Part Number

Search

8ETU04S

Description
8 A, 400 V, SILICON, RECTIFIER DIODE
CategoryDiscrete semiconductor    diode
File Size103KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric Compare View All

8ETU04S Online Shopping

Suppliers Part Number Price MOQ In stock
8ETU04S - - View Buy Now

8ETU04S Overview

8 A, 400 V, SILICON, RECTIFIER DIODE

8ETU04S Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerVishay
Parts packaging codeTO-263
package instructionR-PSSO-G2
Contacts3
Reach Compliance Codeunknow
Other featuresFREEWHEELING DIODE, SNUBBER DIODE, LOW LEAKAGE CURRENT
applicationULTRA FAST RECOVERY POWER
Shell connectionCATHODE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.3 V
JESD-30 codeR-PSSO-G2
JESD-609 codee0
Maximum non-repetitive peak forward current100 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature175 °C
Maximum output current8 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage400 V
Maximum reverse recovery time0.06 µs
surface mountYES
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
8ETU04S/8ETU04-1
Vishay High Power Products
Ultrafast Rectifier,
8 A FRED Pt
TM
FEATURES
8ETU04S
8ETU04-1
• Ultrafast recovery time
• Low forward voltage drop
• Low leakage current
Base
cathode
2
• 175 °C operating junction temperature
2
• Designed and qualified for industrial level
DESCRIPTION/APPLICATIONS
FRED Pt
TM
series are the state of the art ultrafast recovery
rectifiers specifically designed with optimized performance of
forward voltage drop and ultrafast recovery time.
The planar structure and the platinum doped life time control,
guarantee the best overall performance, ruggedness and
reliability characteristics.
These devices are intended for use in the output rectification
stage of SMPS, UPS, dc-to-dc converters as well as
freewheeling diode in low voltage inverters and chopper
motor drives.
Their extremely optimized stored charge and low recovery
current minimize the switching losses and reduce over
dissipation in the switching element and snubbers.
1
N/C
3
Anode
1
N/C
3
Anode
D
2
PAK
TO-262
PRODUCT SUMMARY
t
rr
I
F(AV)
V
R
60 ns
8A
400 V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Repetitive peak reverse voltage
Average rectified forward current
Non-repetitive peak surge current
Repetitive peak forward current
Operating junction and storage temperatures
SYMBOL
V
RRM
I
F(AV)
I
FSM
I
FRM
T
J
, T
Stg
T
C
= 155 °C
T
C
= 25 °C
TEST CONDITIONS
MAX.
400
8
100
16
- 65 to 175
°C
A
UNITS
V
ELECTRICAL SPECIFICATIONS
(T
J
= 25 °C unless otherwise specified)
PARAMETER
Breakdown voltage,
blocking voltage
Forward voltage
SYMBOL
V
BR
,
V
R
V
F
I
R
C
T
L
S
I
R
= 100 µA
I
F
= 8 A
I
F
= 8 A, T
J
= 150 °C
V
R
= V
R
rated
T
J
= 150 °C, V
R
= V
R
rated
V
R
= 400 V
Measured lead to lead 5 mm from package body
TEST CONDITIONS
MIN.
400
-
-
-
-
-
-
TYP.
-
1.19
0.94
0.2
20
14
8.0
MAX.
-
1.3
1.0
10
500
-
-
µA
pF
nH
V
UNITS
Reverse leakage current
Junction capacitance
Series inductance
Document Number: 93936
Revision: 08-Sep-08
For technical questions, contact: diodes-tech@vishay.com
www.vishay.com
1
