B40C1500G THRU B380C1500G
GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER
Reverse Voltage -
65 to 600 Volts
Forward Current -
1.5 Amperes
Case Style WOG
0.388 (9.86)
0.348 (8.84)
0.220 (5.6)
0.160 (4.1)
FEATURES
♦
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
♦
Glass passivated chip junctions
♦
High case dielectric strength
♦
Typical I
R
less than 0.1µA
♦
High surge current capability
♦
Ideal for printed circuit boards
♦
High temperature soldering guaranteed:
260°C/10 seconds, 0.375" (9.5mm) lead length,
5 lbs. (2.3kg) tension
1.0
(25.4)
MIN.
0.032 (0.81)
0.028 (0.71)
0.060 (1.52)
0.020 (0.51)
0.220 (5.6)
0.348 (8.84)
0.308 (7.82)
0.180 (4.6)
MECHANICAL DATA
0.220 (5.6)
0.180 (4.6)
Dimensions in inches and (millimeters)
Case:
Molded plastic body over passivated junctions
Terminals:
Plated leads solderable per MIL-STD-750,
Method 2026
Mounting Position:
Any
Weight:
0.04 ounce, 1.1 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOLS
B40
C1500G
B80
C1500G
B125
C1500G
B250
C1500G
B380
C1500G
UNITS
Maximum repetitive peak reverse voltage
Maximum RMS input voltage R + C-load
Maximum DC blocking voltage
Maximum peak working voltage
Maximum non-repetitive peak voltage
Maximum repetitive peak forward surge current
Maximum average forward output current for
free air operation at T
A
=45°C R + L-load
C-load
Peak forward surge current single sine wave on
rated load at T
J
=125°C
Rating for fusing at T
J
=125°C (t<100ms)
Min. series resistor C-load at V
RMS
=
±10%
Maximum load capacitance +50%
-10%
Maximum instantaneous forward voltage drop
per leg at 1.5A
Maximum reverse current at rated repetitive
peak voltage per leg T
A
=25°C
Typical thermal resistance
per leg (NOTE 1)
Operating junction temperature range
Storage temperature range
V
RRM
V
RMS
V
DC
V
RWM
V
RSM
I
FRM
I
(AV)
65
40
65
90
100
125
80
125
180
200
200
125
200
300
350
10.0
1.6
1.5
50.0
12.5
400
250
400
600
650
600
380
600
800
1000
Volts
Volts
Volts
Volts
Volts
Amps
Amps
I
FSM
I
2
t
Rt
C
L
V
F
1.0
5000
2.0
2500
Amps
A
2
sec
8.0
500
12.0
200
Ohms
µF
Volts
µA
°C/W
°C
°C
4.0
1000
1.0
I
R
R
ΘJA
R
ΘJL
T
J
T
STG
10.0
36.0
11.0
-40 to +125
-40 to +150
NOTES:
1. Thermal resistance from junction to ambient and from junction to lead mounted on P.C.B. at 0.375" (9.5mm) lead lengths with 0.2 x 0.2"
4/98
RATINGS AND CHARACTERISTICS CURVES B40C1500G THRU B380C1500G
FIG.1 - DERATING CURVES
OUTPUT RECTIFIED CURRENT
FOR B40C1500G...B125C1500G
FIG.2 - DERATING CURVES
OUTPUT RECTIFIED CURRENT
FOR B250C1500G...B380C1500G
1.6
BRIDGE OUTPUT
FULL WAVE RECTIFIED CURRENT
AVERAGE AMPERES
BRIDGE OUTPUT FULL WAVE
RECTIFIED CURRENT AVERAGE
AMPERES
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
20
40
CAPACITIVE
LOAD
< 500µF
500-5000µF
50 to 60 Hz
RESISTIVE OR INDUCTIVE LOAD
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
CAPACITIVE
LOAD
0-10µF
10-100µF
>100µF
50 to 60Hz
RESISTIVE OR
INDUCTIVE LOAD
0.375”
(9.5mm)
P.C.B.
0.375”
(9.5mm)
P.C.B.
COPPER PADS
0.22 x 0.22”
(5.5 x 5.5mm)
COPPER PADS
0.22 x 0.22”
(5.5 x 5.5mm)
60
80
100
120
140
0
20
40
60
80
100
120
140
AMBIENT TEMPERATURE, °C
AMBIENT TEMPERATURE, °C
FIG.3 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT PER LEG
PEAK FORWARD SURGE CURRENT,
AMPERES
FIG. 4 - TYPICAL FORWARD
CHARACTERISTICS PER LEG
50
40
30
20
10
0
1
2
4
6
10
T
A
= 25°C
SINGLE SINE-WAVE
(JEDEC Method)
20
10
INSTANTANEOUS FORWARD CURRENT,
AMPERES
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
1
20
40
60 100
NUMBER OF CYCLES AT 60 Hz
0.1
FIG. 5 - TYPICAL REVERSE CHARACTERISTICS
PER LEG
0.01
0.4
0.6
0.8
1.0
1.2
1.4
10
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
T
J
=100°C
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
FIG. 6 - TYPICAL JUNCTION CAPACITANCE
PER LEG
1
JUNCTION CAPACITANCE, pF
100
T
J
=25°C
f = 1.0 MHz
Vsig = 50mVp-p
0.1
10
T
J
=25°C
0.01
0
20
40
60
80
100
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
1
0.1
1
10
100
REVERSE VOLTAGE, VOLTS
