BC337-40: DescriptionSmall Signal Bipolar Transistor, 0.8A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-92, PLASTIC PACKAGE-3; CategoryDiscrete semiconductor The transistor; File Size120KB，3 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric Compare View All

BC337-40 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BC337-40	-	-	View	Buy Now

BC337-40 Overview

Small Signal Bipolar Transistor, 0.8A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-92, PLASTIC PACKAGE-3

BC337-40 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Micro Commercial Components (MCC)
Parts packaging code	TO-92
package instruction	CYLINDRICAL, O-PBCY-T3
Contacts	3
Reach Compliance Code	compli
ECCN code	EAR99
Maximum collector current (IC)	0.8 A
Collector-emitter maximum voltage	45 V
Configuration	SINGLE
Minimum DC current gain (hFE)	250
JEDEC-95 code	TO-92
JESD-30 code	O-PBCY-T3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	NPN
Maximum power consumption environment	0.625 W
Maximum power dissipation(Abs)	0.625 W
Certification status	Not Qualified
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Transistor component materials	SILICON
Nominal transition frequency (fT)	210 MHz
VCEsat-Max	0.7 V

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

BC337-16/25/40

BC338-16/25/40

NPN

Plastic-Encapsulate

Transistors

TO-92

Features

Capable of 0.625Watts of Power Dissipation.

Collector-current 0.8A

Collector-base Voltage :V

CBO

=50V(BC337) , V

CBO

=30V(BC338)

Case Material: Molded Plastic.

Classification Rating 94V-0

UL Flammability

Maximum Ratings

Operating temperature : -55 to +150

Storage temperature : -55 to +150

Electrical Characteristics @ 25

Symbol

Parameter

Unless Otherwise Specified

Min

Max

---

Vdc

Units

Vdc

OFF CHARACTERISTICS

(BR)CEO

Collector-Emitter Breakdown Voltage

=10mAdc, I

=0)

BC337

BC338

Collector-Base Breakdown Voltage

=100µAdc, I

=0)

BC337

BC338

Collector-Emitter Breakdown Voltage

=10µAdc, I

=0)

Collector Cutoff Current

BC337

=45Vdc,I

=0)

=25Vdc,I

=0)

BC338

Collector Cutoff Current

=40Vdc,I

=0)

BC337

BC338

=20Vdc,I

=0)

Emitter Cutoff Current

=4.0Vdc, I

=0)

DC Current Gain

=300mAdc, V

=1.0Vdc)

Collector-Emitter Saturation Voltage

=500mAdc, I

=50mAdc)

Base-Emitter Saturation Voltage

=500mAdc,I

=50mAdc)

Current-Gain-Bandwidth Product

=5.0V, f=100MHz, I

=10mA)

Classification

FE(1)

Marking Code

100~250

A 011

(BR)CBO

(BR)EBO

CBO

5.0

---

Vdc

µAdc

---

0.1

µAdc

0.2

0.1

CEO

EBO

µAdc

ON CHARACTERISTICS

FE(2)

CE(sat)

BE(sat)

---

0.7

1.2

Vdc

1.COLLECTOR

2.BASE

3.EMITTER

Vdc

DIMENSIONS

SMALL SIGNAL CHARACTERISTICS

210

---

MHz

DIM

hFE CLASSIFICATION

160~400

B 011

250~630

C 011

INCHES

MIN

.170

.550

.010

.130

.010

MAX

.190

.590

.020

.160

.104

MIN

4.33

4.30

13.97

0.36

3.30

2.44

MAX

4.83

14.97

0.56

3.96

2.64

NOTE

www.mccsemi.com

Revision: 4

1 of 3

2006/05/18

BC337-40 Related Products

	BC337-40	BC337-16	BC337-25	BC338-40
Description	Small Signal Bipolar Transistor, 0.8A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-92, PLASTIC PACKAGE-3	Small Signal Bipolar Transistor, 0.8A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-92, PLASTIC PACKAGE-3	Small Signal Bipolar Transistor, 0.8A I(C), 45V V(BR)CEO, 1-Element, NPN, Silicon, TO-92, PLASTIC PACKAGE-3	Small Signal Bipolar Transistor, 0.8A I(C), 25V V(BR)CEO, 1-Element, NPN, Silicon, TO-92, PLASTIC PACKAGE-3
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible
Maker	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)
Parts packaging code	TO-92	TO-92	TO-92	TO-92
package instruction	CYLINDRICAL, O-PBCY-T3	CYLINDRICAL, O-PBCY-T3	PLASTIC PACKAGE-3	CYLINDRICAL, O-PBCY-T3
Contacts	3	3	3	3
Reach Compliance Code	compli	compliant	unknown	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Maximum collector current (IC)	0.8 A	0.8 A	0.8 A	0.8 A
Collector-emitter maximum voltage	45 V	45 V	45 V	25 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Minimum DC current gain (hFE)	250	100	160	250
JEDEC-95 code	TO-92	TO-92	TO-92	TO-92
JESD-30 code	O-PBCY-T3	O-PBCY-T3	O-PBCY-T3	O-PBCY-T3
JESD-609 code	e0	e0	e0	e0
Number of components	1	1	1	1
Number of terminals	3	3	3	3
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	ROUND	ROUND	ROUND
Package form	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Polarity/channel type	NPN	NPN	NPN	NPN
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	NO
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal location	BOTTOM	BOTTOM	BOTTOM	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Transistor component materials	SILICON	SILICON	SILICON	SILICON
Nominal transition frequency (fT)	210 MHz	210 MHz	210 MHz	210 MHz
Maximum operating temperature	150 °C	150 °C	150 °C	-
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-
Maximum power consumption environment	0.625 W	0.625 W	0.625 W	-
Maximum power dissipation(Abs)	0.625 W	0.625 W	0.625 W	-
VCEsat-Max	0.7 V	0.7 V	0.7 V	-
