BZX85C3V3RL Series
1 Watt DO-41 Hermetically
Sealed Glass Zener Voltage
Regulators
This is a complete series of 1 Watt Zener diodes with limits and
excellent operating characteristics that reflect the superior capabilities
of silicon–oxide passivated junctions. All this in an axial–lead
hermetically sealed glass package that offers protection in all common
environmental conditions.
Specification Features:
http://onsemi.com
Cathode
Anode
•
•
•
•
•
•
Zener Voltage Range – 3.3 V to 85 V
ESD Rating of Class 3 (>16 KV) per Human Body Model
DO–41 (DO–204AL) Package
Double Slug Type Construction
Metallurgical Bonded Construction
Oxide Passivated Die
Mechanical Characteristics:
CASE:
Double slug type, hermetically sealed glass
FINISH:
All external surfaces are corrosion resistant and leads are
AXIAL LEAD
CASE 59
GLASS
MARKING DIAGRAM
L
BZX
85C
xxx
YWW
readily solderable
MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:
230°C, 1/16″ from the case for 10 seconds
POLARITY:
Cathode indicated by polarity band
MOUNTING POSITION:
Any
MAXIMUM RATINGS
Rating
Max. Steady State Power Dissipation
@ T
L
≤
50°C, Lead Length = 3/8″
Derate above 50°C
Operating and Storage
Temperature Range
Symbol
P
D
Value
1
6.67
T
J
, T
stg
–65 to
+200
Unit
W
mW/°C
°C
L
= Assembly Location
BZX85Cxxx = Device Code
=
(See Table Next Page)
Y
= Year
WW
= Work Week
ORDERING INFORMATION
Device
BZX85CxxxRL
BZX85CxxxRL2
Package
Axial Lead
Axial Lead
Shipping
6000/Tape & Reel
6000/Tape & Reel
* The “2” suffix refers to 26 mm tape spacing.
©
Semiconductor Components Industries, LLC, 2002
1
February, 2002 – Rev. 1
Publication Order Number:
BZX85C3V3RL/D
BZX85C3V3RL Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless
otherwise noted, V
F
= 1.2 V Max., I
F
= 200 mA for all types)
Symbol
V
Z
I
ZT
Z
ZT
I
ZK
Z
ZK
I
R
V
R
I
F
V
F
I
R
Parameter
Reverse Zener Voltage @ I
ZT
Reverse Current
Maximum Zener Impedance @ I
ZT
Reverse Current
Maximum Zener Impedance @ I
ZK
Reverse Leakage Current @ V
R
Breakdown Voltage
Forward Current
Forward Voltage @ I
F
Surge Current @ T
A
= 25°C
V
Z
V
R
I
R
V
F
I
ZT
V
I
F
I
Zener Voltage Regulator
http://onsemi.com
2
BZX85C3V3RL Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted, V
F
= 1.2 V Max., I
F
= 200 mA for all types)
Zener Voltage
(Notes 2 and 3)
Device
(Note 1)
BZX85C3V3RL
BZX85C3V6RL
BZX85C3V9RL
BZX85C4V3RL
BZX85C4V7RL
BZX85C5V1RL
BZX85C5V6RL
BZX85C6V2RL
BZX85C6V8RL
BZX85C7V5RL
BZX85C8V2RL
BZX85C9V1RL
BZX85C10RL
BZX85C12RL
BZX85C13RL
BZX85C15RL
BZX85C16RL
BZX85C18RL
BZX85C22RL
BZX85C24RL
BZX85C27RL
BZX85C30RL
BZX85C33RL
BZX85C36RL
BZX85C43RL
BZX85C47RL
BZX85C62RL
BZX85C75RL
BZX85C82RL
Device
Marking
BZX85C3V3
BZX85C3V6
BZX85C3V9
BZX85C4V3
BZX85C4V7
BZX85C5V1
BZX85C5V6
BZX85C6V2
BZX85C6V8
BZX85C7V5
BZX85C8V2
BZX85C9V1
BZX85C10
BZX85C12
BZX85C13
BZX85C15
BZX85C16
BZX85C18
BZX85C22
BZX85C24
BZX85C27
BZX85C30
BZX85C33
BZX85C36
BZX85C43
BZX85C47
BZX85C62
BZX85C75
BZX85C82
V
Z
(Volts)
Min
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
11.4
12.4
13.8
15.3
16.8
20.8
22.8
25.1
28
31
34
40
44
58
70
77
Nom
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.45
8.2
9.05
10
12.05
13.25
14.7
16.2
17.95
22.05
24.2
27
30
33
36
43
47
62
75
82
Max
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
12.7
14.1
15.6
17.1
19.1
23.3
25.6
28.9
32
35
38
46
50
66
80
87
@ I
ZT
mA
80
60
60
50
45
45
45
35
35
35
25
25
25
20
20
15
15
15
10
10
8
8
8
8
6
4
4
4
2.7
Zener Impedance
(Note 4)
Z
ZT
@ I
ZT
W
20
15
15
13
13
10
7
4
3.5
3
5
5
7
9
10
15
15
20
25
25
30
30
35
40
50
90
125
150
200
Z
ZK
@ I
ZK
W
400
500
500
500
600
500
400
300
300
200
200
200
200
350
400
500
500
500
600
600
750
1000
1000
1000
1000
1500
2000
2000
3000
mA
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Leakage Current
I
R
@ V
R
µA
Max
1
1
1
1
1.5
2
2
3
4
4.5
5
6.5
7
8.4
9.1
10.5
11
12.5
15.5
17
19
21
23
25
30
33
43
51
56
Volts
60
30
5
3
3
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
I
R
(Note 5)
mA
1380
1260
1190
1070
970
890
810
730
660
605
550
500
454
380
344
304
285
250
205
190
170
150
135
125
110
95
70
60
55
1.
