MIL–PRF (CWR Style) Established Reliability – T429 Series CWR29 Style MIL–PRF–55365/11
Table 1 – Ratings & Part Number Reference
Rated
Voltage
VDC
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
10
VDC
Rated
Cap
µF
2.2
3.3
4.7
4.7
6.8
6.8
10
10
15
15
22
22
33
33
33
47
68
68
100
100
150
220
330
1.5
3.3
3.3
4.7
4.7
6.8
6.8
10
10
15
15
15
22
22
22
33
47
47
68
68
68
100
150
220
330
1
µF
Case Code/
Case Size
KEMET/EIA
A/1005
A/1005
A/1005
B/1505
A/1005
C/2005
B/1505
D/1510
B/1505
E/2010
B/1505
D/1510
D/1510
E/2010
F/2214
E/2010
E/2010
G/2711
F/2214
H/2915
G/2711
H/2915
H/2915
A/1005
A/1005
B/1505
A/1005
C/2005
B/1505
D/1510
B/1505
E/2010
B/1505
D/1510
E/2010
D/1510
E/2010
F/2214
E/2010
F/2214
G/2711
F/2214
G/2711
H/2915
G/2711
G/2711
H/2915
H/2915
A/1005
KEMET/EIA
KEMET Part
Number
(See below for
part options)
T429A225(1)004(2)(3)(4)
T429A335(1)004(2)(3)(4)
T429A475(1)004(2)(3)(4)
T429B475(1)004(2)(3)(4)
T429A685(1)004(2)(3)(4)
T429C685(1)004(2)(3)(4)
T429B106(1)004(2)(3)(4)
T429D106(1)004(2)(3)(4)
T429B156(1)004(2)(3)(4)
T429E156(1)004(2)(3)(4)
T429B226(1)004(2)(3)(4)
T429D226(1)004(2)(3)(4)
T429D336(1)004(2)(3)(4)
T429E336(1)004(2)(3)(4)
T429F336(1)004(2)(3)(4)
T429E476(1)004(2)(3)(4)
T429E686(1)004(2)(3)(4)
T429G686(1)004(2)(3)(4)
T429F107(1)004(2)(3)(4)
T429H107(1)004(2)(3)(4)
T429G157(1)004(2)(3)(4)
T429H227(1)004(2)(3)(4)
T429H337(1)004(2)(3)(4)
T429A155(1)006(2)(3)(4)
T429A335(1)006(2)(3)(4)
T429B335(1)006(2)(3)(4)
T429A475(1)006(2)(3)(4)
T429C475(1)006(2)(3)(4)
T429B685(1)006(2)(3)(4)
T429D685(1)006(2)(3)(4)
T429B106(1)006(2)(3)(4)
T429E106(1)006(2)(3)(4)
T429B156(1)006(2)(3)(4)
T429D156(1)006(2)(3)(4)
T429E156(1)006(2)(3)(4)
T429D226(1)006(2)(3)(4)
T429E226(1)006(2)(3)(4)
T429F226(1)006(2)(3)(4)
T429E336(1)006(2)(3)(4)
T429F476(1)006(2)(3)(4)
T429G476(1)006(2)(3)(4)
T429F686(1)006(2)(3)(4)
T429G686(1)006(2)(3)(4)
T429H686(1)006(2)(3)(4)
T429G107(1)006(2)(3)(4)
T429G157(1)006(2)(3)(4)
T429H227(1)006(2)(3)(4)
T429H337(1)006(2)(3)(4)
T429A105(1)010(2)(3)(4)
(See below for
part options)
MIL–PRF–55365/11
Part Number
(See below for
part options)
CWR29C(3)225(1)(2)A(5)
CWR29C(3)335(1)(2)A(5)
CWR29C(3)475(1)(2)A(5)
CWR29C(3)475(1)(2)B(5)
CWR29C(3)685(1)(2)A(5)
CWR29C(3)685(1)(2)C(5)
CWR29C(3)106(1)(2)B(5)
CWR29C(3)106(1)(2)D(5)
CWR29C(3)156(1)(2)B(5)
CWR29C(3)156(1)(2)E(5)
CWR29C(3)226(1)(2)B(5)
CWR29C(3)226(1)(2)D(5)
CWR29C(3)336(1)(2)D(5)
CWR29C(3)336(1)(2)E(5)
CWR29C(3)336(1)(2)F(5)
CWR29C(3)476(1)(2)E(5)
CWR29C(3)686(1)(2)E(5)
CWR29C(3)686(1)(2)G(5)
CWR29C(3)107(1)(2)F(5)
CWR29C(3)107(1)(2)H(5)
