Input (1.667V Range, PGA = 1)
MIN
TYP
115
115
115
115
115
115
115
115
110
110
MAX
UNITS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
dBFS
The
l
denotes the specifications which apply over
the full operating temperature range, otherwise specifications are at T
A
= 25°C. (Note 4)
PARAMETER
V
CM
Output Voltage
V
CM
Output Tempco
V
CM
Line Regulation
V
CM
Output Resistance
CONDITIONS
I
OUT
= 0
I
OUT
= 0
3.135V ≤ V
DD
≤ 3.465V
1mA ≤ | I
OUT
| ≤ 1mA
MIN
1.15
TYP
1.25
±40
1
2
MAX
1.35
UNITS
V
ppm/°C
COMMON MODE BIAS CHARACTERISTICS
mV/ V
Ω
DIGITAL INPUTS AND DIGITAL OUTPUTS
SYMBOL
V
IH
V
IL
I
IN
C
IN
LOGIC OUTPUTS
OV
DD
= 3.3V
V
OH
V
OL
I
SOURCE
I
SINK
OV
DD
= 2.5V
V
OH
V
OL
OV
DD
= 1.8V
V
OH
V
OL
High Level Output Voltage
Low Level Output Voltage
V
DD
= 3.3V
V
DD
= 3.3V
High Level Output Voltage
Low Level Output Voltage
V
DD
= 3.3V
V
DD
= 3.3V
High Level Output Voltage
Low Level Output Voltage
Output Source Current
Output Sink Current
V
DD
= 3.3V
V
DD
= 3.3V
V
OUT
= 0V
V
OUT
= 3.3V
PARAMETER
High Level Input Voltage
Low Level Input Voltage
Digital Input Current
Digital Input Capacitance
CONDITIONS
V
DD
= 3.3V
V
DD
= 3.3V
V
IN
= 0V to V
DD
(Note 7)
LOGIC INPUTS (CLK,
OE,
DITH, PGA, SHDN, RAND)
The
l
denotes the specifications which apply over the
full operating temperature range, otherwise specifications are at T
For 48V5A lamp, step-down type. Input more than 50 volts, the potentiometer adjusts the maximum output current to 5A. Collect 0-10V signal to automatically adjust the current strength, such as: 0V no ...
Although there are many ways to repair the remote control, they all have disadvantages. Wearing copper wire will wear out the conductive line, sticking aluminum foil is easy to fall off, sticking old ...
Hello everyone: I customized a system under wince5.0, and after compiling, the following 4 errors appeared: [color=#FF0000]Error: Unknown memory type found 'CEVIEW.exe'[/color] CEVIEW.exe D:\WINCE500\...
I have posted a series of posts on the power supply section titled "Rectifier Talk". So far, six posts have been posted, mainly discussing the peak, average and effective values of the current in the ...
Tesla and BYD, vying for dominance in the global electric vehicle market, are reportedly considering adopting Samsung's AMOLED (active-matrix organic light-emitting diode) technology for their next...[Details]
introduction
With the development of digital and network technologies, broadcasting technology has become increasingly diversified, with the most significant trend being the transition from an...[Details]
New energy pure electric vehicles generally accelerate faster than comparable fuel-powered vehicles, both from a standing start and while accelerating. Many believe this is simply due to the motor'...[Details]
Robotics
has become
LiDAR
's "second growth curve."
While LiDAR was still battling with its "pure vision" rivals in the automotive field, another field ignited the demand f...[Details]
Core point: The automotive industry chain and the humanoid robot industry have collaborative advantages in hardware, software, and scenarios. Upstream and downstream companies in the automotive ind...[Details]
The all-new MG4 was recently officially announced on the Ministry of Industry and Information Technology's (MIIT) new vehicle announcement. The all-new MG4's semi-solid-state battery version addres...[Details]
introduction
The concept of the smart home is gradually developing and gaining market acceptance. We believe its ultimate form lies in the interconnection of all home appliances through open i...[Details]
Pure electric vehicles, structurally speaking, have components such as a power battery. In addition to the power battery, a small battery also powers some low-voltage electrical components and even...[Details]
With the advent of the electric car era, the number of pure electric vehicles has increased significantly, but many car owners do not know how to properly maintain pure electric vehicles. In additi...[Details]
Keysight Technologies is combining its electromagnetic simulator with Synopsys' AI-driven RF design migration flow to create an integrated design flow for migrating from TSMC's N6RF+ process techno...[Details]
Industrial computers with GPUs leverage powerful parallel processing to build deep learning models to analyze and respond to optical inputs. The systems develop an understanding of visual data to i...[Details]
Plessey Semiconductors has been acquired by Haylo Labs, which was established in March last year with a $100 million, five-year loan from Chinese technology company Goertek.
Haylo Labs w...[Details]
A human-machine interface (HMI) refers to the platform used by people to operate a PLC. This platform provides an interface between programs and humans, serving as a medium for information transmis...[Details]
The MCX E series is the most reliability- and safety-focused series in NXP's extensive MCX product portfolio.
With the launch of this series, NXP has further enriched its 5V-compatible MCU pr...[Details]
On August 21st, BYD announced the launch of its next-generation "Little White Pile" product, the "Lingchong"
charging
pile
, which is now available for general sale. This charging pile feat...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
