TL431N datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> TL431N

TL431N: DescriptionThree Terminal Voltage Reference, 1 Output, Trim/Adjustable, PBCY3, TO-92, 3 PIN; CategoryPower/power management The power supply circuit; File Size158KB，7 Pages; ManufacturerCalogic; Websitehttp://www.calogic.net/

Download Datasheet Parametric Compare View All

TL431N Overview

Three Terminal Voltage Reference, 1 Output, Trim/Adjustable, PBCY3, TO-92, 3 PIN

TL431N Parametric

Parameter Name	Attribute value
Maker	Calogic
Parts packaging code	TO-92
package instruction	TO-92,
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Analog Integrated Circuits - Other Types	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 code	O-PBCY-T3
Number of functions	1
Output times	1
Number of terminals	3
Maximum operating temperature	105 °C
Minimum operating temperature
Maximum output voltage	20 V
Minimum output voltage	2.47 V
Package body material	PLASTIC/EPOXY
encapsulated code	TO-92
Package shape	ROUND
Package form	CYLINDRICAL
Certification status	Not Qualified
surface mount	NO
Temperature level	OTHER
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
Fine-tuning/adjustable output	YES

Preview

Download Datasheet

View All

TL431N Related Products

	TL431N	TL431M1	A1SJ2H-JA	TL431M	TL431NOPTION4	TL431Z	TL431NOPTION3	TL431NOPTION1
Description	Three Terminal Voltage Reference, 1 Output, Trim/Adjustable, PBCY3, TO-92, 3 PIN	Three Terminal Voltage Reference, 1 Output, Trim/Adjustable, PSSO3, SOT-89, 3 PIN	General Specifications	Three Terminal Voltage Reference, 1 Output, Trim/Adjustable, PDSO5, SOT-23, 5 PIN	Two Terminal Voltage Reference, 1 Output, Trim/Adjustable, PBCY3, TO-92	Two Terminal Voltage Reference, 1 Output, Trim/Adjustable, PDSO8, MICRO, SOIC-8	Two Terminal Voltage Reference, 1 Output, Trim/Adjustable, PBCY3, TO-92	Two Terminal Voltage Reference, 1 Output, Trim/Adjustable, PBCY3, TO-92
Maker	Calogic	-	-	Calogic	Calogic	Calogic	Calogic	Calogic
Parts packaging code	TO-92	SOT-89	-	SOT-23	TO-92	SOIC	TO-92	TO-92
Contacts	3	3	-	5	3	8	3	3
Reach Compliance Code	unknow	unknown	-	unknown	unknown	unknown	unknow	unknown
ECCN code	EAR99	EAR99	-	EAR99	EAR99	EAR99	EAR99	EAR99
Analog Integrated Circuits - Other Types	THREE TERMINAL VOLTAGE REFERENCE	THREE TERMINAL VOLTAGE REFERENCE	-	THREE TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE
JESD-30 code	O-PBCY-T3	R-PSSO-F3	-	R-PDSO-G5	O-PBCY-T3	R-PDSO-G8	O-PBCY-T3	O-PBCY-T3
Number of functions	1	1	-	1	1	1	1	1
Output times	1	1	-	1	1	1	1	1
Number of terminals	3	3	-	5	3	8	3	3
Maximum operating temperature	105 °C	105 °C	-	105 °C	105 °C	105 °C	105 °C	105 °C
Maximum output voltage	20 V	20 V	-	20 V	20 V	20 V	20 V	20 V
Minimum output voltage	2.47 V	2.47 V	-	2.47 V	2.47 V	2.47 V	2.47 V	2.47 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	RECTANGULAR	-	RECTANGULAR	ROUND	RECTANGULAR	ROUND	ROUND
Package form	CYLINDRICAL	SMALL OUTLINE	-	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	CYLINDRICAL	SMALL OUTLINE	CYLINDRICAL	CYLINDRICAL
Certification status	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	YES	-	YES	NO	YES	NO	NO
Temperature level	OTHER	OTHER	-	OTHER	OTHER	OTHER	OTHER	OTHER
Terminal form	THROUGH-HOLE	FLAT	-	GULL WING	THROUGH-HOLE	GULL WING	THROUGH-HOLE	THROUGH-HOLE
Terminal location	BOTTOM	SINGLE	-	DUAL	BOTTOM	DUAL	BOTTOM	BOTTOM
Fine-tuning/adjustable output	YES	YES	-	YES	YES	YES	YES	YES
