ALUMINUM ELECTROLYTIC CAPACITORS
PM
Extremely Low Impedance, High Reliability
series
(through 100V only)
High reliability withstanding 5000hour load life at +105
°C
(3000/2000hours
for smaller case sizes as specified below).
Capacitance ranges available based on the numerical values in E12 series
under JIS.
PM
Smaller
PW
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Performance Characteristics
– 55 ~ +105°C (6.3 ~ 100V), –40 ~ +105°C (160 ~ 400V), –25 ~ +105°C (450V)
6.3 ~ 450V
0.47 ~ 15000µF
± 20% at 120Hz, 20°C
Rated Voltage (V)
6.3 ~ 100
Leakage current
160 ~ 450
After 1 minute's application of rated voltage, leakage current is not more CV < 1000 :
I
= 0.1CV+40 (µA) max. (1 minute's)
=
than 0.03CV or 4 (µA), whichever is greater.
CV > 1000 :
I
= 0.04CV+100 (µA) max. (1 minute's)
Measurement frequency : 120Hz, Temperature : 20°C
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
tan
δ
Rated Voltage (V)
tan
δ
(MAX.)
6.3
0.22
10
0.19
6.3 · 10
4
—
—
16
0.16
16
3
—
—
25
0.14
25 · 35
3
—
—
35
0.12
50
0.10
63 ~ 100
0.08
250
—
6
—
160 ~ 350 400 · 450
0.20
0.25
400
—
10
—
450
—
—
15
120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 55°C / Z+20°C
Impedance
Z– 40°C / Z+20°C
ratio
Z– 25°C / Z+20°C
50~100 160~200
—
2
4
—
—
—
315~350
—
8
—
Endurance
After an application of D.C. bias voltage plus the rated ripple
current for 5000 hours (2000 hours for D = 5 and 6.3,
3000 hours for D=8) at 105°C the peak voltage shall not
exceed the rated D.C. voltage, capacitors meet the
characteristic requirements listed at right.
After leaving capacitors under no load at 105°C
for 1000 hours, they meet the characteristic
requirements listed at right.
Printed with white color letter on dark brown sleeve.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Within ±20% of initial value
150% or less of initial specified value
Initial specified value or less
Shelf Life
Marking
Capacitance change
tan
δ
Leakage current
Radial Lead Type
Sleeve
Type numbering system (Example : 25V 470
µ
F
φ12.5 ×
15)
φ
d
1
2
3
4
5
6
7
8
9 10
11 12
UPM 1 E 4 7 1 M HH 6
Case size code
Configuration
P
±
0.5
φD
+
0.5 MAX
Type
Small Dia
Low Profile
Code
6
Capacitance tolerance (± 20%)
Rated Capacitance (470µF)
Rated voltage (25V)
φ
D
5
6.3
Code
DH
EH
PH
HH
Pressure
relief vent
(φ6.3UP)
8 · 10
Series name 12.5 ~ 18
Type
L+
MAX
15
MIN
4
MIN
(φD < 10) 1.5
(φD > 10) 2.0
=
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
•
The PET sleeve product is also available upon request.
In this case, T will be put at
voltage
of type numbering system.
Rated
11th digit
Frequency coefficient
Frequency coefficient of
rated ripple current
Rated voltage
15000
10000
6800
4700
15000
10000
6800
Frequency coefficient
In case L > 25 for the
φ12.5
dia. unit, lead dia.
φ
d = 0.8mm.
3300
4700
2200
3300
1500
2200
1500
1000
1000
680
470
330
680
470
330
6.3~100V
6.3~100V
220
150
Cap.(
µ
F)
Cap.(
µ
F)
(10kHz~
(10kHz~
200kHz=1)
200kHz=1)
220
150
100
100
68
68
47
47
33
33
22
22
15
10
15
10
120Hz
120Hz
300Hz
300Hz
1kHz
1kHz
0.68
0.68
0.47
0.47
0
0.5
Please refer to page 18, 19, 20 about the formed or taped product spec.
Please refer to page 3 for the minimum order quantity.
160~450V
0
0.5
0.6
0.7
0.8
Frequency coefficient
0.8
0.6
0.7
0.9
1.0
0.9
1.0
Frequency coefficient
50Hz
120Hz
100Hz
11kHz
110kHz~
Dimension table in next page.
160~450V
50Hz
0.80
0.80
120Hz
1.00
1.00
100Hz
1.25
1.25
11kHz
1.40
1.40
110kHz~
1.60
1.60
CAT.8100R
