FEATURES AND SPECIFICATIONS
Features and Benefits
s
Trade name for Molex, RJ-45 Jack that includes wire
s
Magnetics are used for common mode noise rejection, DC
Modular Jack
HyperJack
™
insulation of cable side versus the board side and possible
transforming of LH signal
(WANs) with Ethernet 10 Base T or 100 Base T
s
Resistors and/or cpacitors are incorporated to terminate
characteristics
noise from the non used pair
s
Transformers are used in every port to enable series signal
s
An overmolded installation box in the jack is used to
isolation of the transmission lines
mount, solder, pot magnetics, resistors, and capacitors
s
Common mode chokes are incorporated in the same
during high volume production
transformer core to achieve a better signal-to-noise ratio
s
Used for local area networks (LANs) or wide area networks
wound components (magnetics)
Molex's
HyperJack RJ-45
modular jacks feature integrated
magnetics, capacitors
and resistors.
FEATURES AND SPECIFICATIONS
Features and Benefits
s
Integrated magnetics, capacitors and resistors for space
savings and reduced components on the motherboard
s
Eases logistics
s
Flexible magnetic design adapts to physical specifications
from any vendor
s
EMI/RFI protection includes common mode chokes
s
Full magnetic performance suitable for UTP and STP
applications
s
Symmetrical RX/TX design can be used on PCB or hub side
Reference Information
Product Specification: PS-85533-017
Packaging: Tray
Mates with: FCC 68 Plugs
Designed in: Millimeters
Electrical
Voltage: 125V
Current: 1.5A
Contact Resistance: 20m
Ω
max.
Dielectric Withstanding Voltage: 1500V
Insulation Resistance: 500 M
Ω
min.
OCL (TX, RX): 400
µ
H min.
Electrical (continued)
Insertion Loss (TX, RX): 0.1 to 100 MHz -1dB max.
Return Loss (TX, RX):
0.5 to 30 MHz -18 dB min.
40 MHz
-15.5 dB min.
50 MHz
-13.6 dB min.
60 to 80 MHz -12 dB min.
Common Mode Rejection (TX, RX):
1 to 30 MHz
-50 dB min.
60 MHz
-37 dB min.
100 MHz
-28 dB min.
Crosstalk TX-RX (NEXT):
1 to 30 MHz
-42 dB min.
60 MHz
-38 dB min.
100 MHz
-35 dB min.
Isolation (Hi-Pot): 1500V AC or 2250V DC
Physical
Housing: Black polyester, UL 94V-0
Contact: Phosphor Bronze
Plating: Contact Area—Post plate 1.27 to 1.52
µ
m
(50 to 60
µ
") Gold
Solder Tail Area—1.90
µ
m (75
µ
") min. Tin/Lead
Underplating—Nickel
Operating Temperature: -40 to +80°C
Modular Jack
HyperJack
™
85533
Right Angle
Shielded
CATALOG DRAWING (FOR REFERENCE ONLY)
ORDERING INFORMATION
Circuits
8
Loaded Contacts
8
Order No.
85533-0002
