www.hamlin.com
59165 Moulded Switch Features and Benefits
Features
•
2 part magnetically operated
proximity sensor
Gull Wing, leaded and staple form
•
options
•
Tape and reel option (consult Hamlin)
•
Moulded stand-off to allow board
washing
•
Customer defined sensitivity
•
Solder reflow capable
Benefits
•
Suitable for pick and place
•
No standby power requirement
•
Operates through non-ferrous
materials such as wood, plastic or
aluminium
•
Hermetically sealed, magnetically
operated contacts continue to
operate long after optical and other
technologies fail due to
contamination
Applications
•
Position and limit sensing
•
Security system switch
•
Door switch
DIMENSIONS (in) mm
Double click on tag for Recommended Land Pattern
CUSTOMER OPTIONS - Switching Specifications
TABLE 1
Contact Type
Switch Type
Power
Voltage
Current
Resistance
Capacitance
Temperature
Time
Shock
Vibration
Switching
Breakdown
Switching
Carry
Contact, Initial
Insulation
Contact
Operating
Storage
Operate
Release
11ms 1⁄2 sine
50-2000 Hz
Watt - max.
Vdc - max.
Vdc - min.
A - max.
A - max.
Ω
- max.
Ω
- min.
pF - typ.
°C
°C
ms - max.
ms - max.
G - max.
G - max.
Form A
Normally
Open
1
10
200
250
0.5
0.8
0.2
10
10
0.3
-40 to +105
-65 to +105
1.0
1.0
100
30
CUSTOMER OPTIONS - Sensitivity and Termination Specification
TABLE 2
Sensitivity Options:-
Activate Distances are approximate using Hamlin 57045 actuator as illustrated
Switch AT before modification
Select Option
S
T
U
Switch
Activate Pull In Activate Pull In Activate
Pull In Distance
Type
Distance
Distance
AT
AT
AT
Range (in)dmm Range (in)dmm Range (in)dmm
D
TABLE 3
Termination Options:-
SELECT
OPTION
DESCRIPTION
A
B
C
D
Leaded
Staple Form
Gull Wing bulk packed
Gull Wing taped and reel
1 Normally Open
10-15
(.295)
7,5
15-20
(.256)
6,5
20-25
(.197)
5,0
ORDERING INFORMATION
N.B. 57045 actuator sold separately
59165
59036
Table 1
Table 2
Table 3
1
X
00
X
Series 59165
Switch Type
Sensitivity
Termination
Hamlin USA
Hamlin UK
Hamlin Germany
Hamectrol France
ISSUE No: 4 DATE: 1/5/3
Tel:
Tel:
Tel:
Tel:
+1 920 648 3000
•
Fax: +1 920 648 3001
•
Email: sales.us@hamlin.com
+44 (0)1379 649700
•
Fax: +44 (0)1379 649702
•
Email: sales.uk@hamlin.com
+49 (0) 6181 953660
•
Fax: +49 (0) 6181 9536666
•
Email: sales.de@hamlin.com
+33 (0) 1 4687 0202
•
Fax: +33 (0) 1 4686 6786
•
Email: sales.fr@hamlin.com
38
DETAILS PROVIDED ON THIS DATA SHEET ARE PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED
UPON AS BEING ACCURATE FOR ANY PARTICULAR PURPOSE.
Product performance may be affected by the application to which the
product is put. Upon request, HAMLIN will assist purchasers by
providing information specific to any particular application. HAMLIN
disclaims any and all liability whatsoever for any purchaser’s reliance
upon the information contained on this data sheet without further
consultation with authorised representatives of HAMLIN.
