BTE4000 / PTU4000 Series
Pressure transmitters
FEATURES
· 0...-1 to 0...10 bar absolute or gage
1
,
0...-15 to 0...150 psi gage
1
· 0...5 V, 0...10 V, 1...6 V, 4...20 mA output
· Field interchangeable
· Rugged aluminium housing
MEDIA COMPATIBILITY
Wetted materials:
aluminium, silicon, glass
Housing:
Aluminium, protection class IP 65 (according to
DIN EN 60529) respectively NEMA 4
1
SPECIFICATIONS
9,10
Maximum ratings
ELECTRICAL CONNECTION
0...5 V, 0...10 V, 1...6 V output
Supply voltage (reverse polarity protection)
BTE(M)/PTU4...0, ...1, ...7
BTE(M)/PTU4...4
Maximum load current
BTE(M)/PTU4...0, ...1, ...7
Temperature limits
Storage
Operating
Compensated
Humidity limits
Vibration (5 to 500 Hz)
Mechanical shock
Proof pressure
3
BTEM4.../PTU4x01..., 05...
BTE4010.../PTU4150...
all others
2
13...30 V
12...36 V
+Vs
sensor
1
Vout
3
-Vs
2
13 ... 30 V
10 mA
-55 to 100°C
-40 to 100°C
0 to 50°C
0 - 100 %RH
2g
50 g
V
GND
4...20 mA output
+Vs
1
N/C
3
-Vs
2
12 ... 36 V
V
sensor
1.4 bar / 20 psi
16 bar / 200 psi
2 x rated pressure
R
L
GND
December 2008 / 096
1/6
www.sensortechnics.com
BTE4000 / PTU4000 Series
Pressure transmitters
COMMON PERFORMANCE CHARACTERISTICS
(V
S
= 15 V, t
amb
= 25°C)
Characteristics
Operating pressure
BTEM40070..
BTEM4P070..
BTEM4N250..
BTEM40350..
BTEM4N350..
BTEM4P350..
BTE4001..
BTE4N01..
BTE4P01..
BTE4002..
BTE4005..
BTE4010..
PTU4001..
PTU4P01..
PTU4005..
PTU4P05..
PTU4015..
PTU4P015..
PTU4030..
PTU4100..
PTU4150
Offset
Span
Offset
Span
Min.
0
-70
-25
0
-350
-350
0
-1
-1
0
0
0
0
-1
0
-5
0
-15
0
0
0
Typ.
Max.
70
70
0
350
0
350
1
0
1
2
5
10
1
1
5
5
15
15
30
100
150
0.04
0.04
Unit
mbar
bar
p si g
Thermal effects (0 to 50°C)
5
(-20 to 0°C, 50 to 70°C)
5
Non-linearity and hysteresis (BSL)
6
Repeatability
Long term stability
7
Output noise (0 - 1 kHz)
Response time (10 to 90 %)
Power supply rejection
Offset
Span
0.02
0.02
±0.2
±0.10
±0.5
±0.04
1.0
0.05
0.03
%FSO/°C
±0.50
%FS
ms
%/V
December 2008 / 096
2/6
www.sensortechnics.com
BTE4000 / PTU4000 Series
Pressure transmitters
INDIVIDUAL PERFORMANCE CHARACTERISTICS
1
0...10 V output
(V
S
= 15 V, R
L
> 100 kΩ, t
amb
= 25°C)
Characteristics
Zero pressure offset
Full scale span
4
Output impedance
Power consumption (no load)
BTE/PTU4N...
all others
BTE/PTU4N...
all others
Min.
4.85
-0.15
4.9
9.9
Typ.
5.0
0
5.0
10.0
6.0
100
Max.
5.15
0.15
5.1
10.1
50
Unit
V
Ω
mW
0...5 V output
(V
S
= 15 V, R
L
> 100 kΩ, t
amb
= 25°C)
Characteristics
Zero pressure offset
Full scale span
4
Output impedance
Power consumption (no load)
BTE/PTU4N...
all others
BTE/PTU4N...
all others
Min.
2.35
-0.15
2.4
4.9
Typ.
2.5
0
2.5
5.0
6.0
100
Max.
