CAPACITORS
For general purpose
Wide CV value range
Life 2000 hours at +85°C
Safety vent construction products
ALUMINIUM ELECTROLYTIC STANDARD RADIAL CEBM
SECTION 1
RANGE
V
µF
0.1
0.22
0.33
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
2200
3300
4700
6800
10000
15000
6.3
øxl/mm
10
øxl/mm
16
øxl/mm
25
øxl/mm
35
øxl/mm
50
øxl/mm
63
øxl/mm
100
øxl/mm
160
øxl/mm
200
øxl/mm
250
øxl/mm
5x11
5x11
6.3x11
6.3x11
8x11
8x11
10x16
10x16
10x20
12.5x25
12.5x25
16x31.5
400
øxl/mm
6.3x11
6.3x11
6.3x11
6.6.3x11
8x11.5
8x11.5
10x16
10x20
12.5x20
16x25
16x31.5
18x35.5
450
øxl/mm
6.3x11
6.3x11
6.3x11
6.3x11
8x11
10x16
10x20
12.5x20
12.5x25
16x31.5
18x35.5
18x40
5x11
5x11 6.3x11 6.3x11
6.3x11 8x11.5 8x11.5
6.3x11 8x11.5 8x11.5 10x12.5
8x11.5 8x11.5 10x12.5 10x16
10x12.5 10x16 10x20 12.5x20
12.5x20 12.5x20 12.5x25 16x25
12.5x20 12.5x25 16x25 16x31.5
16x25 16x25 16x31.5 18x35.5
16x25 16x31.5 18x32 18x35.5
16x31.5 18x35.5 18x35.5
18x35.5 18x35.5
5x11
5x11 6.3x11
5x11 6.3x11 6.3x11
6.3x11 6.3x11 8x11.5
8x11.5 8x11.5 10x12.5
10x12.5 10x16 10x20
10x16 10x20 12.5x20
10x20 12.5x20 12.5x25
12.5x25 16x25 16x31.5
16x31.5 16x34.5 22x40
18x35.5 18x35.5
18x35.5
5x11
5x11
5x11
5x11
5x11
6.3x11
8x11.5
10x12.5
10x16
12.5x20
16x25
16x25
16x31.5
18x40
6.3x11
6.3x11
6.3x11
8x11.5
8x11.5
10x12.5
10x20
12.5x20
12.5x25
16x25
18x35.5
6.3x11
6.3x11
6.3x11
8x11.5
10x12.5
10x16
10x20
12.5x25
12.5x25
16x31.5
22x35.5
Sizes may reduce as technology continually improves.
ORDERING INFORMATION
CEBM
Range
100
Capacitance
µF
16
Voltage
V
TA
Options:
TA = Tape/Ammo-box
Blank = Loose
CRxx = Cropped to xxMM
TA = 5mm pitch, e.g. TA 2mm = 2mm pitch
33
www.dubilier.co.uk
CAPACITORS
ALUMINIUM ELECTROLYTIC STANDARD RADIAL CEBM
SPECIFICATION
Item
Operating Temperature Range
Rated Working Voltage Range
Nominal Capacitance Range
Capacitance Tolerance
Leakage Current
Performance Characteristics
-25 to +85°C
160 to 450V DC
0.47 to 220µF
SECTION 1
tan ∂
Ripple Current
Low Temperature Characteristics
Impedance
High Temperature Loading
Shelf Life
-40 to +85°C
6.3 to 100V DC
0.47 to 15000µF
± 20% (120Hz, +20°C)
l ≤ 0.01CV or 3[µA] after 2 minutes
l ≤ 0.06CV [µA] after 2 minutes
whichever is greater measured with
application of rated working voltage at +20°C
rated working voltage applied at +20°C
Working voltage [V]
6.3
10
16
25
35
50
63
100
tan ∂ (max.)
0.22
0.19
0.16
0.14
0.12
0.10
0.09
0.08
Working voltage [V]
160
200
250
400
450
0.18
0.20
0.20
tan ∂ (max.)
0.16
0.18
(120Hz, +20°C)For capacitance value > 1000µF, add 0.02 per extra 1000µF
Refer to standard products table (120Hz, +85°C)
Correction factor for frequency
Frequency [Hz]
50/60 120
1K
10K
Correction factor (Multiplier)
0.7
1
1.3
1.7
Impedance ratio max. at 120Hz
Working voltage [V]
6.3
10
16
25
35
50
63
100
-25°C/+20°C
4
3
2
2
2
2
2
2
-40°C/+20°C
8
6
4
4
3
3
3
3
Working voltage [V]
160
200
250
400
450
-25°C/+20°C
2
2
3
15
15
For capacitance value > 1000µF,
Add 0.5 per extra 1000µF for -25°C/+25°C.
Add 1.0 per extra 1000µF for -40°C/+20°C.
m C-Z (rated cap-[µF] x Impedance [Ω]) value at 10KHz
u m i x
Ma
Working voltage [V]
6.3
10
16
25
35
50
63
100
C-Z max. at +20°C
220
160
125
90
80
60
55
50
C-Z max. at -25°C
3000 1900 1300
800
650
560
500
450
Working voltage [V]
160
200
250
450
C-Z max. at +20°C
100
140
150
270
C-Z max. at -25°C
2400 2500 3100
12000
Test conditions
Duration
2000 hours
Ambient temperature
+85°C
Applied voltage
Rated DC working voltage
Post test requirements at +20°C
Leakage current
≤ Initial specified value
Capacitance change
≤ ± 20% of initial measured value
tan ∂
≤ 150% of initial specified value
Test conditions
Duration
500 hours
Ambient temperature
+85°C
Applied voltage
(None)
Post test requirements at +20°C.
Same limits for high temperature loading.
34
www.dubilier.co.uk
