BA1450S: DescriptionAM radio / FM IF stereo system IC; CategoryAnalog mixed-signal IC Consumption circuit; File Size170KB，10 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA1450S Overview

AM radio / FM IF stereo system IC

BA1450S Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	DIP
package instruction	SDIP-24
Contacts	24
Reach Compliance Code	compli
Commercial integrated circuit types	AUDIO SINGLE CHIP RECEIVER
Demodulation type	AM/FM
harmonic distortion	1.8%
JESD-30 code	R-PDIP-T24
JESD-609 code	e3/e2
length	22.9 mm
Number of functions	1
Number of terminals	24
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Output voltage nominal (AM)	90 mV
Nominal output voltage (FM)	480 mV
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	4.25 mm
Signal-to-noise ratio Nom (FM)	80 dB
Maximum slew rate	29 mA
Maximum supply voltage (Vsup)	8 V
Minimum supply voltage (Vsup)	3.8 V
surface mount	NO
Temperature level	COMMERCIAL EXTENDED
Terminal surface	TIN/TIN COPPER
Terminal form	THROUGH-HOLE
Terminal pitch	1.778 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
width	7.62 mm

Preview

Download Datasheet

View All

Audio ICs

AM radio / FM IF stereo system IC

BA1450S

The BA1450S is a tuner system IC for electronic tuning for AM radios, FM IF, and MPX. It has been developed for Hi-Fi

component applications.

The MPX VCO circuit requires no adjustment, which will enable a reduction in the number of production line processes.

In particular, the laser lock technique used in the VCO means that no external adjustment is required.

FApplications

Synthesized tuner for Hi-Fi components.

FFeatures

1) Built-in AM monaural radio, FM IF amplifier / detector,

and FM stereo demodulator.

2) DTS (both SD and IF count) compatible.

3) Built-in reference voltage power supply provides

good shortwave band frequency stability.

4) Good FM stability.

5) The FM MPX VCO uses laser locking making adjust-

ment and external components unnecessary.

FAbsolute

maximum ratings (Ta = 25_C)

6) Built-in forced monaural operation function for MPX

(VCO stops, and LED goes off).

7) Low cutoff of audio is possible to improve AM fidelity.

8) MPX VCO stops in AM mode.

9) Audio muting is possible when an IF request is made.

FRecommended

operating conditions (Ta = 25_C)