2.65
0.15
2.6
5.1
50
Unit
V
Ω
mW
1...6 V output
(V
S
= 15 V, R
L
> 100 kΩ, t
amb
= 25°C)
Characteristics
Zero pressure offset
Full scale span
4
Output impedance
Power consumption (no load)
BTE/PTU4N...
all others
BTE/PTU4N...
all others
Min.
3.35
0.85
2.4
4.9
Typ.
3.5
1.0
2.5
5.0
6.0
100
Max.
3.65
1.15
2.6
5.1
50
Unit
V
Ω
mW
4...20 mA output
(V
S
= 15 V, R
L
= 100
Ω,
t
amb
= 25°C)
Characteristics
Zero pressure offset
Full scale span
4
Output impedance
Power consumption (I
L
= 20 mA)
BTE/PTU4N...
all others
BTE/PTU4N...
all others
Min.
11.8
3.8
7.9
15.8
Typ.
12.0
4.0
8.0
16.0
0.1
260
Max.
12.2
4.2
8.1
16.2
Unit
mA
Ω
mW
December 2008 / 096
3/6
www.sensortechnics.com
BTE4000 / PTU4000 Series
Pressure transmitters
OUTPUT CHARACTERISTICS
0...5 V output version
10
Vout 9
V
8
7
6
5
4
3
2
1
-100 -80 -60 -40 -20
0 +20 +40 +60 +80 +100 %
operating pressure
all others
BTE/PTU4N...
BTE/PTU4P...
0...10 V output version
10
Vout
V 9
8
7
6
5
4
3
2
1
-100 -80 -60 -40 -20
0 +20 +40 +60 +80 +100 %
operating pressure
BTE/PTU4N...
all others
BTE/PTU4P...
1...6 V output version
10
Vout 9
V
8
7
6
5
4
3
2
1
-100 -80 -60 -40 -20
0 +20 +40 +60 +80 +100 %
operating pressure
all others
BTE/PTU4N...
BTE/PTU4P...
4...20 mA output version
20
Iout 18
mA
16
14
12
10
8
6
4
2
-100 -80 -60 -40 -20
0 +20 +40 +60 +80 +100 %
operating pressure
all others
BTE/PTU4N...
BTE/PTU4P...
LOAD LIMITATION
1200
Ohm
1000
800
600
400
200
operating
range
0
10
20
30 V
Vsupply
December 2008 / 096
4/6
www.sensortechnics.com
BTE4000 / PTU4000 Series
Pressure transmitters
ELECTROMAGNETIC CAPABILITY
8
Test conditions
Criterion Interference
Radiated, radio frequency
EN61000-4-3: Grade 3, 10 V/m, 80 to 1000 MHz
A
<1 %FSO
electromagnetic field immunity (RFI)
80 % AMC (1 kHz)
Electrical fast transient /
EN61000-4-4: Grade 3, ±2 kV
B
<1 %FSO
burst immunity (EFT)
Electrostatic discharge immunity
EN61000-4-2: Grade 4, ±8 kV, contact discharge
B
<1 %FSO
test (ESD)
Immunity to conducted disturbances EN61000-4-6: Grade 3, 0.15 to 80 MHz
A
<1 %FSO
induced by radio-frequency fields
10 V, 80 % AMC (1 kHz)
OUTLINE DRAWING
93.0 (3.66)
12.0
(0.47)
2.0 (0.08)
70.0 (2.76)
10.0
(0.39)
18.0
(0.71)
30.0
(1.18)
14.0
(0.55)
18.0
(0.71)
1
3
2
vent hole
3/8" BSP
(1/4"-18 NPT
for PTU devices)
12.0
(0.47)
PIN
1
2
3
Voltage version
+Vs
-Vs
Vout
ca se
Current version
+Vs
-Vs
N/C
ca se
mass:
typ. 145 g
dimensions in mm (inches)
RECOMMENDED ACCESSORY
Plug
DIN EN 175301-803 A
and profile washer included in delivery.
For a complete connector/cable assembly use order no.
ZK000110-x
(x=cable lenghts in m).
50
34
Profile washer
M3
31
dimensions in mm
Note: For proper function of all gage devices the gage port must be vented to the atmosphere
through the connector/cable assembly.
December 2008 / 096
5/6
www.sensortechnics.com
