ATTENUATORS
Type N, with mounting holes, DC - 18 GHz, 20 Watts
SPECIFICATIONS:
Models: 2100-XX dB
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values
Attenuation Accuracy
3 & 6 dB
10 & 20 dB
30 & 40 dB
VSWR
DC - 1 GHz
2.4
1
2.4 - 18 GHz
Input Power
Peak Power
Impedance
Operating Temp Range
DC - 18 GHz
18 GHz
0, 3, 6, 10, 20, 30 & 40 dB
DC - 1 GHz
2.4
1
2.4 - 18 GHz
±0.5 dB
±0.75 dB
±0.75 dB
±1.00 dB
±1.00 dB
±1.50 dB
1.30:1 Max.
1.40:1 Max.
20 Watts Avg. @ 40°C
Derated Linearly to 5 Watts @ +1
o
C
25
500 Watts Max.
(5uSec Pulse, .05% Duty Cycle)
50 Ohms
-65°C to +125°C
Passivated Stainless Steel
Gold Plated Beryllium Copper
Black Anodized Aluminum
Connector
Configuration
Male/Female
Male/Male
Female/Female
LENGTH
Inches
Millimeters
[98.3 ±1.27]
3.87 ±.05
[96.27 ±1.27]
3.79 ±.05
[100.33 ±1.27]
3.95 ±.05
Mechanical:
Type N Connectors
Mates with MIL
-STD-348
Conductors
Housing
TYPE N FEMALE
2.29 [58.17]
TYPE N MALE
4-40UNC-2B STAINLESS
STEEL THREADED INSERT
TYPICAL - 4 PLACES
.700
[17.78]
14X Ø.50
[12.7]
.50
[12.7]
1.00
[25.4]
.150
[3.81]
2.000
[50.8]
SEE TABLE
.145 [3.68]
.50
[12.7]
1.00
[25.4]
HOW TO ORDER:
Model Number:
2100-XXY
Connector Configuration
= Male/Female
F = Fem/Fem
M = Male/Male
dB Value
Ordering Examples:
Model Number:
2100-20
DC - 18 GHz; 20 dB; Type N - Male/Fem
Model Number:
2100-06F
DC - 18 GHz; 6 dB; Type N - Fem/Fem
Model Number:
2100-03M
DC - 18 GHz; 3 dB; Type N - Male/Male
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design specifications are subject to change without notice.
Contact factory for technical specifications before purchasing or use.
2100: REV D (M)
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex.com/inmet • inmetsales@aeroflex.com
