023201.6M-ND: DescriptionAxial Lead and Cartridge Fuses - Designed to METI Standard; File Size122KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet View All

023201.6M-ND Overview

Axial Lead and Cartridge Fuses - Designed to METI Standard

Preview

Download Datasheet

View All

Axial Lead and Cartridge Fuses

Designed to METI Standard

RoHS

5 x 20 mm

Medium-Acting Fuse 232 Series

• Designed to Japanese Standard JIS C6575.

• Available in Cartridge, Axial and Radial Lead Format.

• Available in ratings of 1A to 10A.

•

RoHS compliant and Lead-Free version available, add XP suffix to

standard catalog number

ELECTRICAL CHARACTERISTICS:

% of Ampere

Rating

130%

160%

200%

1000%

Opening

Time

1 hour,

Minimum

1 hour,

Maximum

2 minutes,

Maximum

.01 sec,

Minimum

INTERRUPTING RATING:

1A-5A 10,000A @ 125VAC, 0.7-0.8 power factor

6.3A-10A 300A @ 125VAC, 0.7-0.8 power factor

100 amperes at 250 VAC, 0.7-0.8 power factor

ORDERING INFORMATION:

RoHS compliant and Lead-Free version available, add XP suffix to

standard catalog number

Catalog

Number

0232

001.

0232

1.25

0232

01.6

0232

002.

0232

02.5

0232

003.

0232

3.15

0232

004.

0232

005.

0232

06.3

0232

008.

0232

010.

Ampere

Rating

1.25

1.6

2.5

3.15

6.3

Voltage

Rating*

125/250

Nominal

Resistance

Cold Ohms

0.0957

0.0707

0.0567

0.0385

0.0297

0.0257

0.0235

0.018

0.0145

0.0105

.0076

.0061

Nominal

Melting I

Sec

1.41

4.22

7.14

8.47

14.25

17.65

22.55

38.75

58.25

92.85

187.5

298.5

ENVIRONMENTAL SPECIFICATIONS:

Operating temperature:

-55˚C to 125˚C

Thermal Shock:

MIL-STD-202F Method 107G, Test Condition B: (5

cycles –65°C to +125°C)

Vibration:

MIL-STD-202F Method 201A

Humidity:

MIL-STD-202F Method 103B, Test Condition A. high relative

humidity (95%) and elevated temperature (40°C) for 240 hours.

Salt Spray:

MIL-STD-202F Method 101D, Test Condition B

PHYSICAL SPECIFICATIONS:

Material:

Body: Glass

Cap: Nickel Plated Brass

Leads: Tin Plated Copper

Terminal Strength:

MIL-STD-202F Method 211A,

Test Condition A

Solderability:

Reference IEC 60127 Second Edition 2003-01 Annex A

Product Marking:

Cap 1: current and voltage rating.

Cap 2: Agency approval markings.

Packaging:

Available in Bulk (v=5, H=100, M=1000 pcs/pkg) or on

Tape/Reel (MRET1=1000 pcs/reel).

To order 125V rating, add part number suffix X125

422

w w w. l i t t e l f u s e . c o m
