UBMINIATURE
S
UBMINIATURE
F
USES
WICKMANN
TE5
®
/ No. 395
125V,
UL 248-14, 125V, F
Time-Current Characteristic
Quick Acting (F)
Specifications
Packaging
000: Tape/Ammopack (1400 pcs.)
044: Short Leads - Bulk (1400 pcs.)
Standard
UL 248-14
CSA C22.2 No. 248.14
Materials
Brown Thermoplastic
Polyamide PA 6.6, UL 94V0
Round Pins: Copper alloy, tin plated
Base/Cap:
Approvals
UL Listed: File No. E 67006
cUL Listed: File No. E 67006
MITI: File No. 32-1693
Temperature
Operating Temperature
-40ºC to +85ºC (consider de-rating)
Features
Dimensions (mm)
8,5
max. 8
Climatic Category
-25ºC/+70ºC/21 days (IEC 60068-2-1..3)
max. 4
Reduced PCB space requirements
Direct solderable or plug-in versions
Internationally approved
Low internal resistance
Shocksafe casing
Vibration resistant
Stock Conditions
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days - 95%
Vibration Resistance
24 cycles at 15 min. each (IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
WebLinks
0,5 min
L
∅
0,6
1,5
Data Sheet
www.wickmann.com/products/395.pdf
Lead Pull Strength
10N (IEC 60068-2-21)
Approval Certificates
www.wickmann.com/approvals
1 +0,1
5,08
Time-Current Curve
Page 59
www.wickmann.com/itcurves
Solderability
260ºC,
≤
3 sec. (Wave)
350ºC,
≤
1 sec. (Hand)
Holes in PCB
Packaging
Page 118
www.wickmann.com/pack
Soldering Heat Resistance
260ºC, 10 sec. (IEC 60068-2-20)
Long Leads (L=18.8mm)
Short Leads (L=4.3mm)
Marking
, F, Current Rating, Approvals
FaxBack Document # 302
Limits for Pre-arcing Time
Rated Current
50mA ... 6.30A
Unit Weight
0.60g (approx.)
< 5s
2.0 x I
Rated
2.0 x I
Rated
< 60s
50mA
63mA
80mA
100mA
125mA
160mA
200mA
250mA
315mA
400mA
500mA
630mA
800mA
1.00A
1.25A
1.60A
2.00A
2.50A
3.15A
4.00A
5.00A
6.30A
0050
0063
0080
0100
0125
0160
0200
0250
0315
0400
0500
0630
0800
1100
1125
1160
1200
1250
1315
1400
1500
1630
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
125V
100A / 125VAC
50-60Hz
cos
ϕ
= 1.0
1600
1300
1200
1100
1350
1000
950
900
800
230
220
210
200
190
180
170
160
150
140
130
120
115
85
85
100
110
160
150
210
225
255
95
110
135
160
190
225
275
450
375
445
520
600
850
0.0001
0.00013
0.0002
0.0013
0.0019
0.0037
0.0075
0.013
0.026
0.015
0.022
0.038
0.068
0.1
0.2
0.39
0.53
1.1
1.9
3.2
6.1
9.7
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Order
Information
000801
Qty.
Order-
Number
Series
395
Amp Code
Packaging
WebSite:
www.wickmann.com
FaxBack: +1 (404) 699-6176
• Europe
Tel: +49 (2302) 662-107
• Americas
Tel: +1 (404) 699-7820
• Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com
E-mail: service@wickmannusa.com E-mail: sales@wickmann.com.hk
MITI
cUL
UL
Permissible continuous operating current is
≤
70% at ambient temperature of 23ºC (73.4ºF).
Rated
Amp
Voltage
Breaking
Voltage Drop Power Dissipation Melting Integral
1.0 x I
Rated
10 x I
Rated
Current
Code
Rating
Capacity
1.0 x I
Rated
max. (mV)
max. (mW)
max. (A
2
s)
Approvals
•
•
•
•
•
•
•
•
