Power Inductors - Shielded
ctparts.com
CTDS1608BL Series
From .10 mH to 10 mH
Part
Number
CTDS1608BL_-104
CTDS1608BL_-154
CTDS1608BL_-224
CTDS1608BL_-334
CTDS1608BL_-474
CTDS1608BL_-684
CTDS1608BL_-105
CTDS1608BL_-155
CTDS1608BL_-225
CTDS1608BL_-335
CTDS1608BL_-475
CTDS1608BL_-685
CTDS1608BL_-106
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% only.
* 30°C Temperature rise.
CTDS1608BLF
Please specify “F” for Lead Free
Inductance
(mH ±20%)
.10
.15
.22
.33
.47
.68
1.0
1.5
2.2
3.3
4.7
6.8
10.0
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.95
1.4
1.7
2.2
3.8
4.9
9
11
19
24
30
56
74
Insulation
core-winding
Ω
(MΩ)
>10
>10
>10
>10
>10
>10
>10
>10
>10
>10
>10
>10
>10
SRF
Typ.
(MHz)
12
10
8
6
5
4
2
1
1
1
1
0.9
0.8
Current*
Max.
(mA)
220
200
180
160
140
120
100
80
50
40
30
20
10
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
6.6
0.26
B
Max.
4.45
0.18
C
Max.
2.92
0.12
D
1.02
0.04
E
1.27
0.05
F
4.32
0.17
G
3.05
0.1
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Back light of LCD displays
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%
Testing:
Tested on a HP4285A at 100 KHz , 0.1Vrms
Packaging:
Tape & Reel
Marking:
Color Dots OR Inductance code
Miscellaneous:
RoHS Compliant available.
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
Parts will be marked with
Significant Digit Dots OR Inductance Code
A
1st significant digit
B
Ind. Code
XXX
2nd significant digit
3rd significant digit
PAD LAYOUT
C
D
E
G
F
