335MABA03KI: DescriptionAC/Motor Run Film Capacitors; File Size447KB，4 Pages; ManufacturerIllinois Capacitor; Websitehttp://www.illinoiscapacitor.com/

Download Datasheet View All

335MABA03KI Overview

AC/Motor Run Film Capacitors

Preview

Download Datasheet

View All

AC/Motor Run Film Capacitors

MAB

FEATURES

Good dvdt

–

High frequency electronic ballasts

–

Motor run

–

SMPS

Motor speed control

General purpose AC application

–

Switching capacitor for industrial controls

APPLICATIONS

Operating Temperature Range

Capacitance Tolerance

Rated Voltage

Self Inductance

Dissipation Factor

(max) at 20°C

Insulation Resistance

@20°C (<70% RH)

for 1 minute at 100VDC

Dialectric Strength

Self Inductance

Capacitance Drift

Temperature Coefficient

Freq (kHz)

40°C to +105°C without use of approvals

Range -25°C to +85°C for use of approvals

±10% at 1 kHz, 20°C

See Voltage Code Table.

Voltage must be derated by 1.25% per °C exceeding 85°C.

<1 nano-Henry per mm of body length and lead length

C≤2.2μF

.06%

2.2μF<C≤15μF

.1%

> 10,000MΩ x μF for C<1μF.

> 3,000MΩ x μF for C≥1μF.

160% of rated VAC for 60 seconds at 20°C between leads.

200% of rated VAC for 60 seconds at 20°C between leads.

for EN 60252-1 approval.

3KV at 60HZ for 60 seconds between leads and case.

<1nH/mm of lead spacing and lead wire length.

<1.0% up to 40°C after 2 years

-200ppm/ °C +/- 100ppm/ °C

125% of rated voltage at +85°C

200 hrs. for Class D (1,000 hours expected life, continuous service)

600 hrs. for Class C (3,000 hours expected life, continuous service)

2,000 hrs. for Class B (10,000 hours expected life, continuous service)

6,000 hrs. for Class A (30,000 hours expected life, continuous service)

Polypropylene

Vacuum Deposited Metal Layers

Metallized Film

Solid or Stranded Tinned Copper Wire

Solvent resistant plastic box (UL 94-V1) with epoxy fills (UL 94V-0)

15μF<C≤22μF

.12%

C>22μF

.14%

Load Life Test

Capacitance Change

≤3%

Dielectric

Electrodes

Construction

Leads

Coating

ILLINOIS CAPACITOR, INC.

Your Global Source for World-Class Capacitors

North America

Tel: 847.675.1760

sales@illcap.com

Asia

Tel: 852.2793 0931

sales@illcap.com.hk
