UCC3808N-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> UCC3808N-2

UCC3808N-2: Description1A SWITCHING CONTROLLER, 1000kHz SWITCHING FREQ-MAX, PDIP8, GREEN, PLASTIC, DIP-8; CategoryPower/power management The power supply circuit; File Size1022KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

UCC3808N-2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	UCC3808N-2	-	-	View	Buy Now

UCC3808N-2 Overview

1A SWITCHING CONTROLLER, 1000kHz SWITCHING FREQ-MAX, PDIP8, GREEN, PLASTIC, DIP-8

UCC3808N-2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	GREEN, PLASTIC, DIP-8
Contacts	8
Reach Compliance Code	unknow
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	13 V
Minimum input voltage	4.3 V
Nominal input voltage	10 V
JESD-30 code	R-PDIP-T8
JESD-609 code	e4
length	9.81 mm
Humidity sensitivity level	NOT SPECIFIED
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum seat height	5.08 mm
surface mount	NO
Switch configuration	PUSH-PULL
Maximum switching frequency	1000 kHz
technology	BICMOS
Temperature level	COMMERCIAL
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm
