General Purpose Relays
PCB Relays
Miniature Power PCB Relay PB
n
n
n
n
n
SCHRACK
1pole 10A, 1 form C (CO) or 1 form A (NO)
Environmentally-friendly cadmium-free contacts
Class F coil system standard
Compact and simple design gives high process security
Product in accordance to IEC 60335-1
Typical applications
White goods, small home appliances, heating temperature controllers
F0224-C
VZ
Approvals
VDE REG.-Nr. 121560, UL E214025
Technical data of approved types on request
Coil Data
Coil voltage range
Operative range, IEC 61810
Coil versions, DC coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
Coil versions, DC-coil, 360mW
005
5
3.75
006
6
4.50
009
9
6.75
012
12
9.00
018
18
13.50
022
22
16.50
024
24
18.00
048
48
36.00
Coil versions, DC-coil, 500mW
005
5
3.75
006
6
4.5
012
12
9
024
24
18
5 to 48 VDC 5 to 24 VDC 5 to 24 VDC
2
2
2
Release
voltage
VDC
0.5
0.6
0.9
1.2
1.8
2.2
2.4
4.8
0.5
0.6
1.2
2.4
Coil
resistance
Ω±10%
70
100
225
400
900
1344
1600
6400
48
69
274
1097
Rated coil
power
mW
357
360
360
360
360
360
360
360
521
522
526
525
PB1
PB5
PB6
Contact Data
Contact arrangement
1 form C (CO) or 1 form A (NO)
Rated voltage
250VAC
Max. switching voltage
400VAC
Rated current
10A
Limiting making current, max 4 s, duty factor 10% 15A
Breaking capacity max.
2500VA
Contact material
AgNi 90/10, AgSnO
2
Frequency of operation, with/without load
360/36000h
-1
Operate/release time max.
10/20ms
Bounce time max., form A/form B
10/15ms
Contact ratings
Type
IEC 61810
PB114; PB113
PB114
PB134; PB133
PB134
PB634
PB634
UL 508
PB1x4
Contact
A/B (NO/NC)
A of C
A (NO)
A (NO)
A (NO)
A (NO)
A (NO)
Load
10A/3A, 250VAC, cosφ=1, 85°C
10A, 250VAC, cosφ=1, 85°C
10A, 250VAC, cosφ=1, 85°C
6.5A, 440VAC, cosφ=1, 85°C
8.5A, 250VAC, cosφ=1, 85°C
10A, 250VAC, cosφ=1, 85°C
10A, 250VAC, cosφ=1, 85°C
5x10
6
operations
Cycles
30x10
3
30x10
3
20x10
3
50x10
3
100x10
3
60x10
3
20x10
3
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Other coil voltages on request.
Mechanical endurance, DC coil
Insulation Data
Initial dielectric strength
between open contacts
between contact and coil
Clearance/creepage
between contact and coil
form C (CO) version
form A (NO) version
Material group of insulation parts
Tracking index of relay base
04-2011, Rev. 0411
www.te.com
© 2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
1000Vrms
2500Vrms
≥3/4mm
≥4/5mm
IIIa
PTI250
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
General Purpose Relays
PCB Relays
Miniature Power PCB Relay PB
(Continued)
Other Data
PCB layout
1)
/ terminal assignment
Bottom view on solder pins
SCHRACK
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Resistance to heat and fire
version PB1, PB5
according EN60335, par.30
Ambient temperature, DC coil
-40 to +85°C
Category of environmental protection
IEC 61810
RTII - flux proof
Vibration resistance (functional), form A/form B, 30 to 400Hz
PB1, PB6
>10/4g
PB5
>10/6 g
Shock resistance (destructive)
>100g
Terminal type
PCB-THT
Weight
5.4g
Resistance to soldering heat THT
IEC 60068-2-20
270°C/10s
Packaging/unit
tube/35 pcs., box/1050 pcs.
S0407-AA
S0407-AB
Dimensions
1)
S0407-AC
Layout note:
No openings (e.g. holes, slots, cutouts, unused pins, open through
connections, etc.) allowed under the relay base. The relay base must be
fully covered by the pcb, recommended minimum distance between the
relay and the edge of the printed circuit board is 5 mm.
For more information, please contact our application support.
S0406-A
Product code structure
Type
PB
Miniature Power PCB Relay PB
Version
1
Standard version
Typical product code
PB
1
1
4
012
5
6
500 mW version
High performance version (form A version only)
1 form A contact (1 NO)
AgNi 90/10
Contact arrangement
1
1 form C contact (1 CO)
3
Contact material
3
AgSnO
2
4
Coil
Coil code: please refer to coil versions table
Product code
PB114005
PB114006
PB114012
PB114024
PB134005
PB134006
PB134012
PB134024
PB514012
PB514024
PB634005
PB634006
PB634012
PB634024
Version
Standard
class F
1 form C
1 CO contact
1 form A
1 NO contact
Contacts
Contact material
AgNi 90/10
500 mW
version
High
performance
version
1 form C
1 CO contact
1 form A
1 NO contact
5VDC
6VDC
12VDC
24VDC
5VDC
6VDC
12VDC
24VDC
12VDC
24VDC
5VDC
6VDC
12VDC
24VDC
Coil
Part number
6-1415029-1
7-1415029-1
8-1415029-1
9-1415029-1
1415030-1
1-1415030-1
2-1415030-1
3-1415030-1
2-1415538-5
5-1415535-6
3-1415541-8
3-1415541-9
4-1415541-1
4-1415541-2
2
04-2011, Rev. 0411
www.te.com
© 2011 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
