AP09N20BGP-HF
Halogen-Free Product
Advanced Power
Electronics Corp.
▼
Simple Drive Requirement
▼
Lower Gate Charge
▼
Fast Switching Characteristics
▼
RoHS Compliant & Halogen-Free
G
S
N-CHANNEL ENHANCEMENT MODE
POWER MOSFET
D
BV
DSS
R
DS(ON)
I
D
200V
460mΩ
7.8A
Description
Advanced Power MOSFETs from APEC provide the
designer with the best combination of fast switching,
ruggedized device design, low on-resistance and cost-effectiveness.
The TO-220 package is widely preferred for commercial-industrial
through-hole applications.
G
D
S
TO-220(P)
Absolute Maximum Ratings
Symbol
V
DS
V
GS
I
D
@T
C
=25℃
I
D
@T
C
=100℃
I
DM
P
D
@T
C
=25℃
T
STG
T
J
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
1
Rating
200
+20
7.8
5
20
69
-55 to 150
-55 to 150
Units
V
V
A
A
A
W
℃
℃
Total Power Dissipation
Storage Temperature Range
Operating Junction Temperature Range
Thermal Data
Symbol
Rthj-c
Rthj-a
Parameter
Maximum Thermal Resistance, Junction-case
Maximum Thermal Resistance, Junction-ambient
Value
1.8
62
Unit
℃/W
℃/W
1
201005131
Data & specifications subject to change without notice
AP09N20BGP-HF
Electrical Characteristics@T
j
=25 C(unless otherwise specified)
Symbol
BV
DSS
R
DS(ON)
V
GS(th)
g
fs
I
DSS
I
GSS
Q
g
Q
gs
Q
gd
t
d(on)
t
r
t
d(off)
t
f
C
iss
C
oss
C
rss
Parameter
Drain-Source Breakdown Voltage
Static Drain-Source On-Resistance
2
Gate Threshold Voltage
Forward Transconductance
Drain-Source Leakage Current
Gate-Source Leakage
Total Gate Charge
2
Gate-Source Charge
Gate-Drain ("Miller") Charge
Turn-on Delay Time
2
Rise Time
Turn-off Delay Time
Fall Time
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Test Conditions
V
GS
=0V, I
D
=250uA
V
GS
=10V, I
D
=5A
V
GS
=4.5V, I
D
=3A
V
DS
=V
GS
, I
D
=250uA
V
DS
=10V, I
D
=5A
V
DS
=160V, V
GS
=0V
V
GS
= +20V, V
DS
=0V
I
D
=5A
V
DS
=160V
V
GS
=4.5V
V
DD
=100V
I
D
=5A
R
G
=3.3Ω
V
GS
=10V
V
GS
=0V
V
DS
=25V
f=1.0MHz
Min.
200
-
-
1
-
-
-
-
-
-
-
-
-
-
-
-
-
Typ.
-
-
-
-
9
-
-
21
2
14
6
9
39
10
630
90
45
Max. Units
-
460
500
3
-
25
+100
33.6
-
-
-
-
-
-
1000
-
-
V
mΩ
mΩ
V
S
uA
nA
nC
nC
nC
ns
ns
ns
ns
pF
pF
pF
o
Source-Drain Diode
Symbol
V
SD
t
rr
Q
rr
Notes:
1.Pulse width limited by Max. junction temperature.
2.Pulse test
Parameter
Forward On Voltage
2
2
Test Conditions
I
S
=5A, V
GS
=0V
I
S
=5A, V
GS
=0V,
dI/dt=100A/µs
Min.
-
-
-
Typ.
-
190
1.7
Max. Units
1.3
-
-
V
ns
uC
Reverse Recovery Time
Reverse Recovery Charge
THIS PRODUCT IS SENSITIVE TO ELECTROSTATIC DISCHARGE, PLEASE HANDLE WITH CAUTION.
USE OF THIS PRODUCT AS A CRITICAL COMPONENT IN LIFE SUPPORT OR OTHER SIMILAR SYSTEMS IS NOT AUTHORIZED.
APEC DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED
HEREIN; NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.
APEC RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN.
2
AP09N20BGP-HF
20
16
T
C
= 25
o
C
16
I
D
, Drain Current (A)
I
D
, Drain Current (A)
10V
7.0V
6.0V
5.0V
V
G
=4.5V
T
C
=150 C
12
o
10V
7.0V
6.0V
5.0V
V
GS
=4.5V
12
8
8
4
4
0
0
8
16
24
32
0
0
8
16
24
32
V
DS
, Drain-to-Source Voltage (V)
V
DS
, Drain-to-Source Voltage (V)
Fig 1. Typical Output Characteristics
Fig 2. Typical Output Characteristics
1.6
2.8
2.4
1.4
I
D
=5A
V
GS
=10V
Normalized BV
DSS
(V)
Normalized R
DS(ON)
-50
0
50
100
150
2
1.2
1.6
1.2
1
0.8
0.8
0.4
0.6
0
-50
0
50
100
150
T
j
, Junction Temperature ( C)
o
T
j
, Junction Temperature (
o
C )
Fig 3. Normalized BV
DSS
v.s. Junction
Temperature
8
Fig 4. Normalized On-Resistance
v.s. Junction Temperature
1.4
1.2
6
Normalized V
GS(th)
(V)
I
S
(A)
1
4
T
j
=150
o
C
2
T
j
=25
o
C
0.8
0.6
0
0.4
0
0.2
0.4
0.6
0.8
1
1.2
1.4
-50
0
50
100
150
V
SD
, Source-to-Drain Voltage (V)
T
j
, Junction Temperature ( C )
o
Fig 5. Forward Characteristic of
Reverse Diode
Fig 6. Gate Threshold Voltage v.s.
Junction Temperature
3
AP09N20BGP-HF
10
1000
f=1.0MHz
I
D
=5A
V
DS
=160V
V
GS
, Gate to Source Voltage (V)
8
800
4
C (pF)
6
600
C
iss
400
2
200
C
oss
C
rss
0
0
10
20
30
40
50
0
1
5
9
13
17
21
25
29
Q
G
, Total Gate Charge (nC)
V
DS
, Drain-to-Source Voltage (V)
Fig 7. Gate Charge Characteristics
Fig 8. Typical Capacitance Characteristics
100
1
10
Operation in this area
limited by R
DS(ON)
100us
Normalized Thermal Response (R
thjc
)
Duty factor=0.5
0.2
I
D
(A)
0.1
0.1
0.05
1ms
1
P
DM
0.02
T
c
=25
o
C
Single Pulse
0
0.1
1
10
100
10ms
100ms
1s
DC
1000
t
T
0.01
Duty factor = t/T
Peak T
j
= P
DM
x R
thjc
+ T
C
Single Pulse
0.01
0.00001
0.0001
0.001
0.01
0.1
1
10
V
DS
, Drain-to-Source Voltage (V)
t , Pulse Width (s)
Fig 9. Maximum Safe Operating Area
Fig10. Effective Transient Thermal Impedance
V
DS
90%
V
G
Q
G
4.5V
Q
GS
Q
GD
10%
V
GS
t
d(on)
t
r
t
d(off)
t
f
Charge
Q
Fig 11. Switching Time Waveform
Fig 12. Gate Charge Waveform
4
