MMC-14-A-9505-1-H-1-B-3 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> MMC-14-A-9505-1-H-1-B-3

MMC-14-A-9505-1-H-1-B-3: DescriptionSplitter/Coupler, 1X4 Port, 95/5 Ratio, SC/PC Connector; CategoryWireless rf/communication Optical fiber; File Size215KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

MMC-14-A-9505-1-H-1-B-3 Overview

Splitter/Coupler, 1X4 Port, 95/5 Ratio, SC/PC Connector

MMC-14-A-9505-1-H-1-B-3 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknow
Connection Type	SC/PC CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER
Fiber type	50/125
Maximum insertion loss	7.8 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Nominal operating wavelength	1550 nm
Port configuration	1X4
Split ratio/coupling ratio	95/5

Preview

Download Datasheet

View All

FBT COUPLER

Multimode Coupler

(Based on 50/50)

Parameter

Central Wavelength

Configuration

Insertion Loss*

50/125 Fiber

62.5/125, 100/140, 105/125 Fiber

Directivity

TDL

Operating & Storage Temperature

Light Duty ( B )

Package Dimensions

Medium Duty ( L )

(dimensions in mm)

Heavy Duty ( K, R )

1x2, 2x2

≤ 4.9 dB

≤ 4.6 dB

630, 850, 980, 1060, 1310, 1550nm

1x3

1x4

1x8

1x16

≤ 6.7 dB

≤ 7.8 dB

≤ 11.5 dB

≤ 15 dB

≤ 6.4 dB

≤ 7.5 dB

≤ 11 dB

≤ 14.2 dB

≥ 40 dB

≤ 0.2 dB

- 40° C ~ + 85° C

3.0(

) x55.0(L)

3.0(

)x60.0(L)

100 x 12 x 8

3.0(

) x60.0(L) 3.0(

) x 60.0(L) 3.0(

) x 60.0(L)

100 x 12 x 8

95 X 75 X 6

100 x 12 x 8

95 X 75 X 6

100 x 12 x 8

130 X 100 X 6

5.0(

) x 60.0(L)

135 x 100 x 10

130 X 100 X 8.5

Tap Couplers

Maximum Insertion Loss

Coupling

Ratio

60/40

70/30

80/20

90/10

95/5

99/1

50/125 µm

4.5/6.5 dB

3.9/8.0 dB

3.2/10.0 dB

2.7/13.5 dB

2.4/17.0 dB

1.4/22.0 dB

62.5/125 µm

3.6/5.8 dB

3.0/7.0 dB

2.4/9.0 dB

1.9/12.5 dB

1.5/16.5 dB

1.1/22.0 dB

100/140 µm &

105/125 µm

3.0/5.0 dB

2.3/6.3 dB

1.7/8.3 dB

1.2/12.0 dB

1.0/16.0 dB

0.8/22.0 dB

* All data tested under LED direct launching conditions.

Note1: All values specified are without connectors.

Note2: Higher performance specifications available upon request.

M M C-

-A-

Port Number A Grade

12: 1 x 2

22: 2 x 2

13: 1 x 3

14: 1 x 4

18: 1 x 8

116: 1 x 16

Wavelength

A: 630 nm

B: 850 nm

C: 1060 nm

D: 980 nm

E: 1310 nm

H: 1550 nm

Connector

0: None

1: FC/PC

3: SC/ PC

9: Special

C: ST

Coupling Ratio

Fiber Type

xy % : xy %

1: 50/125 µm

EVEN: even split 2: 62.5/125 µm

3: 100/140 µm

4: Special

5: 105/125 µm, NA=0.15

6: 105/125 µm, NA=0.22

Fiber Length

Pigtail Style

1: 1 meter

(=Package style)

2: 2 meter

B: bare fiber

S: Special

L: 900 µm loose tube

K: 2mm cable

R: 3mm cable

www.lighteltech.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
