AC S
AFETY
C
APACITORS
Johanson Dielectrics Type SC ceramic chip capacitors are
designed for AC voltage surge and lightning protection in
line-to-ground interface applications in computer networks,
modem, facsimile and other equipment.
Johanson’s safety capacitor offering includes four different
case sizes and NPO and X7R dielectric materials.
These devices are surface mount ready with barrier
terminations and tape and reel packaging.
Information on capacitor safety ratings and certification details
may be found below.
W
L
T
E/B
Polyterm
®
soft termination
option available for
demanding environments &
processes.
SAFETY
RATING
X2/Y3
Y3
X1/Y2
Y2
X1/Y2
Japan
VOLTAGE
RATING
250 VAC
250 VAC
250 VAC
250 VAC
250 VAC
250 VAC
WITHSTANDING
VOLTAGE
1,500 VAC
1,500 VAC
1,500 VAC
1,500 VAC
1,500 VAC
1,500 VAC
IMPULSE
VOLTAGE
2,500 V
2,500 V
5,000 V
5,000 V
5,000 V
N/A
CASE
SIZE
1808
1812
1808
2211
2220
2220
JOHANSON
ORDERING P/N
302R29______V3E-****-SC
302S43______V3E-****-SC
502R29______V3E-****-SC
502R30______V3E-****-SC
502S47______V3E-****-SC
AC2_________V4E-****-JS
STANDARDS:
EN 60384-14:2005, EN 60950 2001 • UL 60950-01
CERTIFICATIONS:
TUV Rheinland T72110251 • UL File E212609 • Semko 0026092-1 & 0003222-1
STANDARDS:
EN 60384-14:2005, EN 60950:2001
CERTIFICATIONS:
TUV Rheinland T72110251
STANDARDS:
EN 60384-14:2005 • UL 60950-01
CERTIFICATIONS:
TUV Rheinland T72110897 / UL File E212609-A1-UL-1
STANDARDS:
EN 60384-14:2005 • UL 60950-01
CERTIFICATIONS:
TUV Rheinland T72110897 • UL File: E212609-A1-UL-1
STANDARDS:
EN 60384-14:2005 • UL 60950-01
CERTIFICATIONS:
TUV Rheinland T72110897 • UL File: E212609-A1-UL-1
STANDARDS:
JIS-C-5102 • JIS-C-5150
CERTIFICATIONS:
N/A
X Capacitors are defined as suitable for use in situations where failure of the capacitor would not lead to danger of electric shock.
Y Capacitors are defined as suitable for use in situations where failure of the capacitor could lead to danger of electric shock.
H
OW TO
O
RDER
AC S
AFETY
C
APACITORS
302
VOLTAGE
302 = 250VAC
[3000V Impulse]
502 = 250VAC
[5000V Impulse]
AC2 =250VAC
[N/A]
P/N written: 302R29W102MV3E-
****
-SC
R29
SIZE
R29=1808
R30=2211
S43=1812
S47=2220
AC2=2220
W
DIELECTRIC
N = NPO
W = X7R
102
CAPACITANCE
1st two digits are
significant; third digit
denotes number of
zeros, R = decimal.
102 = 1000 pF
104 = 0.10 µF
5R0 = 5.0pF
M
TOLERANCE
J = ± 5%
K = ± 10%
M = ± 20%
V
TERMINATION
3
MARKING
E
PACKING
-
****
-SC
TYPE
SC = Safety
Certified
JS = Japan
Safety
V = NI Barrier with 3 = Special E = Embossed 7”
100% Sn Plating 4 = Unmarked
No code = bulk
(Matte)
Tape specs.
F = Polyterm
per EIA RS481
flexible termination
8
www.johanson dielectrics.com
