Part Number:
Status:
Overview:
Description:
0472660201
Active
high_definition_multimedia_interface_hdmi
0.50mm (.020") Pitch HDMI* Receptacle, Right Angle, Black, Through Hole Shell Tab
Length 1.90mm (.075"), Gold (Au) Flash, Matt Tin Plated Shell, with Flange, Tray
Package, Lead Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-47152-001 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Series
General
Product Family
Series
Application
Comments
Component Type
Overview
Product Name
Type
I/O Connectors
47266
Wire-to-Board
With Upper Flange
Receptacle
high_definition_multimedia_interface_hdmi
HDMI
N/A
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Boot Color
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Panel Mount
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Ports
Temperature Range - Operating
Termination Interface: Style
Waterproof / Dustproof
Wire Size AWG
N/A
19
19
Black
Male
Yes
Yes
Copper Alloy
Gold
Tin-Bismuth
High Temperature Thermoplastic
2
Right Angle
No
Yes
Tray
Yes
0.020 In
0.50 mm
0.020 In
0.50 mm
2
0.05
40
1
Yes
Yes
1
-20°C to +85°C
Surface Mount
No
N/A
Search Parts in this Series
47266Series
Mates With
88768 HDMI cable assembly, 88764 HDMI
Adapter, 88767 HDMI Adapter
Electrical
Current - Maximum per Contact
Shield Type
Shielded
Voltage - Maximum
0.5A
Full Shield
Yes
40V DC
Material Info
Reference - Drawing Numbers
Packaging Specification
PK-47266-005
Product Specification
PS-47152-001
Sales Drawing
SD-47266-001
