70 MHz Bandpass SAW Filter
70 MHz Bandpass SAW Filter
36 MHz Bandwidth
Specifications
Parameter
Center Frequency at 25°C
Insertion Loss at fc
1 dB Bandwidth
3 dB Bandwidth
40dB Bandwidth
Passband Variation
Phase Linearity
Group Delay Variation
Absolute Delay
Ultimate Rejection
Substrate Material
Ambient Temperature
Operating Temperature Range
Sym
fc
IL
BW
1
BW
3
BW
40
-
-
-
-
-
-
Ta
To
Minimum
69.8
-
32.7
36.0
-
-
-
-
-
50
-
-
-55
Typical
70
24.1
33.8
37.4
51.3
0.3
5.0
15
2
55
128-LiNbO
3
25
25
Maximum
70.2
25.0
-
-
55.5
1.3
8.0
30
-
-
-
-
85
Unit
MHz
dB
MHz
MHz
MHz
dB
Deg
nsec
µsec
dB
-
°C
°C
BP60030
Typical Performance
Package Outline
Matching Configuration
No Matching Required
Nominal Source/Load Impedance : 50
Ω
