Power Inductors - Unshielded
ctparts.com
CTGS104 Series
From 10 µH to 560 µH
Part
Number
CTGS104_-100M
CTGS104_-120M
CTGS104_-150M
CTGS104_-180M
CTGS104_-220M
CTGS104_-270M
CTGS104_-330M
CTGS104_-390M
CTGS104_-470M
CTGS104_-560K
CTGS104_-680K
CTGS104_-820K
CTGS104_-101K
CTGS104_-121K
CTGS104_-151K
CTGS104_-181K
CTGS104_-221K
CTGS104_-271K
CTGS104_-331K
CTGS104_-391K
CTGS104_-471K
CTGS104_-561K
Not shown at actual size.
SPECIFICATIONS
Part numbers indicate available tolerance
K = ±10%, M = ±20%
CTGS104F
Please specify “F” for RoHS Compliant
Inductance
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
L Test
Freq.
(_Hz)
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
1.0k
1.0k
1.0k
1.0k
1.0k
1.0k
1.0k
1.0k
1.0k
1.0k
DCR
Max.
Ω
(Ω)
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.20
0.22
0.25
0.34
0.40
0.54
0.62
0.72
0.95
1.10
1.24
1.53
1.90
Rated
DC
(A)
2.38
2.13
1.87
1.73
1.60
1.44
1.26
1.20
1.10
1.01
0.91
0.85
0.74
0.69
0.61
0.56
0.53
0.45
0.42
0.38
0.35
0.32
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD power inductor
Applications:
VTR power supplies, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±10%, ±20%
Testing:
Inductance is tested on an HP4284A or HP4285A at
specified frequency
Packaging:
Tape & Reel
Marking:
Marked with inductance code
Rated DC:
The value of current when the inductance is 10%
lower than its initial value at 0 Adc or D.C. current when at
∆T
= 40°C whichever is lower
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
10±0.3
0.39±0.012
B
9±0.3
0.35±0.012
C
4.2±0.5
0.17±0.020
D
Typ.
2.1
0.083
PAD LAYOUT
01.14.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
