Crystal Units
Surface Mount Type CX1612SB
1.6×1.2mm for Consumer Products
Features
• Crystal unit for Consumer Products
• Ultra-miniature and low profile (1.6×1.2×0.3mm)
• Ceramic package
• Reflow compatible
How to Order
CX1612SB 36000
□□ □ □ □ □□
①
②
③ ④⑤⑥ ⑦
①
Series
③
Load Capacitance
B0
D0
EJ
6 pF
8 pF
-10
to
+70°C
②
Frequency
④
Frequency Tolerance
G
±15×10
-
6
Applications
• Digital Electronics
• Consumer Products
• 1seg. tuner
⑤
Operating Temp. Range
⑥
Frequency Temp. Stability
±15×10
-
6
⑦
Individual Specification
RoHS Compliant
Packaging (Tape & Reel 3000/ 1000 pcs./ reel)
Specifications
Item
Frequency Range
Overtone Order
Load Capacitance
Frequency Tolerance
Motional Series Resistance
Drive Level
Operating Temp. Range
Storage Temp. Range
Frequency Temp. Characteristics
• Please contact us for other specifications.
Symbol
f
_nom
OT
CL
f
_tol
R1
DL
T
_use
T
_stg
f
_tem
Specification
26000 to 60000
Fundamental
8
±15
Table 1
Table 2
-10
to
+70
-40
to
+85
±15
Units
kHz
―
pF
×10
-
6
ohm
μW
°C
°C
×10
-
6
25°C±3°C
Remarks
Freq. deviation from the value at 25°C
Table1 Motional Series Resistance
Frequency Range
26000≤f
_nom
<40000kHz
40000≤f
_nom
<50000kHz
50000≤f
_nom
≤60000kHz
Motional Series Resistance
150Ω max.
100Ω max.
50Ω max.
Table2 Level of Drive
Frequency Range
26000≤f
_nom
≤60000kHz
Level of Drive
10μW (100μW max.)
Dimensions
4−R0.1
#4
#3
1.20±0.10
(Unit: mm)
Recommended Land Pattern
0.65
0.5
0.65
(Unit: mm)
0.12±0.05
0.55
#1
1.60±0.10
#2
0.30±0.05
#1
8−0.05±0.05
#2
C 0.20
4−0.10±0.1
#4
GND
(NC)
GND
#3
4−0.47±0.1
0.55
#4
4−0.57±0.1
#3
#1
#2
CONNECTION
(TOP VIEW)
1.15
0.85
0.3
