General Purpose Relays
SCHRACK
Power Relay 410 63 125°C
n
n
n
n
n
n
n
1 pole 16 A, 1 NO or 1 NC contact
Switching capacity 4000 VA
Coil power 360 mW
4 kV / 8 mm coil-contact, insulation to VDE 0631 and 0700
Ambient temperature up to 125°C
Quick connect terminals for load side
WG version: Materials in accordance to IEC 60335-1
Applications
White goods appliances, oven control, electric heating, power
suppplies, air conditionning, motors, magnetic valves
F0248-BA
Approvals
V
REG.-Nr. 3725,
Z
E214025
Contact data
Technical data of approved types on request
Contact configuration
Contact set
Type of interruption
Rated voltage / max. switching voltage AC
Rated current
Limiting making capacity, max 4 s, duty factor 10%
Contact material
Rated frequency of operation with / without load
Contact ratings
Type
Contact Load
IEC
410
410
410
410
410
410
410
410
61810
63 … 001
63 … 001
63 … 001
63 … 002
63 … 005
63 … 005
63 … 005
63 … 006
NO
NO
NO
NC
NO
NO
NO
NC
16 A,
12 A,
16 A,
16 A,
16 A,
12 A,
16 A,
16 A,
250 VAC,
250 VAC,
250 VAC,
250 VAC,
250 VAC,
250 VAC,
250 VAC,
250 VAC,
cosϕ=1
cosϕ=1
cosϕ=1
cosϕ=1
cosϕ=1
cosϕ=1
cosϕ=1
cosϕ=1
1NO or 1NC
single contact
micro disconnection
250 / 400 VAC
16 A
25 A
AgCdO, AgNi
10 / 600 min
-1
Ambient
temp. [°C]
125°C
125°C
105°C
125°C
125°C
125°C
105°C
125°C
Cycles
50x10
3
200x10
3
100x10
3
50x10
3
50x10
3
200x10
3
100x10
3
50x10
3
Coil data
Rated coil voltage DC coil
Operative range to IEC 61810
Coil insulation system according UL1446
6...60 VDC
1
Class F
Coil versions, DC-coil
Coil
Rated
Operate
Release
Coil
Rated coil
code
voltage
voltage
voltage
resistance
power
VDC
VDC
VDC
Ohm
mW
054
6
3.6
0.45
100+10%
360
053
9
5.5
0.68
230+10%
352
050
12
7.3
0.9
400+10%
360
046
24
14.6
1.8
1600+10%
360
043
48
29.2
3.6
6400+10%
360
042
60
36.5
4.5
10000+10%
360
All figures are given for coil without preenergization, at ambient temperature +23°C
Other coil voltages on request
1
Datasheet Rev. IJ1
Issued 2009/10
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information only
to be used together with the
'Definitions' section in the cat-
alogue or at schrackrelays.com
in the ‘Schrack’ section.
Specifications subject to
change.
General Purpose Relays
SCHRACK
Power Relay 410 63 125°C
(Continued)
Insulation
Dielectric strength coil-contact circuit
open contact circuit
Clearance / creepage coil-contact circuit
Material group of insulation parts
Tracking index of relay base
Insulation to IEC 61810-1
Type of insulation coil-contact circuit
open contact circuit
Rated insulation voltage
Pollution degree
Rated voltage system
Overvoltage category
4000 V
rms
1000 V
rms
W
8 / 8 mm
W
IIIa
PTI 250
reinforced
micro disconnection
250 V
3
230 / 400 V
III
PCB layout / terminal assignment
Bottom view on solder pins
S0256-CA
1 NO contact
Other data
Mechanical endurance
1x10
6
cycles
Material
RoHS - Directive 2002/95/EC
compliant as per product date code 0349
Resistance to heat and fire, WG version
according EN60335, par.30
Environment
Ambient temperature range
-20...+125°C
Category of protection
RTII - flux proof
Processing
Mounting
pcb
Resistance to soldering heat
270°C / 10 s
Relay weight
24 g
Packaging unit
1050 pcs
S0256-CB
1 NC contact
S0256-CC
Dimensions
S0282-AB
Product key
Type
41063
Power Relay 410 63 125°C
Coil
Typical product key
041063
050
001
Coil code: please refer to coil versions table, preferred types in bold print
Version
001
1 NO contact (1 form A), AgCdO
002
1 NC contact (1 form B), AgCdO
005
1 NO contact (1 form A), AgNi
006
1 NC contact (1 form B), AgNi
Version
Blank
Standard version
WG
Product in accordance with IEC 60335-1 (domestic appliances)
Other types on request
Product key
0410 63 050 001
0410 63 046 001
0410 63 050 002
Version
standard
PCB terminals
quick connect term.
Cont. material
AgCdO
Cont.configuration
1 NO contact
1 NC contact
Coil
12 VDC
24 VDC
12 VDC
Part number
3-1415410-4
3-1415410-0
3-1415410-5
2
Datasheet Rev. IJ1
Issued 2009/10
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information only
to be used together with the
'Definitions' section in the cat-
alogue or at schrackrelays.com
in the ‘Schrack’ section.
Specifications subject to
change.
