Push-In |
Spacing 7.5 mm
AK4210/..VP-7.5-H-BAGY
- 2- to n-poles
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.2 mm²
10.0 mm²
0.2mm²
6.0 mm²
0.25 mm²
6.0 mm²
Order Data (Spacing 7.5 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
16.75
24.25
31.75
39.25
46.75
54.25
61.75
69.25
76.75
84.25
91.75
AK4210/2VP-7.5-H-baGY
AK4210/3VP-7.5-H-baGY
AK4210/4VP-7.5-H-baGY
AK4210/5VP-7.5-H-baGY
AK4210/6VP-7.5-H-baGY
AK4210/7VP-7.5-H-baGY
AK4210/8VP-7.5-H-baGY
AK4210/9VP-7.5-H-baGY
AK4210/10VP-7.5-H-baGY
AK4210/11VP-7.5-H-baGY
AK4210/12VP-7.5-H-baGY
Poles
Width (mm)
Article Designation
Article
Number
54210020407 D
54210030407 D
54210040407 D
54210050407 D
54210060407 D
54210070407 D
54210080407 D
54210090407 D
54210100407 D
54210110407 D
54210120407 D
PU
50
50
50
50
50
50
50
50
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
Dimensions
Stripped Length
PCB Hole Diameter
15.0 mm
2.1 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
8
9
10
11
12
Materials
Solder Tab
Clamp Spring
Copper
Alloy
Stainless
Steel
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
Accessoires
-
Figure
Designation
Spacer SPC-AK4210-H-baGY
Article Number
Order Data:
54210000000
Colours
BASALT GREY, RAL 7012
BLACK, RAL 9011
LIGHT GREEN, similar RAL 6018
GREEN, RAL 6018
BLUE, RAL 5015
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
- solid
- stranded
Test Voltage
B
600 V
35 A
C
600 V
35 A
D
600 V
5A
1000 V
41 A
III
min
max
10.0 mm²
6.0 mm²
3.5 kV
AWG 24-8
AWG 24-8
2.20 kV
AWG 24-8
AWG 24-8
2.20 kV
AWG 24-8
AWG 24-8
2.20 kV
0.2 mm²
0.2 mm²
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
