SHEET 1 OF 1
n
16.00
[.630 in]
SWITCH FUNCTION
POS. 1
POS. 2
n
18.00
[.709 in]
n
11.80
[.465 in]
RING ILLUMINATION
COLOR: TRANSPARENT GREEN
ON
PANEL CUTOUT
MAX. PANEL THICKNESS
14.0mm [.551]
1-3
(ON)
1-2
(ON) = MOMENTARY
HIGH ACTUATOR
ACTUATOR FINISH
STAINLESS STEEL
1
1
a
L
3
2
BODY FINISH
STAINLESS STEEL
10.40
n
[.409 in]
3.90
`
.50
[.154
`
.020
in]
b (+)
SPDT
CONTACT CONFIGURATION
M16x1.0
20.10
`
1.00
[.791
`
.039
in]
1.50
[.059 in]
NOTE 14
HARDWARE SUPPLIED
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. RATING: 2A 48VDC
6. ELECTRIC LIFE: 50,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MΩ MIN.
8. DIELECTRIC STRENGTH: 2,000 VAC MIN. FOR 1 MINUTE
9. CONTACT RESISTANCE: 50mΩ MAX. @ 1A 12VDC
10. OPERATING TEMP.: -20°C to 55°C
11. DENOTES CRITICAL PARAMETER.
12. LAMP VOLTAGE: 2V, BASE VOLTAGE
13. ILLUMINATION COLOR: GREEN
14. HARDWARE SUPPLIED: O-RING AND HEXNUT
15. WATERPROOF: IP67
29.00
`
1.00
[1.142
`
.039
in]
35.00
`
1.00
[1.378
`
.039
in]
36.00
`
1.00
[1.417
`
.039
in]
2.00
[.079 in]
1
(-)
1.80
[.071 in]
.80
[.031 in]
2.50
[.098 in]
.40
[.016 in]
(-)
1
2
3
(+)
2.80
[.110 in]
A
REV
20371
PCR NO
RELEASE FOR PRODUCTION
DESCRIPTION
12/29/11
DATE
BGL
BY
TITLE
SCALE
PV3WH2B0SS-331
2:1
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
12/29/2011
DR
BGL
DWG
52-PV3WH2B0SS331
REV
A
