53426-1010

Description
8 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP
CategoryThe connector
File Size30KB,2 Pages
ManufacturerMolexKits
Websitehttp://www.molexkits.com
Download Datasheet Parametric View All

53426-1010 Online Shopping

Suppliers Part Number Price MOQ In stock
53426-1010 - - View Buy Now

53426-1010 Overview

8 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP

53426-1010 Parametric

Parameter NameAttribute value
Contact materialsNOT SPECIFIED
Total number of contacts8
Lead-freeYes
EU RoHS regulationsYes
stateACTIVE
OptionsGENERAL PURPOSE
Manufacturer Series51103
Contact surface matchingNOT SPECIFIED
Contact coated terminalsNOT SPECIFIED
Connection TypeTWO PART BOARD CONNECTOR
Connector male and femaleFEMALE
collocation informationMULTIPLE MATING PARTS AVAILABLE
Installation typeCABLE
Number of load rows1
Terminal typeCRIMP
UL flammability code94V-0
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0134
General Information
Part Number:
76650-0134
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Mini-Lock Deluxe Connector Kit
Fully Shrouded Positive Lock Vertical and Right Angle Header and Receptacle
Mini-Lock™
(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
Mini-Lock is a versatile wire-to-board system from Molex for a broad range of
2.50mm (.098" ) pitch industry standard applications. The kit includes Right Angle
headers. Mini-Lock is fully shrouded to protect contacts, and includes high guide
walls to facilitate mating.
Features and Benefits
• Four point contact design for good
electrical reliability
• Thumb-latch locking feature for easy
mating and unmating
• High guide walls to facilitate mating
• Fully shrouded headers to protect pins
• Pull tabs to assist in unmating
Applications
• White goods
• Vending machines
• Automotive
• PDAs
• TVs
Wire-to-Board
2.50mm (.098")
Receptacle and Header
Vertical and Right Angle
7, 8, 9 and 10
3 Amps
250 Volts
28-22 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