TOLERANCE AND TYPE NUMBER DESIGNATION
The type numbers listed have zener voltage min/max limits as shown and have a standard tolerance on the nominal zener voltage of
±5%.
2.
AVAILABILITY OF SPECIAL DIODES
For detailed information on price, availability and delivery of nominal zener voltages between the voltages shown and tighter voltage
tolerances, contact your nearest ON Semiconductor representative.
3.
ZENER VOLTAGE (V
Z
) MEASUREMENT
V
Z
measured after the test current has been applied to 40
±10
msec, while maintaining the lead temperature (T
L
) at 30°C
±1°C,
3/8″ from
the diode body.
4.
ZENER IMPEDANCE (Z
Z
) DERIVATION
The zener impedance is derived from 1 kHz cycle AC voltage, which results when an AC current having an rms value equal to 10% of the
DC zener current (I
ZT
or I
ZK
) is superimposed on I
ZT
or I
ZK
.
5.
SURGE CURRENT (I
R
) NON–REPETITIVE
The rating listed in the electrical characteristics table is maximum peak, non–repetitive, reverse surge current of 1/2 square wave or eqivalent
sine wave pulse of 1/120 second duration superimposed on the test current, I
ZT
. However, actual device capability is as described in Figure
5 of the General Data – DO–41 Glass.
http://onsemi.com
3
BZX85C3V3RL Series
P
D
, STEADY STATE POWER DISSIPATION (WATTS)
1.25
1
0.75
0.5
0.25
L = 1″
L = 1/8″
L = 3/8″
L = LEAD LENGTH
TO HEAT SINK
0
20
40
60
80 100 120 140
T
L
, LEAD TEMPERATURE (°C)
160
180
200
Figure 1. Power Temperature Derating Curve
http://onsemi.com
4
BZX85C3V3RL Series
a. Range for Units to 12 Volts
θV
Z , TEMPERATURE COEFFICIENT (mV/°C)
θV
Z , TEMPERATURE COEFFICIENT (mV/°C)
+12
+10
+8
+6
+4
+2
0
-2
-4
2
3
4
5
6
7
8
9
V
Z
, ZENER VOLTAGE (VOLTS)
10
11
12
RANGE
V
Z
@ I
ZT
100
70
50
30
20
10
7
5
3
2
1
10
20
30
50
V
Z
, ZENER VOLTAGE (VOLTS)
70
100
RANGE
V
Z
@ I
ZT
b. Range for Units to 12 to 100 Volts
Figure 2. Temperature Coefficients
(–55°C to +150°C temperature range; 90% of the units are in the ranges indicated.)
θ
JL , JUNCTION TO LEAD THERMAL RESISTANCE (mV/°C/W)
150
125
100
75
50
25
0
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
θV
Z , TEMPERATURE COEFFICIENT (mV/°C)
175
+6
+4
+2
0
-2
-4
V
Z
@ I
Z
T
A
= 25°C
20 mA
0.01 mA
1 mA
NOTE: BELOW 3 VOLTS AND ABOVE 8 VOLTS
NOTE:
CHANGES IN ZENER CURRENT DO NOT
NOTE:
EFFECT TEMPERATURE COEFFICIENTS
3
4
5
6
7
8
V
Z
, ZENER VOLTAGE (VOLTS)
L, LEAD LENGTH TO HEAT SINK (INCHES)
Figure 3. Typical Thermal Resistance
versus Lead Length
100
70
50
30
20
10
7
5
3
2
1
0.01
10% DUTY CYCLE
20% DUTY CYCLE
5% DUTY CYCLE
Figure 4. Effect of Zener Current
Ppk , PEAK SURGE POWER (WATTS)
11 V-100 V NONREPETITIVE
3.3 V-10 V NONREPETITIVE
RECTANGULAR
WAVEFORM
T
J
= 25°C PRIOR TO
INITIAL PULSE
0.02
0.05
0.1
0.2
0.5
This graph represents 90 percentile data points.
For worst case design characteristics, multiply surge power by 2/3.
1
2
5
PW, PULSE WIDTH (ms)
10
20
50
100
200
500
1000
Figure 5. Maximum Surge Power
http://onsemi.com
5
