ALUMINUM ELECTROLYTIC CAPACITORS
PM
Extremely Low Impedance, High Reliability
series
(through 100V only)
High reliability withstanding 5000hour load life at +105
°C
(3000/2000hours
for smaller case sizes as specified below).
Capacitance ranges available based on the numerical values in E12 series
under JIS.
PM
Smaller
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
PW
Performance Characteristics
– 55 ~ +105°C (6.3 ~ 100V), –40 ~ +105°C (160 ~ 400V), –25 ~ +105°C (450V)
6.3 ~ 450V
0.47 ~ 15000µF
± 20% at 120Hz, 20°C
Rated Voltage (V)
6.3 ~ 100
Leakage current
160 ~ 450
After 1 minute's application of rated voltage, leakage current is not more CV < 1000 :
I
= 0.1CV+40 (µA) max. (1 minute's)
=
than 0.03CV or 4 (µA), whichever is greater.
CV > 1000 :
I
= 0.04CV+100 (µA) max. (1 minute's)
Measurement frequency : 120Hz, Temperature : 20°C
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
tan
δ
Rated Voltage (V)
tan
δ
(MAX.)
6.3
0.22
10
0.19
6.3 · 10
—
—
4
16
0.16
16
—
—
3
25
0.14
25 · 35
—
—
3
35
0.12
50
0.10
63 ~ 100
0.08
250
—
6
—
160 ~ 350 400 · 450
0.20
0.25
400
—
10
—
450
15
—
—
120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance
Z– 40°C / Z+20°C
ratio
Z– 55°C / Z+20°C
50~100 160~200
—
—
4
—
—
2
315~350
—
8
—
Endurance
After an application of D.C. bias voltage plus the rated ripple
current for 5000 hours (2000 hours for D = 5 and 6.3,
3000 hours for D=8) at 105°C the peak voltage shall not
exceed the rated D.C. voltage, capacitors meet the
characteristic requirements listed at right.
After leaving capacitors under no load at 105°C
for 1000 hours, they meet the characteristic
requirements listed at right.
Printed with white color letter on dark brown sleeve.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Within ±20% of initial value
150% or less of initial specified value
Initial specified value or less
Shelf Life
Marking
Capacitance change
tan
δ
Leakage current
Radial Lead Type
Sleeve (P.E.T.)
Type numbering system (Example : 25V 470
µ
F)
1
2
3
4
5
6
7
8
9 10
11 12
φ
d
UPM 1 E 4 7 1 M HD
Size code
Configuration
Type
Small Dia
Low Profile
Code
6
Capacitance tolerance (± 20%)
P
±
0.5
φD
+
0.5 MAX
Rated Capacitance (470µF)
Rated voltage (25V)
Series name
Pressure
relief vent
(φ6.3up)
Type
L+
MAX
15
MIN
4
MIN
Configuration
φ
D
Pb-free leadwire
Pb-free PET sleeve
Sn-Pb finished leadwire
PVC sleeve (containing Pb)
(φD < 10) 1.5
(φD > 10) 2.0
=
(mm)
5
6.3
8 · 10
12.5 ~ 18
DD
ED
PD
HD
DH
EH
PH
HH
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
●
Please contact to us if other configurations are required.
In case L > 25 for the
φ12.5
dia. unit, lead dia.
φ
d = 0.8mm.
Frequency coefficient of
Rated voltage
Rated voltage
rated ripple current
Frequency coefficient
15000
10000
15000
6800
10000
4700
6800
Frequency coefficient
4700
3300
2200
1500
3300
2200
1500
1000
680
1000
470
680
330
6.3~100V
(10kHz~
200kHz=1)
6.3~100V
470
220
150
330
Cap.(
µ
F)
100
220
(10kHz~
200kHz=1)
150
100
68
47
68
47
33
120Hz
22
15
300Hz
1kHz
Cap.(
µ
F)
33
10
22
0.68
120Hz
300Hz
1kHz
Please refer to page 19, 20, 21 about the formed or taped product spec.
Please refer to page 3 for the minimum order quantity.
15
0.47
10
0.68
0
0.5
0.6
0.7
0.8
Frequency coefficient
0.9
1.0
Dimension table in next page.
160~450V
50Hz
0.47
0.80
0
120Hz
1.00
0.5
100Hz
1.25
0.7
11kHz
0.8
1.40
0.9
110kHz~
1.60
1.0
0.6
Frequency coefficient
CAT.8100T-1