CWR29C(3)157(1)(2)H(5)
CWR29C(3)227(1)(2)H(5)
CWR29C(3)337(1)(2)H(5)
CWR29D(3)155(1)(2)A(5)
CWR29D(3)335(1)(2)A(5)
CWR29D(3)335(1)(2)B(5)
CWR29D(3)475(1)(2)A(5)
CWR29D(3)475(1)(2)C(5)
CWR29D(3)685(1)(2)B(5)
CWR29D(3)685(1)(2)D(5)
CWR29D(3)106(1)(2)B(5)
CWR29D(3)106(1)(2)E(5)
CWR29D(3)156(1)(2)B(5)
CWR29D(3)156(1)(2)D(5)
CWR29D(3)156(1)(2)E(5)
CWR29D(3)226(1)(2)D(5)
CWR29D(3)226(1)(2)E(5)
CWR29D(3)226(1)(2)F(5)
CWR29D(3)336(1)(2)E(5)
CWR29D(3)476(1)(2)F(5)
CWR29D(3)476(1)(2)G(5)
CWR29D(3)686(1)(2)F(5)
CWR29D(3)686(1)(2)G(5)
CWR29D(3)686(1)(2)H(5)
CWR29D(3)107(1)(2)G(5)
CWR29D(3)157(1)(2)G(5)
CWR29D(3)227(1)(2)H(5)
CWR29D(3)337(1)(2)H(5)
CWR29F(3)105(1)(2)A(5)
(See below for
part options)
DC
Leakage
µA @ +20ºC
Max/5 Min
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
2.0
3.0
3.0
4.0
4.0
6.0
8.0
10.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
3.0
3.0
4.0
4.0
4.0
6.0
10.0
10.0
20.0
1.0
µA @ +20ºC
Max/5 Min
DF
% @ +20ºC 120
Hz Max
6.0
6.0
6.0
6.0
6.0
6.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
10.0
10.0
10.0
10.0
10.0
10.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
8.0
8.0
8.0
8.0
6.0
8.0
8.0
6.0
8.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
6.0
% @ +20ºC 120
Hz Max
ESR
Ω @ +20ºC
100 kHz Max
4.0
6.0
6.0
3.2
6.0
2.2
3.2
1.3
3.2
1.0
3.2
1.3
1.3
0.9
0.6
0.9
0.9
0.275
0.55
0.18
0.25
0.20
0.18
4.0
6.0
3.2
6.0
2.2
3.2
1.5
3.2
1.0
3.2
1.7
0.9
1.7
1.0
0.6
1.0
1.0
0.275
0.4
0.25
0.18
0.275
0.275
0.18
0.18
5.0
Ω @ +20ºC
100 kHz Max
Moisture
Sensitivity
Reflow Temperature
≤ 260ºC
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Reflow Temperature
≤ 260ºC
Rated
Voltage
Rated Cap
Case Code/
Case Size
KEMET Part Number
MIL-PRF-55365/11
Part Number
DC
Leakage
DF
ESR
Moisture
Sensitivity
(1) To complete KEMET/CWR part number, insert M for ±20%, K for ±10%, or J for ±5%. Designates Capacitance tolerance.
(2) To complete KEMET/CWR part number, insert failure rate letter per the Ordering Information found on page 2. Designates Reliability Level.
(3) To complete KEMET/CWR part number, insert B = Gold Plated, C = Hot solder dipped, H = Solder plated or K = Solder Fused. Designates Termination Finish.
(4) To complete KEMET part number, insert 4250 = +25°C after Weibull, 4251 = -55°C +85°C after Weibull, or 4252 = -55°C +85°C before Weibull. Designates
Surge current option.
(5) To complete CWR part number, insert A = +25°C after Weibull, B = -55°C +85°C after Weibull, C = -55°C +85°C before Weibull or Z = None. Designates Surge
current option.
Refer to Ordering Information for additional detail.
