BZT03-Series
Vishay Semiconductors
Zener Diodes with Surge Current Specification
Features
•
•
•
•
•
Glass passivated junction
Hermetically sealed package
e2
Clamping time in picoseconds
Lead (Pb)-free component
Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
949539
Applications
Medium power voltage regulators and medium power
transient suppression circuits
Mechanical Data
Case:
SOD-57 Sintered glass case
Weight:
approx. 369 mg
Packaging Codes/Options:
TAP / 5 k Ammopack (52 mm tape) / 25 k/box
TR / 5 k 10" reel
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Power dissipation
Repetitive peak reverse power
dissipation
Non repetitive peak surge power t
p
= 100
µs,
T
j
= 25 °C
dissipation
Junction temperature
Storage temperature range
Test condition
l = 10 mm, T
L
= 25 °C
T
amb
= 25 °C
Symbol
P
V
P
V
P
ZRM
P
ZSM
T
j
T
stg
Value
3.25
1.3
10
600
175
- 65 to + 175
Unit
W
W
W
W
°C
°C
Thermal Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Junction ambient
Test condition
l = 10 mm, T
L
= constant
on PC board with spacing 25 mm
Symbol
R
thJA
R
thJA
Value
46
100
Unit
K/W
K/W
Electrical Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Forward voltage
Test condition
I
F
= 0.5 A
Symbol
V
F
Min
Typ.
Max
1.2
Unit
V
Document Number 85599
Rev. 1.4, 13-Jul-05
www.vishay.com
1
BZT03-Series
Vishay Semiconductors
Typical Characteristics (Tamb = 25
°C
unless otherwise specified)
50
3
I
F
Forward Current (A )
–
3.0
2.5
2.0
T
j
=25°C
1.5
1.0
0.5
0
25
50
7
2
94 9086a
94 9585
0
0.5
1.0
1.5
2.0
V
F
– Forward Voltage ( V )
Figure 1. Epoxy Glass Hard Tissue, Board Thickness 1.5 mm,
R
thJA
≤100
K/W
P
ZSM
– Non-Repetitive Surge Power
Dissipation (W )
Figure 3. Forward Current vs. Forward Voltage
P
tot
–Total Power Dissipation ( W )
4
l=10mm
3
15mm
2
20mm
1
see Fig.1
0
0
40
80
l
l
10000
T
j
=25°C
1000
T
L
=constant
100
120
160
200
94 9586
10
0.01
0.1
1
10
100
94 9584
T
amb
– Ambient T
emperature ( °C )
t
p
– Pulse Length ( ms )
Figure 2. Total Power Dissipation vs. Ambient Temperature
Figure 4. Non Repetitive Surge Power Dissipation vs. Pulse
Length
Package Dimensions in mm (Inches)
Sintered Glass Case
SOD-57
3.6 (0.140)max.
Cathode Identification
ISO Method E
94 9538
0.82 (0.032) max.
26(1.014) min.
4.0 (0.156) max.
26(1.014) min.
www.vishay.com
4
Document Number 85599
Rev. 1.4, 13-Jul-05
