SD12064R6YLA

Description
General Purpose Inductor, 4.6uH, 25%, Ferrite-Core, 4949
CategoryPassive components    inductor
File Size529KB，6 Pages
ManufacturerABC [ABC Taiwan Electronics Corp]
Environmental Compliance
Download Datasheet Parametric Compare View All

SD12064R6YLA Overview

General Purpose Inductor, 4.6uH, 25%, Ferrite-Core, 4949

SD12064R6YLA Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerABC [ABC Taiwan Electronics Corp]
package instruction4949
Reach Compliance Codeunknow
ECCN codeEAR99

Preview

Download Datasheet
REF :
PROD.
NAME
SPECIFICATION FOR APPROVAL
SHIELDED SMD
POWER INDUCTOR
B
ABC'S DWG NO.
ABC'S ITEM NO.
SD1206□□□□L□
PAGE: 1
Ⅰ﹒
MECHANICAL DIMENSIONS
：
A : 12.50±0.30
B : 12.50±0.30
C :
A
D :
E :
E1:
M
P1
E2:
F :
F1:
P
N
P2
1
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
5.70±0.30
1.90±0.20
2.50 nom.
2.00 ref.
2.00 ref.
7.50±0.25
6.40 ref.
5.20 ref.
4.15 ref.
3.00 ref.
Marking
Inductance code
E1
E
C
D
H
I
K
I
( PCB Pattern )
F2:
I :
J :
H : 10.50 ref.
E2
F2
3
F
：
CLIP 3
For mounting fixed
F1
J
2
K : 13.00 ref.
M : 4.70 ref.
N :
4.50 ref.
7.50 ref.
3.75 ref.
3.75 ref.
a
c
b
d
e
f
P :
P1 :
P2 :
Ⅱ﹒
SCHEMATIC DIAGRAM
：
1
Ⅲ﹒
MATERIALS LIST
：
2
a
﹒
Core
：
Ferrite ER core
b
﹒
Core
：
Ferrite SB core
c
﹒
Wire
：
Ultra-fine rectangular
Enamelled copper wire
（
class F
）
d
﹒
Terminal
：
Cu/Sn
e
﹒
Adhesive
：
Epoxy resin
f
﹒
Adhesive
：
Epoxy resin
g
﹒
Remark
：
Lead content 200ppm max.
include ferrite
Peak Temp
：
260
℃
max.
Max time above 230
℃ ：
50sec max.
Max time above 200
℃ ：
70sec max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
Reflow Area
Forced Cooling Area
+2.0 ~ 4.0
℃
-(1.0 ~ 5.0)
℃
/ sec max.
/ sec max.
Peak Temperature:
260℃
50sec max.
230℃
250
Temperature (
℃
)
200
150
70sec max.
Ⅳ﹒
GENERAL SPECIFICATION
：
a
﹒
Temp. rise
：
40
℃
max.
b
﹒
Storage temp.
：
-40
℃
~ +125
℃
c
﹒
Operating temp.
：
-40
℃
~ +105
℃
d
﹒
Resistance to solder heat
：
260
℃
. 10 secs.
AE-001A
100
50
0
50
100
150
Time ( seconds )
200
250

SD12064R6YLA Related Products

SD12064R6YLA SD12062R3YLA SD12062R3YLB SD12064R6YLB
Description General Purpose Inductor, 4.6uH, 25%, Ferrite-Core, 4949 General Purpose Inductor, 2.3uH, 25%, Ferrite-Core, 4949 General Purpose Inductor, 2.3uH, 25%, Ferrite-Core, 4949 General Purpose Inductor, 4.6uH, 25%, Ferrite-Core, 4949
Is it Rohs certified? conform to conform to conform to conform to
Maker ABC [ABC Taiwan Electronics Corp] ABC [ABC Taiwan Electronics Corp] ABC [ABC Taiwan Electronics Corp] ABC [ABC Taiwan Electronics Corp]
package instruction 4949 4949 4949 4949
Reach Compliance Code unknow unknown unknown unknown
ECCN code EAR99 EAR99 EAR99 EAR99
uppercase and lowercase codes - 4949 4949 4949
structure - Shielded Shielded Shielded
core material - Ferrite Ferrite Ferrite
DC Resistance - 0.0046 Ω 0.0046 Ω 0.007 Ω
Nominal inductance(L) - 2.3 µH 2.3 µH 4.6 µH
Inductor type - GENERAL PURPOSE INDUCTOR GENERAL PURPOSE INDUCTOR GENERAL PURPOSE INDUCTOR
Manufacturer's serial number - SD1206-L SD1206-L SD1206-L
Maximum operating temperature - 105 °C 105 °C 105 °C
Minimum operating temperature - -40 °C -40 °C -40 °C
Package height - 5.7 mm 5.7 mm 5.7 mm
Package length - 12.5 mm 12.5 mm 12.5 mm
Package form - SMT SMT SMT
Package width - 12.5 mm 12.5 mm 12.5 mm
method of packing - Bulk TR, 13 Inch TR, 13 Inch
Maximum rated current - 11 A 11 A 7.5 A
series - SD1206-L SD1206-L SD1206-L
shield - YES YES YES
Tolerance - 25% 25% 25%
Base Number Matches - 1 1 1
