Datasheet for 76650-0189
General Information
Part Number:
76650-0189
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
2.0 Thin Connector Kit
Locking Plug and Receptacle
N/A
(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Circuit Sizes:
Current Rating:
Voltage:
Wire Size:
Wire-to-Wire
2.00mm (.079")
Plugs and Receptacle
2, 3, 4 and 5
(1-2) Amps - Dependant on Wire Gauge
125 Volts
28-24 AWG
Product Highlights
This family has a very thin housing design, with the housings having a 2.7mm
maximum thickness. The 51005 series (9.2mm) mated with the 51006 series
(10.8mm) has a mated length of 14.8mm. The plug and receptacle mate with an
audio click, and remain mated very strongly with locking tangs on both sides. The
housings are marked at circuit one.
Features and Benefits
• Spring beam design provides high
pressure and small deflection for high
vibration applications
• Polarization prevents mismating
• Operating Temperature: -40 to +105˚C
• Locking tang for secure housing retention
• Very thin housing design, 2.7mm (.106)"
Applications
• Office Automation: Printers, Fax machines,
Scanners, Copiers
• Measuring / Analyzing Equipment, Security
systems / alarms, Medical monitoring,
Lab equipment
• Other applications: Vending machines,
Gaming machines, Fitness equipment
Bill of Materials for Part No. 76650-0189
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0189
Country
Molex Part No. of Origin
50012-8100
50013-8100
51005-0200
51005-0300
51005-0400
51005-0500
51006-0200
51006-0300
51006-0400
51006-0500
Description
Male Crimp Terminal, Loose, for 2.00mm (.079") Pitch 51006
Mexico Plug
Female Crimp Terminal, Loose, for 2.00mm (.079") Pitch
Mexico 51005 Receptacle
2.00mm (.079") Pitch Wire-to-Wire Receptacle Housing, 2
Japan Circuits
2.00mm (.079") Pitch Wire-to-Wire Receptacle Housing, 3
Japan Circuits
2.00mm (.079") Pitch Wire-to-Wire Receptacle Housing, 4
Japan Circuits
2.00mm (.079") Pitch Wire-to-Wire Receptacle Housing, 5
Japan Circuits
Japan
Japan
Japan
Japan
2.00mm (.079") Pitch Wire-to-Wire Plug Housing, 2 Circuits
2.00mm (.079") Pitch Wire-to-Wire Plug Housing, 3 Circuits
2.00mm (.079") Pitch Wire-to-Wire Plug Housing, 4 Circuits
2.00mm (.079") Pitch Wire-to-Wire Plug Housing, 5 Circuits
Quantity in
Kit
50
50
5
5
3
3
5
5
3
3
Recommended Molex Tool(s) for Part No. 76650-0189*
Country
Molex Part No. of Origin
63811-7800 *
57046-5000 *
Description
Sweden
Hand Crimp Tool, UL Approved
USA
Hand Crimper - JAPAN
*Tool(s) not included in kit. Tool(s) ordered separately.
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 2
