SN74LS273FN datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> SN74LS273FN

SN74LS273FN: DescriptionD Flip-Flop, LS Series, 1-Func, Positive Edge Triggered, 8-Bit, True Output, TTL, PQCC20, QCC-20; Categorylogic logic; File Size232KB，5 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

SN74LS273FN Overview

D Flip-Flop, LS Series, 1-Func, Positive Edge Triggered, 8-Bit, True Output, TTL, PQCC20, QCC-20

SN74LS273FN Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
package instruction	QCCJ,
Reach Compliance Code	unknow
series	LS
JESD-30 code	S-PQCC-J20
length	8.9662 mm
Logic integrated circuit type	D FLIP-FLOP
Number of digits	8
Number of functions	1
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature
Output polarity	TRUE
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
propagation delay (tpd)	27 ns
Maximum seat height	4.57 mm
Maximum supply voltage (Vsup)	5.25 V
Minimum supply voltage (Vsup)	4.75 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	TTL
Temperature level	COMMERCIAL
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
Trigger type	POSITIVE EDGE
width	8.9662 mm
minfmax	30 MHz

Preview

Download Datasheet

View All

SN74LS273FN Related Products

	SN74LS273FN	SN74265J4	SN74273J	SN74276J	SN74265J
Description	D Flip-Flop, LS Series, 1-Func, Positive Edge Triggered, 8-Bit, True Output, TTL, PQCC20, QCC-20	AND/NAND Gate	D Flip-Flop, TTL/H/L Series, 1-Func, Positive Edge Triggered, 8-Bit, True Output, TTL, CDIP20, DIP-20	J-Kbar Flip-Flop, TTL/H/L Series, 1-Func, Negative Edge Triggered, 4-Bit, True Output, TTL, CDIP20, DIP-20	AND/NAND Gate, TTL/H/L Series, 2-Func, 2-Input, TTL, CDIP16, DIP-16
Maker	Rochester Electronics	Rochester Electronics	Rochester Electronics	Rochester Electronics	Rochester Electronics
package instruction	QCCJ,	,	DIP,	DIP,	DIP,
Reach Compliance Code	unknow	unknown	unknown	unknown	unknow
Logic integrated circuit type	D FLIP-FLOP	AND/NAND GATE	D FLIP-FLOP	J-KBAR FLIP-FLOP	AND/NAND GATE
series	LS	-	TTL/H/L	TTL/H/L	TTL/H/L
JESD-30 code	S-PQCC-J20	-	R-GDIP-T20	R-GDIP-T20	R-GDIP-T16
length	8.9662 mm	-	24.195 mm	24.195 mm	19.56 mm
Number of digits	8	-	8	4	-
Number of functions	1	-	1	1	2
Number of terminals	20	-	20	20	16
Maximum operating temperature	70 °C	-	70 °C	70 °C	70 °C
Output polarity	TRUE	-	TRUE	TRUE	-
Package body material	PLASTIC/EPOXY	-	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED
encapsulated code	QCCJ	-	DIP	DIP	DIP
Package shape	SQUARE	-	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	CHIP CARRIER	-	IN-LINE	IN-LINE	IN-LINE
propagation delay (tpd)	27 ns	-	27 ns	30 ns	18 ns
Maximum seat height	4.57 mm	-	5.08 mm	5.08 mm	5.08 mm
Maximum supply voltage (Vsup)	5.25 V	-	5.25 V	5.25 V	5.25 V
Minimum supply voltage (Vsup)	4.75 V	-	4.75 V	4.75 V	4.75 V
Nominal supply voltage (Vsup)	5 V	-	5 V	5 V	5 V
surface mount	YES	-	NO	NO	NO
technology	TTL	-	TTL	TTL	TTL
Temperature level	COMMERCIAL	-	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	J BEND	-	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	1.27 mm	-	2.54 mm	2.54 mm	2.54 mm
Terminal location	QUAD	-	DUAL	DUAL	DUAL
Trigger type	POSITIVE EDGE	-	POSITIVE EDGE	NEGATIVE EDGE	-
width	8.9662 mm	-	7.62 mm	7.62 mm	7.62 mm
minfmax	30 MHz	-	30 MHz	35 MHz	-
