90156-0146 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 90156-0146

90156-0146: Description6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP; CategoryThe connector; File Size32KB，3 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric View All

90156-0146 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	90156-0146	-	-	View	Buy Now

90156-0146 Overview

6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP

90156-0146 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Terminal spacing	2.54 mm
Total number of contacts	6
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	90156
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	TWO PART BOARD CONNECTOR
Connector male and female	FEMALE
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	CABLE
Number of load rows	1
Terminal type	CRIMP
UL flammability code	94V-1

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0177

General Information

Part Number:

76650-0177

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

C-Grid III Connector Kit

Single Row Vertical Header and Receptacle

C-Grid III™

(Molex Parts within this kit) - EU RoHS Compliant

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire Size:

Product Highlights

The 3rd generation C-Grid III 2.54mm (.100") pitch post and receptacle

interconnection system offers complete design flexibility and modular components

that provide the widest range of electronic packaging alternatives. C-Grid III is a

highly-versatile 2.54mm interconnection system offering unique design features:

Surface Treatment (platings), Flexibility, Advantage by Design (same mating

concept with all termination techniques), Interchangeability (fully compatible with the

industry standard DIN41651 as well as the French norm HE-13/14), and Lower

Applied Cost.

Wire-to-Board

2.54mm (.100")

Receptacles and Headers

Vertical

2, 3, 4, 5, 6 and 8

3 Amps

350 Volts

24-22 AWG

Features and Benefits

Applications

For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com

Page 1 of 3
