Power Inductors - Unshielded
ctparts.com
CTGS73 Series
From 10 µH to 330 µH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Parts specify tolerance code when ordering.
CTGS73-100_
K = ±10%, L = ±15%, M = ±20% & N = ±30%
CTGS73F
Please specify “F” for RoHS Compliant
Inductance
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
L Test
Freq.
(_Hz)
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
1.00k
1.00k
1.00k
1.00k
1.00k
1.00k
1.00k
DCR
Max.
Ω
(Ω)
0.08
0.09
0.10
0.11
0.13
0.15
0.17
0.22
0.25
0.28
0.33
0.41
0.48
0.54
0.75
1.02
1.20
1.31
1.50
Rated
DC
(A)
1.44
1.39
1.24
1.12
1.07
0.94
0.85
0.74
0.68
0.64
0.59
0.54
0.51
0.49
0.40
0.36
0.31
0.29
0.28
Compliant
Available
RoHS
CTGS73_-100_
CTGS73_-120_
CTGS73_-150_
CTGS73_-180_
CTGS73_-220_
CTGS73_-270_
CTGS73_-330_
CTGS73_-390_
CTGS73_-470_
CTGS73_-560_
CTGS73_-680_
CTGS73_-820_
CTGS73_-101_
CTGS73_-121_
CTGS73_-151_
CTGS73_-181_
CTGS73_-221_
CTGS73_-271_
CTGS73_-331_
PHYSICAL DIMENSIONS
Size
A
7.8 ± 0.30
0.307 ± 0.012
B
7.0 ± 0.30
0.276 ± 0.012
C
3.5 ± 0.30
0.138 ± 0.012
D
Typ.
2.1
0.083
CHARACTERISTICS
Description:
SMD power inductor
Applications:
VTR power supplies, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±10%, ±15%, ±20% & ±30%
Testing:
Inductance is tested on an HP4285A at specified
frequency
Packaging:
Tape & Reel
Marking:
Marked with inductance code
Premissible Current:
The value of current when the inductance
is 10% lower than its initial value at D.C. superposition or D.C.
current when at
∆T
= 40°C whichever is lower
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
