LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
AXF
AXF
SERIES
105¡C Low profile, Snap-in Terminal Type
♦
FEATURES
•
Load Life : 105°C 3000 hours, with 20mm height.
•
Smaller size with higher ripple current endurance than MXF series.
♦
SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Ι=3
CV
Leakage Current(MAX)
Characteristics
-40~+105°C
10~100V.DC
±20%(20°C,
120Hz)
(After 5 minutes application of rated voltage)
-25~+105°C
160~450V.DC
Ι=
Leakage Current
(µA)
V=
Rated Voltage
(V)
C=
Rated Capacitance
(µF)
(20°C, 120Hz)
Dissipation Factor(MAX)
Rated Voltage
10 16 25 35 50 63 80 100 160~ 420~
(V)
400 450
tan
δ
0.55 0.50 0.45 0.40 0.35 0.30 0.25 0.20 0.15 0.20
Rated Voltage
(V)
Z(-25°C)/Z(20°C)
Z(-40°C)/Z(20°C)
10~100
3
12
160~250
3
-
315~450
8
-
(120Hz)
Impedance Ratio(MAX)
After applying rated voltage with rated ripple current for 3000hrs at 105°C, the capacitors shall meet the following requirements.
Capacitance Change
Endurance
Dissipation Factor
Leakage Current
Not more than 200% of the specified value.
Not more than the specified value.
Within
±20%
of the initial value.
♦
EXPLANATION
AXF
Rated Voltage
Series
OF PART NUMBER
DxL
Rated Capacitance
Capacitance Tolerance
Option
Terminal Code
Case Size
♦
Terminal
Code
Code
Standard Terminal
Short Terminal
Blank
ST
(mm)
•
Short terminal type
♦
DIMENSIONS
•
Standard terminal type
SLEEVE
VENT
2-ø2
NEGATIVE
10
10
±0.1
VENT
SLEEVE
2-ø2
NEGATIVE
10
10
±0.1
L±2
6±1
øD±1
øD±1
MOUNTING HOLES
L±2
∗
4±0.5
∗For
ø35, 3.5±0.5
øD±1
øD±1
MOUNTING HOLES
LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
AXF
♦
STANDARD SIZE, RATED RIPPLE CURRENT
WV
Cap(µF)
10
16
25
35
50
63
80
100
20x20 0.60
20x20 0.71
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
WV
Cap(µF)
20x20 0.65 22x20 0.78
20x20 0.70 25x20 0.95
20x20 0.83 22x20 0.84 25x20 1.09
22x20 0.99 25x20 1.04 30x20 1.32
20x20 0.87 22x20 1.10 25x20 1.19
22x20 1.02 25x20 1.20 30x20 1.44
20x20 0.80 25x20 1.15 30x20 1.47
22x20 0.94 25x20 1.34 30x20 1.52
20x20 0.98 22x20 1.04 30x20 1.60
22x20 1.08 25x20 1.29
20x20 1.06 22x20 1.29 30x20 1.45
20x20 1.25 25x20 1.58
20x20 0.98 22x20 1.38 25x20 1.61
20x20 1.16 25x20 1.68
22x20 1.31 25x20 1.80
25x20 1.59
25x20 1.77
160
180
200
220
250
315
350
385
20x20 0.35
20x20 0.38 20x20 0.38
20x20 0.41 20x20 0.40 22x20 0.42
22x20 0.48 22x20 0.45 25x20 0.50
22x20 0.51 25x20 0.54 25x20 0.52
20x20 0.59 25x20 0.57 25x20 0.57 30x20 0.61
20x20 0.63 20x20 0.60 22x20 0.65 30x20 0.65 30x20 0.65 30x20 0.64
20x20 0.66 20x20 0.66 22x20 0.70 25x20 0.74 30x20 0.70 35x20 0.78 35x20 0.80
20x20 0.69 22x20 0.80 22x20 0.80 25x20 0.80 25x20 0.77 35x20 0.85 35x20 0.85
22x20 0.81 25x20 0.90 25x20 0.87 25x20 0.85 30x20 0.95 35x20 0.90
25x20 0.98 25x20 0.95 25x20 0.95 30x20 1.02 30x20 1.00
25x20 1.02 30x20 1.15 30x20 1.15 30x20 1.12 35x20 1.16
30x20 1.25 30x20 1.20 30x20 1.20 35x20 1.25
30x20 1.30 35x20 1.36 35x20 1.41
35x20 1.46 35x20 1.43
35x20 1.51
400
420
450
20x20 0.26
20x20 0.30 20x20 0.30
20x20 0.34 20x20 0.34 22x20 0.36
22x20 0.39 22x20 0.38 25x20 0.41
22x20 0.40 25x20 0.45 25x20 0.43
25x20 0.49 25x20 0.48 30x20 0.50
30x20 0.55 30x20 0.53 30x20 0.53
30x20 0.60 30x20 0.58 35x20 0.61
35x20 0.75 35x20 0.70
35x20 0.80
Ripple Current A r.m.s./120Hz·105°C
Case Size øD
±1
xL
±2
(mm)
Coefficient
Ambient Temperature
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
WV
Cap(µF)
♦
MULTIPLIER FOR RIPPLE CURRENT
(1)Temperature coefficient
(°C)
105
1.0
85
1.7
65>
=
2.1
27
33
39
47
56
68
82
100
120
150
(2)Frequency coefficient
Frequency
60(50) 120
(Hz)
10~100WV 0.90 1.00
160~250WV
315~450WV
0.80
0.80
1.00
1.00
500
1.05
1.20
1.20
1k
1.10
1.30
1.25
10k<
=
1.15
1.50
1.40
Coefficient
