5-1622806-3: DescriptionRESISTOR, NETWORK, FILM, BUSSED, 0.2W, THROUGH HOLE MOUNT, SIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size111KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

5-1622806-3 Overview

RESISTOR, NETWORK, FILM, BUSSED, 0.2W, THROUGH HOLE MOUNT, SIP, ROHS COMPLIANT

5-1622806-3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1635860283
package instruction	SIP, ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
The first element resistor	820 Ω
Manufacturer's serial number	SIL
Installation features	THROUGH HOLE MOUNT
Network Type	BUSSED
Number of components	8
Number of functions	1
Number of terminals	9
Package shape	RECTANGULAR PACKAGE
method of packing	BULK
Rated power dissipation(P)	0.2 W
Resistor type	ARRAY/NETWORK RESISTOR
surface mount	NO
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	100 ppm/°C
Terminal shape	FLAT
Tolerance	5%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

SIL09E821J Product Details

Live Product Chat

Fixed Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

SIL09E821J

(5-1622806-3)

T E I nternal N umber: 5 - 1 6 2 2 8 0 6 - 3

Product Highlights:

Resistor Type = General Purpose Resistor

Resistance Selection = <1K ?

Resistance = 820 ?

Power Rating = .20 W

Tolerance = 5 %

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

General Purpose Resistors Networks - Sil Resistor Ne...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Resistor Type = General Purpose Resistor

Resistance (?)

= 820

Element

= Thick Film

Termination Type

= Preformed Leadframe

Electrical Characteristics:

Resistance Selection (?)

= <1K

Power Rating (W)

= 0.20

Tolerance (%)

= 5

Package Type

= Loose Piece - Bag

Body Related Features:

Series

= SIL

Mount Style

= SIL Network

Package, C omponent Size

= 22.86 x 5.08

Configuration Related Features:

Number of Terminations

= 9

Number of Resistors

= 8

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= ?100

Operation/Application:

Application

= Various

Other:

Brand = C itec

Additional Information:

Product Line Information

5-1622806-3 Related Products

	5-1622806-3	SIL09E821J
Description	RESISTOR, NETWORK, FILM, BUSSED, 0.2W, THROUGH HOLE MOUNT, SIP, ROHS COMPLIANT	RESISTOR, NETWORK, FILM, BUSSED, 0.2W, THROUGH HOLE MOUNT, SIP, ROHS COMPLIANT
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
The first element resistor	820 Ω	820 Ω
Manufacturer's serial number	SIL	SIL
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT
Network Type	BUSSED	BUSSED
Number of components	8	8
Number of functions	1	1
Number of terminals	9	9
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
method of packing	BULK	BULK
Rated power dissipation(P)	0.2 W	0.2 W
Resistor type	ARRAY/NETWORK RESISTOR	ARRAY/NETWORK RESISTOR
surface mount	NO	NO
technology	METAL GLAZE/THICK FILM	METAL GLAZE/THICK FILM
Temperature Coefficient	100 ppm/°C	100 ppm/°C
Terminal shape	FLAT	FLAT
Tolerance	5%	5%
