Thru-Hole DIP Switches
SERIES 76
SPST Rocker
FEATURES
• Raised and Recessed, Rocker
and PIANO-DIP
®
Styles
• Sealed Base Standard
• Spring and Ball Contact
• Top Tape Seal Option
DIP Switches
DIMENSIONS
In inches (and millimeters)
Side Actuated PIANO-DIP
®
PIANO-DIP
®
End Views
Rocker and Recessed Rocker
B = .156 ± .010
(3,96 ± 0,25)
TYPICAL
.020 + .005 –.000
(0,51 + 0,13)
LENGTH
± .010 (±0,25)
SEE ORDER INFO.
1
2
3
4
5
6
7
LENGTH
± .010 (±0,25)
SEE
ORDER INFO.
.281 ± .010
(7,14 ± 0,25)
TYP.
.380 ± .010
(9,65 ± 0,25)
B
.012 ± .001
(0,30 ± 0,03)
.300 + .030 –.000
(7,62 + 0,76)
A = .272 ± .010
(6,91 ± 0,25)
.380 ± .010
(9,65 ± 0,25)
OPEN
OPEN
C
L
C
L
Rocker
1
2
3
4
5
6
7
8
A
.295 + .000
–.020
(7,49 –0,51)
.156 ± .010
(3,96 ± 0,25)
TYP.
.020 + .005
–.000
(0,51 + 0,13)
.012 ± .001
(0,30 ± 0,03)
.300 + .030 –.000
(7,62 + 0,76)
.020 ± .002
(0,51 ± 0,05)
See also end view.
.090 ± .005
(2,29 ± 0,13)
.100 ± .005
(2,5 ± 0,13)
.020 ± .002
(0,51 ± 0,05)
.090 ± .005
(2,29 ± 0,13)
.100 ± .005
(2,5 ± 0,13)
See also end view.
C
L
C
L
For recessed rockers, delete .295 dimension.
CIRCUITRY
Styles 76SB and 76RSB
Style 76PSB
UP IS OPEN (OFF)
Styles 76PRB
UP IS CLOSED (ON)
Typical circuit diagram with actuator
in the closed position.
Actuator shown in the down position.
Actuator shown in the down position.
ORDERING INFORMATION
Series
Switch Style:
SB = Raised Rocker
RSB = Recessed Rocker
PSB = Piano-DIP (Up is Off)
PRB = Piano-DIP (Up is On)
76RSB04ST
T
= RoHS compliant
Sealed*:
S = Tape Seal
Number of Positions:
02 through 10, 12
No. of Pos.
2
3
4
5
6
7
8
9
10
12
Length (Inches)
0.280"
0.380"
0.480"
0.580"
0.680"
0.780"
0.880"
0.980"
1.080"
1.280"
Length (Metric)
7,1 mm
9,7 mm
12,2 mm
14,7 mm
17,3 mm
19,8 mm
22,4 mm
24,9 mm
27,4 mm
32,5 mm
No./Tube
35
27
21
18
15
13
12
10
9
8
*A top tape seal is required for switches that are
machine soldered or heavily cleaned after hand
soldering. To order top seal versions, add "S" to
the Grayhill part number.
Available from your local Grayhill Distributor.
For prices and discounts, contact a local Sales
Office, an authorized local Distributor or Grayhill.
Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
