SMM0102
Vishay Draloric
Metal Film, Cylindrical Resistors
FEATURES
•
Stable metal film on high quality ceramic
•
Low TC and tight tolerances
•
Excellent stability
•
Force fitted steel caps, tin plated on nickel barrier
•
Reliable solderable terminations to facilitate surface
mounting
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
SMM0102
SMM0102
SMM0102
1)
POWER RATING
P
70°C1)
W
0.20
0.20
0.20
LIMITING ELEMENT
VOLTAGE MAX
2)
V
100
100
100
R
max
= 10m
Ω
I
max
= 2A
TEMPERATURE
COEFFICIENT
ppm/K
15
25
50
TOLERANCE
%
0.1
0.1
1.0
RESISTANCE
RANGE
Ω
100R – 100K
100R – 100K
10R – 2M21
E-SERIES
24 – 96
24 – 96
24 – 96
Zero-Ohm-Resistor : OMM0102
Power rating depends on the maximum temperature at the
solder point, the component placement density and the
substrate material
Rated voltage:
PxR
•
Further values and tolerances on request
•
Coating: green for
TC = 50ppm/K
pink
TC = 25ppm/K
violet TC = 15ppm/K
zero ohm resistor with a black band only
•
Marking: see appropriate catalog or web page
2)
TECHNICAL SPECIFICATIONS
PARAMETER
Rated Dissipation at 70°C
Limiting Element Voltage
Insulation Voltage (1 min)
Thermal Resistance
Insulation Resistance
Category Temperature Range
Failure Rate
Weight / 1000pcs
10
UNIT
W
V
V
dc/ac peak
K/W
Ω
°C
–9
PMM0207
0.2
100
> 150
≤
250
≥
10
10
- 55 / + 125
/h
<2
7.8
g
ORDERING INFORMATION
SMM0102
MODEL
25
TC
ppm / K
562R
RESISTANCE VALUE
Ω
0.1%
TOLERANCE
± %
B3
PACKAGING
B3-Blistertape 3000 pcs
Document Number: 20003
Revision: 20-Oct-03
For Technical questions contact: ff1aresistors@vishay.com
www.vishay.com
1
SMM0102
Vishay Draloric
DIMENSIONS
MODEL
SMM0102
DIMENSIONS
[in millimeters]
D
max
1.1
d*
D - 0.05
L
2.2 - 0.15
A
max
0.45
A
min
0.35
Metal Film Cylindrical Resistors
*d measured in the middle of the resistor
SOLDER PAD DIMENSIONS
[in millimeters]
MODEL
SMM0102
REFLOW SOLDERING WAVE SOLDERING
a
0.5
b
1.3
l
1.3
a
0.6
b
1.3
l
1.3
PERFORMANCE
TEST
Endurance Test at 70°C
IEC 60115-1 4.25.1
Endurance at UCT
IEC 60115-1 4.25.3
Overload Test
IEC 60115-1 4.13
Thermal Shock
IEC 60115-1 4.19, IEC 60068-2-14
Damp Heat Steady State
IEC 60115-1 4.24, IEC 60068-2-3
Resistance to Soldering Heat
IEC 60115-1 4.18, IEC 60068-2-20
1)
CONDITIONS OF TEST
1000 hours at 70°C, 1.5 hours "ON", 0.5 hours "OFF"
8000 hours at 70°C, 1.5 hours "ON", 0.5 hours "OFF"
1000 hours at 125°C without load
REQUIREMENTS
1)
≤
± 0.25%
≤
± 0.5%
≤
± 0.5%
≤
± 0.1%
≤
± 0.1%
≤
± 0.5%
≤
± 0.1%
Short time overload for 2 seconds at 6.25 x rated power
Rapid change between upper and lower category temperature
56 days at 40°C and 93% relative humidity
10 seconds at 260°C solder bath temperature
For a resistance range from 10
Ω
to 1M
Ω
PACKAGING
REEL
BULK
MODEL
TAPE WIDTH
DIAMETER
PIECES / REEL
CODE
BULK FEEDING MAGAZINE
PIECES/MAGAZIN
E
CODE
SMM0102
OMM0102
8mm
Blistertape
180mm
180mm
330mm
1000
3000
10000
B1*
B3
B0
8000
M8
• For further information about packaging see appropriate catalog or web page
*For
≤
TC25 and Tol.
≤
0.5% only
www.vishay.com
2
For Technical questions contact: ff1aresistors@vishay.com
Document Number: 20003
Revision: 20-Oct-03
